Quick Start Guide
Wi-Fi TO RS-232/422/485
CONVERTER
MODEL HXSP-2108W
1
1
1
.

Check Package Content

HXSP-2108W unit
RS-232 DB9 Female Crossing configuration cable
Software CD
Ext power adapter
Printed version of this HXSP-2108W Quick Start Guide
2 2

.Hardware Installation

Connect RS-232 DB9 Female Crossing configuration cable
to HXSP-2108W unit on RS-232 side.
Connecting the Power Adapter to HXSP-2108W power jack.
When the power is properly supplied.The Link and DIS. LED
will light in red and yellow color until the system is ready, at
which time the Link. LED will be put out and DIS PWR LED
still light.
RS-232/422/485 Pinouts
RS-232 Pinout(DB9 Female )
PIN RS-232
2 RXD
3
5
7
8
RS-422/485 Pinout(SIX Terminal from Left)
PIN
1
2
3
4
5
6
3
3

LED indication

LINK ---- Indicate WLAN status
DIS ---- Indicate WLAN status
ACT ---- It will flash when transmit the data from WLAN to
1Pcs
serial or from serial to WLAN.
PWR ---- Indicate the Power supply
1Pcs
Detail for LINK,DIS Led indicate
1Pcs
LINK
1Pcs
1Pcs
4 4

.Software Installation

I
nsert the software CD and search for such as F:/Tool/
pcommlite folder to run Settup.exe.Note: Be sure you have
administrative rights &disable firewalls in windows XP
5 .
5

Configure the HXSP-2108W

erial Console (38400, n, 8, 1)
Input/Output
Before configuring the HXSP-2108W via the serial console,
I
TXD O
GND -
RTS O
CTS I
RS-422 RS-485
T+ 485+
T- 485-
R+ NC
R- NC
VIN+ VIN+
VIN- VIN+
DIS Status
OFF OFF WLAN Connecting
ON OFF WLAN Connected
OFF ON WLAN Disconnect
ON ON Setup Command
turn off the power and use a serial cable to connect the
HXSP-2108W to your computer's serial port. We suggest
using PComm Terminal Emulator, which is available in CD
driver to carry out the configuration procedure. Firstly install
PComm Terminal Emulator on your computer.
Connect HXSP-2108W RS-232 serial port directly to your
computer's male RS-232 serial Port with RS-232 DB9 Female
Cross Configuration cable
From the Windows desktop, click on Start # Programs #
PComm Lite # Terminal Emulator.
When the PComm Terminal Emulator window opens,
first click on the Port Manager menu item and select Open,
or click on the Open icon.
The Property window opens automatically. From the
Communication Parameter page,
select the appropriate COM port for the connection, COM1 in
this example, and 38400 for
Baud Rate, 8 for Data Bits, None for Parity, and 1 for Stop
Bits.
From the Property window.s Terminal page, select ANSI
or VT100 for Terminal Type, and click on OK. If you select
