Development Kit Manual
DK-114N-1 and DK-114N-3
Overview
Big Chip LEDs from Luminus Devices have been designed
from the ground up to enable a new class of illumination and
projection systems. Benefiting from a suite of innovations in
chip technology, packaging, and thermal management, Big
Chip LEDs allow designers to achieve efficient light engine
designs and deliver high brightness solutions.
The DK-114N series development kit is a comprehensive so-
lution designed specifically to support the development of
single and three channel PT and CBT series Big Chip LEDs.
Each channel of the kit, comprising of a high current driver, an
efficient thermal management solution and cables is capa-
ble of sourcing a drive current of 14 A and ensures that CBT
and PT series LEDs are operated at up to 70 W for maximum
brightness. This plug and play solution can easily be connect-
ed to common laboratory equipment through standard con-
nectors and allows system designers to save weeks in their
development cycles.
1
960017 Rev C
© 2013 Luminus Devices, Inc. - All Rights Reserved
DK-114N series - Development Kit Manual

Table of Contents

1. Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2. Development Kit Contents . . . . . . . . . . . . . . . .2
2.1 Heat Sink and Driver Board . . . . . . . . . . . . .2
2.2 Cable Assembly . . . . . . . . . . . . . . . . . . . . . . . .3
2.3 TIM and Mounting Hardware . . . . . . . . . . .4
3. User Instructions . . . . . . . . . . . . . . . . . . . . . . . . .4
3.2 Electrical Connections . . . . . . . . . . . . . . . . . .6
3.3 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
4. Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Luminus Devices, Inc. • T 978.528.8000 • www.luminus.com
1100 Technology Park Drive • Billerica, MA 01821

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DK-114N-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Luminus DK-114N-1

  • Page 1: Table Of Contents

    Development Kit Manual DK-114N-1 and DK-114N-3 Overview Big Chip LEDs from Luminus Devices have been designed from the ground up to enable a new class of illumination and projection systems. Benefiting from a suite of innovations in Table of Contents...
  • Page 2: Key Features

    The DK-114N-1 and DK114N-3 are similar in all aspects; while the DK-114N-1 supports one channel, the DK-114N-3 supports three channels. All instructions in this manual are based on the DK-114N-1 and can easily be replicated in the DK-114N-3. As shown in Figure 1, the DK- 114N-1 consists of : •...
  • Page 3: Cable Assembly

    • Driver board to LED cables • Signal cable • Thermistor cable Luminus Devices, Inc. • T 978.528.8000 • www.luminus.com 1100 Technology Park Drive • Billerica, MA 01821 960017 Rev C © 2013 Luminus Devices, Inc. - All Rights Reserved...
  • Page 4: Tim And Mounting Hardware

    3. User Instructions The following sections explain the set-up and operation of the DK-114N-1 Development Kit. Additional lab equipment such as a 12 V laboratory power supply, an oscilloscope, a waveform generator, a multimeter and a photodetector are required to power and use the DK-114N-1.
  • Page 5: Device Mounting Instructions

    The device is now mounted and ready for electrical connections (Figure 9). Figure 9: LED mounted on heat sink Luminus Devices, Inc. • T 978.528.8000 • www.luminus.com 1100 Technology Park Drive • Billerica, MA 01821 960017 Rev C © 2013 Luminus Devices, Inc. - All Rights Reserved...
  • Page 6: Electrical Connections

    3.3 Operation The DK-114N-1 can be used to drive LEDs in continuous-current controlled mode via the on-board POT or through an external analog voltage. Additionally, each channel has inputs for PWM dimming using an external function generator and supports frequencies up to 40 kHz.
  • Page 7 Figure 12 shows the relationship between the LED current and the external voltage. Figure 12: LED Current as a function of External Voltage Luminus Devices, Inc. • T 978.528.8000 • www.luminus.com 1100 Technology Park Drive • Billerica, MA 01821 960017 Rev C © 2013 Luminus Devices, Inc. - All Rights Reserved...
  • Page 8 (Fig 7) must be connected to the on board thermistor. The resistance across the cable’s leads can then be used to monitor temperature. Figure 13: Coreboard temperature as a function of thermistor resistance Luminus Devices, Inc. • T 978.528.8000 • www.luminus.com 1100 Technology Park Drive • Billerica, MA 01821 960017 Rev C © 2013 Luminus Devices, Inc. - All Rights Reserved...
  • Page 9 LEDs. The driver board in the DK-114N-1, based on National Semiconductor’s LM3433 IC, addresses the challenge of connecting multiple common anode LEDs by utilizing a grounded common anode topology, i.e., the anode is kept at ground and the cathode is at a negative potential, thus enabling LEDs to be in contact directly with the heat sink.
  • Page 10 12 V / 12.5 A 3.9” x 2” X 7.8” mount SWS Series Luminus Devices, Inc. • T 978.528.8000 • www.luminus.com 1100 Technology Park Drive • Billerica, MA 01821 960017 Rev C © 2013 Luminus Devices, Inc. - All Rights Reserved...
  • Page 11 Appendix F: Driver Board Schematic and Pinout Figure 15: Schematic of driver board Luminus Devices, Inc. • T 978.528.8000 • www.luminus.com 1100 Technology Park Drive • Billerica, MA 01821 960017 Rev C © 2013 Luminus Devices, Inc. - All Rights Reserved...
