- Page 1 Apator Powogaz S.A. ul. Klemensa Janickiego 23/25, 60-542 Poznań, Poland tel.: +48 61 84 18 101, fax: +48 61 84 70 192 www.apator.com Communication module APT-VERTI-1 User Manual ISO 9001 PN-N-18001 ISO 14001...
-
Page 2: Table Of Contents
Table of contents 1. APPLICATION ..........................3 2. REGULATORY AND STANDARD COMPLIANCE ..............4 3. DEVICE OVERVIEW ........................4 3.1. Device components .......................... 4 3.2. Device and standard accessory RF antenna dimensions ..............5 3.3. Specification ............................. 5 4. DEVICE OPERATION ........................6 4.1. -
Page 3: Application
1. APPLICATION The APT-VERTI-1 communication module is an RF intermediate transmission device between the RF data output meter modules and the meter-reading collector's app installed on a mobile device. The primary function of the communication module is to convert the data signals between an RF interface operating in the ISM 868 MHz band and a Bluetooth/USB interface. -
Page 4: Device Overview
× AT-WMBUS-05-4 Retransmitter The APT-VERTI-1 enhances the success rate of RF communication data frame reading. This mode of operation gives up to a 10% improvement in conflicting data frame recovery (depending on the network traffic intensity). 2. REGULATORY AND STANDARD COMPLIANCE Apator Powogaz S.A. -
Page 5: Device And Standard Accessory Rf Antenna Dimensions
3.2. Device and standard accessory RF antenna dimensions Physical characteristics 3.3. Specification Wireless M-Bus T1 mode 868.950 MHz T2 mode 868.300 MHz Transmitter power output 14 dBm (25 mW) Receiver sensitivity -110 dBm Bluetooth Transmitter power output 4 dBm (2.5 mW) Range max 10 m Profile... -
Page 6: Device Operation
1. Keep the Bluetooth-enabled mobile terminal within 10 m of the APT-VERTI-1 communication module. 2. Switch on the APT-VERTI-1 Bluetooth interface. Briefly depress the On/Off/Bluetooth selector button (3). The blue LED (6) will flash when the Bluetooth interface is on. -
Page 7: Power Saver Mode
4.6. Battery charging and maintenance Due to the performance characteristics of lithium-ion battery packs, avoid leaving the APT-VERTI-1 communication module with the battery drained for too long. Otherwise, the battery service life will be reduced. The battery is deeply discharged when the red LED (4) blinks briefly every 10 seconds. - Page 8 Distributor: Apator Powogaz S.A., ul. Klemensa Janickiego 23/25, 60-542 Poznań, Poland tel. +48 (61) 84 18 101; fax +48 (61) 84 70 192 Apator Powogaz S.A. has the right to modify and improve the products without notice.
