MP3 PLAYER

FM TUNER

VOICE RECORDING

SLIDING USB JACK 내장

124 Colors Backlight

User Manual

MODEL :

CYPOSE I Series

DIMOTECH CO., Ltd

www.cypose.co.kr

Table of Contents

Need help?

Do you have a question about the CYPOSE I Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Dimotech CYPOSE I Series

Page 1 User Manual MP3 PLAYER MODEL : FM TUNER VOICE RECORDING CYPOSE I Series SLIDING USB JACK 내장 DIMOTECH CO., Ltd 124 Colors Backlight www.cypose.co.kr...
Page 2 Safety Instructions To remove a battery, turn off the power by pressing the POWER key longer. Searching memory by connecting PC, Please do not remove system file such as Config.sys and Map.sys Downloading firmware, please do not disconnect the cable from PC. You might not use the CYPOSE system.
Page 3: Table Of Contents
CONTENTS 1.1. Product Features 1.2. Product Specification 1.3. Package Contents 1.4. Name of Parts Connecting USB Jack Music Player Mode Usage Recording Mode Usage FM Radio Mode Usage Special Mode Usage Menu Usage Firmware Upgrade...
Page 4: Product Features
1 . 1 . Product Features Built-in USB Jack You can directly download the files on PC without optional USB cable because of built-in USB jack. (USB cable is provided as bundle) 3D Sound Effects and Bass Sense Experience the best audio realism with 3D sound effects with adjustment function of bass. Full Graphic 4Line LCD and 124 Colors Backlight Change the backlight depending on your mood and maximize your visibility with 124 colors backlight 4-line LCD (128 x 64 pixel).
Page 5 1 . 1 . Product Features 6 EQ mode and User EQ Enjoy quality sound with 6 Preset EQ Modes (Normal, Rock, Jazz, Classic, Live and Pop) or customize your own EQ by adjusting frequency bandwidth from -9dB to +5dB with 1dB setting. Media Sync Function CYPOSE is best for studying languages and supports a lyrics display by downloading Media sync function.
Page 6: Product Specification
1 . 2 . Product Specification Category Item Specification No. Channel Stereo (L+R) Frequency range 20Hz ~ 20KHz AUDIO 12mW ＋ 12mW (16 Ohm) Headphone Output S/N Ratio 90dB (MP3) Frequency range 87.5MHz ~ 108MHz FM Radio Headphone Output 12 mW ＋ 12mW S/N Ratio 50dB File format...
Page 7: Package Contents
1 . 3 . Package Contents Installation CD & Manual USB Cable Line-in Cable Necklace Earphone AAA Battery Option CYPOSE Carrying Case Arm band...
Page 8: Name Of Parts
1 . 4 . Name of Parts Front View Back View 1.Neck Strap 1.LCD Window 2.Battery Compartment 4.Volume + 3.Sliding USB 6.Jog Switch 5.Volume - 1.LCD Window 1. Neck Strap 2.To select the previous music for MP3 3.To select the next music for MP3 2.
Page 9 1 . 4 . Name of Parts Side View(1) Side View(2) 1.Earphone 1.Line-In 2.HOLD Key 2.REC Key 3.MODE Key 4.POWER Key 1.Earphone 1.Plug it to any external audio source (such as 2.REC Key : Recording and Folder/File Searching CD/LP/Cassette player) and CYPOSE will record 3.Mode Select : Music Player / Recording / onto the player in digital file format.
Page 10 1 . 4 . Name of Parts LCD Window Battery Indicator Folder Name Root Lose yourself Artist/Title Name Interval Repeat 00:02:17 Play Time Play Progress Bar 44KHz EQ Mode File Format 192Kbps Classic Shuffle On/OFF Playback Mode Sample Rate / Bit Rate...
Page 11: Connecting Usb Jack
2 . Connecting USB Jack Connecting USB Jack (USB Cable) 1. Press the green button of CYPOSE’s back side and Push it out. And the built-in USB jack appears. 2. Connect the USB jack to the USB port of your computer. (Or You can use USB cable(provided).) 3.
Page 12: Music Player Mode Usage
Music Player Mode Usage Music Player Mode consists of ‘Music File Player’ playing the music file and ‘Playlist Player’. MODE Player Playlist Player is the function you can specify Music File your preferred music to playback. Playlist 1. Press the MODE Key. Music Player 2.
Page 13 Music Player Mode Usage File navigation and file management on the File Navigation Screen Root Directory Move Move up Korean Pop Lose yoursel Move to sub folder / All the thin Move to upper folder Play Root Korean Pop Move down Delete Deleting file and folder Lose yoursel...
Page 14 Music Player Mode Usage Key operations during playback(2) Block Repetition : Use the ‘REC’ key during playback. Root Lose yourself 1.Press the ‘REC’ key shortly at the beginning position of the block you want be repeated. (A-) 00:02:17 2.Then press the key again at the ending position of the repeat block.(A-B) 44KHz 192Kbps Classic...
Page 15 Music Player Mode Usage Playlist Player Playlist Player Playlist Player is the function you can specify your preferred music to playback. Playlist Playlist I can’t figh I can’t fight Nookie 00:00:28 [Playlist Screen] [Playlist Playback Screen] 44KHz Calling All 192Kbps Classic To add to playlist Playlist...
Page 16 Music Player Mode Usage Change the order of the added files to the Playlist Playlist Playlist I can’t figh Nookie Nookie Calling All Calling All I can’t figh 1.Select the file you want move by pressing the Jog Switch upward/downward and Press the ‘Jog Switch’...
Page 17: Recording Mode Usage
Recording Mode Usage Select the ‘Recording Mode’ after pressing the ‘MODE’ key. Record Recording file name VOC-001 004:12:09 [Sound Source] Recording progress time 00:02:11 233,007 KB 44KHz 56Kbps Line-In VOR function on / off FM Radio Voice Recording (Recording voice with the built-in microphone) Record Do not connect anything to Line-in jack.
