Summary of Contents for Biocare Petrust Plus

  • Page 1 International user manual...

  • Page 2: Table Of Contents

    Contents Introduction ....................... 1 Safety Precautions ....................2 Warranty ........................4 Intended Use ......................5 Section 1. Controls & Display ..............6 plus pettrust Keypad description ..............6 Side Panel ........................8 Data Transmission .................... 8 The External AC Indicator ................9 Section 2.
  • Page 3 Cycle Time Key Function ................27 Section 4. Maintenance ................28 Event Codes......................28 Maintenance and Cleanning ..............29 Section 5. Specifications ................30 Components of the Product ..............30...

  • Page 4: Introduction

    Introduction plus pettrust is developed to accurately measure the blood pressure of dogs and cats, with a high degree of accuracy. In the measurement of blood pressure, the user's experience and practices for equipment performance is very important. The user manual is a guide designed to help you understand the capabilities and operation of your pettrust NIBP monitor.

  • Page 5: Safety Precautions

    Safety Precautions * Please follow this instructions and use it correctly. * The following safety precautions are for the prevention of danger and damage. * Details are as follows : Symbol Damage content Mandatory compliance Absolutely prohibited items Before the measurement begins, make sure that the pressure does not cause the dog and the dog to worsen.
  • Page 6 DO NOT operate the unit in a highly flammable environment. If the measurement site has edema or congestion, please stop measuring. DO NOT use other cuffs for measurement. DO NOT use other brands of chargers for charging. DO NOT operate the unit with wet hands to avoid electric shock or malfunction. DO NOT press the button with a sharp item.

  • Page 7: Warranty

    BioCare’ s obligation under this warranty is limited to repairing, at BioCare’ s option, any part which upon BioCare’ s examination proves defective.

  • Page 8: Intended Use

    Intended Use Introduction The pettrust offers the advantages over previous veterinary blood pressure. Using pettrust, the BP can be measured in awake or anesthetized animals. pettrust use the oscillometric method which simplifies the measurement of blood pressure in companion animals. It is useful for monitoring BP and heart rate during surgical procedures on animals under anesthesia.

  • Page 9: Section 1. Controls & Display

    Section 1. Controls & Display plus ・ pettrust Keypad description ① . SYS ② . MAP ③ . The External AC Indicator ④ . Power key ⑤ . Alarm Silence / Pulse sound switch ⑥ . Cycle time ⑦ . Review ⑧...
  • Page 10 Function Press to turn power on. Press and hold for 3 seconds to turn ④ Power key power off. Press this key to alarm silence. Alarm Silence ⑤ In the measurement, press the button to open the pulse. Pulse sound measurement start key.

  • Page 11: Side Panel

    ・ Side Panel 1. Reset : return default situation. 2. NIBP connector : NIBP cuff hose connects. 3. Battery charge connector : Connect the charger. 4. Mini USB port : When you install the dedicated BT Dongle. You can sent data to the PC by wireless transmission.

  • Page 12: The External Ac Indicator

    ・ The External AC Indicator Indicators Explanation Indicating that the battery power is too low, if not charged, the device will automatically shut down. Connecting the battery charger with the device and the Orange batteries are charging. The batteries are fully charged. Green...

  • Page 13: Section 2. Setup Procedures

    Section 2. Setup Procedures ・ Placing the Unit into Service １． Remove the pettrust from the shipping container. 2． Connect the battery charger as described 3． Ensure the external AC Indicator is on. 4． Allow the monitor’ s battery to charge for 8 hours. ・...

  • Page 14: Lcd Drawing

    ・ LCD Drawing Press the button, will enter the initial screen : Time system Time Review Date Alarm Unit Cycle time Wait a few seconds then entering the standby screen : Number of stored data...

