Advanced Diagnostics AD30 Operating Instructions

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

'ON' Switch
Audible
Detection
Signal
Detection LED
1
Power
Note: Although the detector needs to be as close as possible to the coil ,on certain vehicles
a) The coil will emit a signal when the door is opened.
b) The coil will emit a signal when the ign key is inserted into the ign and not turned on.
c) The 'OK' LED will flash at various times and the sound will vary dependant upon car.
Size
Weight
Auto Power Off
Power
AD30 Operating Instructions
Step
2
Specification
+
ok
And / Or
ok
78(w) x 117(h) x 24(d)
135g
Yes. Approx 2 mins
9v / PP3 Battery
Detection Area
Power LED
Result
= Coil OK
= Fault