Page 18 Recording Mode Usage Line-In Recording (Direct Encoding) Record Line-In Recording is the function recording the audio signal from the LINE-001 audio device or PC 004:08:44 00:03:25 232,853 KB 44KHz 56Kbps 1. Connect the headphone jack of the CDP and the Line-in jack of the CYPOSE with two-way stereo cable.
Page 19: Fm Radio Mode Usage
FM Radio Mode Usage Select the ‘FM Radio Mode’ after pressing the ‘MODE’ key. FM Radio Stereo/Mono Stereo Preset Mode 95.90MHz Frequency No. FM Radio frequency range is from 87.5MHz to 108.0MHz Move up Key operation in the FM Radio Mode Shortly : Frequency/Preset down Shortly : Frequency/Preset up Longer : Auto Scan down...
Page 20 FM Radio Mode Usage Recording FM Broadcasting FM Radio Stereo 95.90MHz Within listening FM Radio, you can record FM radio. To record FM Radio, please press long ‘REC’ button. Record FM-001 It begins Record once recording mode screen display. 004:06:32 00:02:11 232,176 KB 44KHz...
Page 21: Special Mode Usage
Special Mode Usage Special Special Mode provides two additional function. Text Viewer 1. Text Viewer function 2. Stopwatch function Stopwatch Text-Viewer TXT files management Root Text file searching is possible only TXT files, and to view the text file, it is permitted When the ANSI form text.
Page 22 Special Mode Usage Stopwatch [Stopwatch Screen] The screen of stopwatch shows a timer at the top of the right. It can indicate 1/100 seconds and up to 99hour 59minitues 59 seconds and 99. Lap times also appear at the bottom of the screen 3 Lap times appear at once;...
Page 23: Menu Usage
MENU Usage Using the ‘MENU’ Into the ‘MENU’ Mode : Press the Jog Switch longer. Menu Move up Sound Click longer : Enter the MENU Backlight Click shortly : Set the MENU Display Move to upper menu Move to sub menu / Exit menu Move down [Menu List]...
Page 24 MENU Usage Sound Root Sound Equaliser dB +5 +2 Lose yourself Equalizer Base Sense 00:01:08 JAZZ 44KHz 3D Sound 192Kbps Classic 1.To enter the MENU, 2.Select MENU you want and press this key again shortly press this key longer Equalizer Move up Equaliser dB +5 +2...
Page 25 MENU Usage User EQ Equaliser Customize your own EQ by adjusting frequency bandwidth from -9dB to +5dB with 1dB setting. USER 1.Select User EQ and press the ‘Jog Switch’ to direction to turn into the ‘editing’ mode. 2.Change the values by pressing the Jog Switch to ‘+’ ‘-’ direction. 3.Press the Jog Switch shortly 4.Press the ‘Jog Switch’...
Page 26 MENU Usage Backlight You can change the backlight depending on your mood and maximize your visibility with 124 colors backlight Backlight Play Mode RED/GREEN/BLUE : 5 levels (0-4) Setting Mode List 6. Manual mode (FM Radio Mode) 1. Play (Music Player Mode) 7.
Page 27 MENU Usage Display Display Scroll Select the sub menus by pressing the Jog Switch upward/downward. Language Contrast Scroll Speed Scroll This is the feature to adjust the scroll speed of text on the LCD display. You can choose : Slow / Normal / Fast / Fastest Normal Language Contrast...
Page 28 MENU Usage Timer Timer Select the sub menus by pressing the Jog Switch upward/downward. Power Off Backlight Power Down Power Off When there is no button operation during a preset time while the CYPOSE is stopped, it is automatically turned off 1 min You can choose : 1 min, 2 min, 3 min ………...
Page 29 MENU Usage Player Boundary Select the range of item to be played Player by moving cursor up and down Boundary with Jog Switch. Boundary All Files * All Files: All tracks are played Repeat regardless of the folder Folder * Folder: Only the currently selected Shuffle One File folder is played...
Page 30 MENU Usage Battery Battery Select the battery type by pressing the Jog Switch upward/downward. You can check proper remained power level for each battery Rechargeable Rechargeable (1.2V) Alkaline Alkaline (1.5V) Recording Record Quality Select the sub menu by pressing the Jog Switch upward/downward. V.O.R.
Page 31 MENU Usage FM Radio FM Radio Select the sub menus by pressing the Jog Switch upward/downward. Auto Scan Stereo It is permitted only FM Mode. Preset Clear Auto Scan Auto Scan When you perform this function by pressing the Jog Switch, this is Stereo automatically search the broadcast station and it is set up preset 90.10MHz...
Page 32 MENU Usage Memory Memory Information Select the sub menus by pressing the Jog Switch upward/downward. Low Format Information Information Information on the flash memory in CYPOSE is displayed. Total : 248,558 KB Used : 129,442 KB Remain : 129,116 KB You can check usage and remaining memory size.
Page 33 MENU Usage FW Upgrade FW Upgrade Firmware is the internal program to operate the product. Connected You can download the latest firmware from our web site. Information The current version number of the firmware installed in CYPOSE is displayed.
Page 34: Firmware Upgrade
Firmware Upgrade Firmware Upgrade The function of CYPOSE can be improved. We provided the latest firmware. Users can download the latest firmware upgraded through a CYPOSE website. How to install the latest Firmware Enter menu Mode by pressing the Jog Switch longer Select ‘FW upgrade’...
Page 35 FCC Compliance THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED UNAUTHORIZED MODIFICATIONS TO THIS...
