8210 Presidents Drive
Orlando, Florida 32809
svision.com
WARNING!
PERMANENT
DAMAGE TO THE
12VAC LAMP WILL
OCCUR IF IT
INSTALLED IN A
120VAC SOCKET.
The IGS54 and the IGS321
are available in either
12VAC (low volatge) model
and a 120VAC mode.
The 120VAC light has a
gold or brass colored
Edison screw base.
The 12VAC Edison screw
base is a silver or aluminim
color.
DANGER
!
RISK OF ELECTRICAL
SHOCK OR
ELECTROCUTION
Always disconnect power
to the pool or spa light at
the circuit breaker before
servicing the light. Failure
to do so could result in
death or serious injury to
the installer, servicemen.
pool and spa users or
others due to electrical
shock.
Refer
to
the
original
manufacturer's installation
manual before proceeding.
This device is not intended
for use with emergency
exit fixtures or emergency
exit lights.
DELIVER TO HOMEOWNER
IGP231/IGS54
Galaxy LED Lamp
Installation/Operation/Warranty
This guide contains important information on installing
and using your Galaxy LED Lamp. Please read it
carefully and save it for future reference.
Rated Lamp Life
The illumination generated by the Galaxy LED Lamp is
based on Light Emitting Diodes (LED) whose predicted
source life is rated at 100,000 elapsed time hours under
normal operating conditions.
[Temperature: -4° to 104°F (-20°C to 40°C), Humidity:
0-95% non-condensing humidity]. This equates to 11.4
years of continuous 24-hour a day usage.
Safety Precautions
Do not open, alter or tamper with the product. This
will void the manufacturer's warranty. Follow all
instructions in the user guide, and observe all warnings
carefully.
•
Do not allow the LED unit to get wet. It is conformal
coated to protect it from moisture.
•
Keep the unit dry.
•
Handle the Galaxy LED Lamp as you would any
delicate product. Be careful not to drop the unit.
IGP231
Pool LED Lamp
IGS54
Spa LED Lamp
