Anchor Communications PortaCom Owner's Manual

Specifications

Components and specifications.
Pc-100 Power Console: Two-channel power console with external AC power adapter.
- output connectors (4):
- voltage output to belt packs:
- maximum current capacity:
- maximum belt packs:
- input power requirement:
- dimensions:
- weight
- AC 20 power adapter:
output voltage/current:
- AC 20/220 (export) power adapter: 230 VAC, 50/60 Hz
output voltage/current:
Bp-200 Belt Pack: Belt pack with volume control, A/B channel switch, mic mute
switch and call light.
- input line connector:
- headset connector:
- bridging impedance:
- DC current requirements:
- dimensions:
- weight:
H-200 Headset: Dual-earpiece headset.
H-200S Headset: Single-earpiece headset.
- connector:
- microphone type:
- dimensions:
- weight:
B3-100 Branch Box: 3-Station branch/extension box.
- input connector (1):
- output connectors (3):
- dimensions:
- weight:
Interconnecting cable: 2-conductor shielded cable
- 3-pin XLR connectors (male/female)
System Specifications:
- operating distance:
- nominal line level
- signal-to-noise ratio
- channel separation:
- distortion:
Specifications subject to change without notice.
Anchor Communications (310) 784-2300
100-0081-000 / Revision A, 02/98
3-pin XLR, male
22 volts DC
400 mA
20 BP-100 belt packs
24 VAC, 50/60 Hz, 750 mA;
or, 30-40 VDC, 500 mA
1.75 x 8.5 x 4.5" (45 x 216 x 114 mm)
3.6 lbs (1.7 Kg.)
120 VAC, 60 Hz
24 VAC @ 750 mA
24 VAC @ 750 mA
3-pin XLR, female
4-pin XLR, male
10 kΩ minimum
20 mA maximum
3.6 x 2.6 x 2.1" (91 x 66 x 53 mm)
0.46 lbs (0.2 Kg.)
4-pin XLR, female
dynamic, low impedance
noise cancelling
3.5 x 7.4 x 7.9" (89 x 188 x 201 mm)
H-200: 16 oz, H-200S: 13 oz
3-pin XLR, female
3-pin XLR, male
1.9 x 4.1 x 4.25" (48 x 105 x 108 mm)
1.2 lbs (0.5 Kg.)
2,500 feet
-15 dBV
-65 dB
-45 dB
< 0.5%
PortaCom
Owner s Manual
'