  • Page 15: Setting The Monitor

    ・ Setting the Monitor Press the and hold for 3 seconds, will enter the setup mode. You can setting the date, time, units, alarm limits, button beep and memory deletion can be set in the monitor. ☑ Note one : Press up or down button to make changes.
  • Page 16 2. Month Setting The month could be set from 1 to 12. 3. Day Setting The day could be set from 1 to 31 depend on month and year. It had been preset by program.
  • Page 17 4. Hour Setting The hour could be set from 0 to 23.　　　　　　　　　　　　 5. Minute Setting The minute could be set from 0 to 59.
  • Page 18 6. 12H/24H (AM/PM) Setting The time format could be changed automatically between 12H or 24H by user. 24 H to 00: 00 ~ 23: 59 display. 12 H to 12: 00 ~ 11: 59AM or PM display.　　　　　　　　　　　 7. Unit of Blood Pressure Setting The unit could be changed automatically between “...
  • Page 19 8. Alarm Limit Settings A. Alarm will activate when a high alarm limit is exceeded or the measured valve drops below a low alarm limit. The monitor provides visible and audible alarms on the interface display screen. B.Preset and Adjustable Range : Preset Adjustable Range 240 mmHg(32.0 Kpa)
  • Page 20 C. Systolic_High Setting The alarm limit for Systolic_High could be set as shown on the right. 　　　　　　　　　　　　　　　　　　　　 D. Systolic_Low Setting The alarm limit for Systolic_Low could be set as shown on the right. E.Diastolic_High Setting The alarm limit for Diastolic_High could be set as shown on the right. 　　　　　　　　　　　　　　　　　　　　...
  • Page 21 F. Diastolic_Low Setting The alarm limit for Diastolic_Low could be set as shown on the right. G. Mean Arterial Pressure_High Setting The alarm limit for Mean Arterial Pressure_High could be set as shown on the right. 　　　　　　　　　　　　　　　　　　　　 H. Mean Arterial Pressure_Low Setting The alarm limit for Mean Arterial Pressure_High could be set as shown on the right.
  • Page 22 I. Pulse Rate_High Setting The alarm limit for Pulse Rate_High could be set as shown on the right.　　　　　　　　 J. Pulse Rate_Low Setting The alarm limit for Pulse Rate_High could be set as shown on the right. Attention : The auditory and visual alarm manifestations shall active immediately once beyond limit range.
  • Page 23 9. Button Sound ON/OFF Setting The button sound (beep) could be changed between “Yes (ON)” and “No (OFF)” by user. Attention : If select the “No” option. It will not affect the original setting of alarm silence. 10. Communication Selection Setting The button communication selection could be changed between “H (high speed)”...
  • Page 24 11. Pulse sound ON/OFF Setting The button pulse sound could be changed between “Yes (ON)” and “No (OFF)” by user. In the measurement, press the button can also open the pulse sound. Attention : If select the “Yes” , the auditory and visual manifestations shall active immediately once pulse is detected.
  • Page 25 Alarm Silence Key Function : 1. Pressing this alarm silence button momentarily will to alarm silence. 2. A bell icon with a “X” indicates that an alarm limit has been turned to “OFF” when the icon appears in the LCD screen. 3.

  • Page 26: Section 3. Operating Instructions

    Section 3. Operating Instructions In order to accurately measure the blood pressure of dogs and dogs, you must choose plus the appropriate cuff size and measurement sites. pettrust in order to respond to different use of the situation, also has a variety of different measurement mode. This section will be for the cuff winding method, the measurement of the precautions and a variety of measurement models to do a detailed introduction.

  • Page 27: Select The Measurement Position

    ・ Select the measurement position As shown on the right Ａ ・ Front legs Ｂ ・ Hind legs Ｃ ・ Tail Best choice : A > B > C ・ Placing the NIBP Cuff As shown on the right 1. The end of the cuff should fall inside the range on the inside of the cuff.

  • Page 28: Operation Precautions

    ・ Operation precautions 1. For optimum accuracy, the patient should remain still during blood pressure measurement. Gentally insert 2. The right size cuff applied to the limb. the connector 3. The animal should be in a comfortable position. No weight bearing on the test sites with cuff is used.

  • Page 29: Measurement Start

    Measurement start ・ Normal Measurement mode 1. Pressing the NIBP key will cause the monitor to take one measurement. 2. Once press the NIBP key again. It will stop to measure and deflate the pressure immediately. 3. Measuring time of about 30 to 90 seconds, depending on the size of the cuff.

  • Page 30: Cycle Time Key Function

    ・ Cycle Time Key Function 1. If an NIBP cycle time has been selected the monitor will automatically take NIBP measurements at scheduled intervals. 2. Selectable cycle time range : 10sec, 01,02,03,05, 1 0, 1 5,30,60,90min, 02hours. 3. Press the button to end the cycle time.

  • Page 31: Section 4. Maintenance

    Section 4. Maintenance This section explains cleaning and maintenance, error codes, and troubleshooting in this section. If the error code is generated, please check the size of the cuff in detail and refer to the precautions in the previous section and remove the wrong part ・...

  • Page 32: Maintenance And Cleanning

    ・ Maintenance and Cleanning 1. Cleaning the Monitor ☑ Turn the power off before cleaning the monitor. ☑ The exterior surface of the pettrust may be wiped clean using alcohol and then dried with a clean, dry cloth. ☑ Never immerse the monitor in liquids. ☑...

  • Page 33: Section 5. Specifications

    Section 5. Specifications ・ Components of the Product Name Specifications content NIBP Range 30~300 mmHg 300 mmHg Resolution 1 mmHg Accuracy ± 3 mmHg or 2% Heart Rate Range 32~240 BPM (Pulse) Resolution 1 BPM Accuracy ± 3 BPM or 2% Battery type Internal rechargeable Lithium ion battery packs (4.2 V) Power...
  • Page 34 Name Specifications content Environmental Storage environment : Temperature C to 50 C ( 14 F to 122 Humidity 15 to 90 % (non-condensing) Atmospheric Pressure 619 to 775 mmHg (825 to 1033 hPa) Operating environment : Temperature 0℃ to 45℃ Humidity 15 to 90 % (non-condensing) Atmospheric Pressure...
  • Page 35 2018pep01V01_EN 2018.01 Ver. 1 .0...
