Attaching the pedestal
Removing the pedestal from the TV
Be sure to remove the pedestal in the following way
when using the wall-hanging bracket or repacking the
TV.
1
Lay the TV on a foam mat or thick soft cloth on a
table.
2
Remove the assembly screws
3
Pull out the pedestal from the TV.
4
Remove the assembly screws
1
3
2
from the TV.
from the bracket.
Inserting remote's batteries
Note the correct
polarity (+ or -)
Wall mounting the TV (optional)
Please contact your local Panasonic dealer to purchase
the recommended wall-hanging bracket.
Rear of the TV
a
b
Screw for fixing the TV onto the
wall-hanging bracket (not supplied)
■
Holes for wall-hanging bracket installation
a: 200 mm
b: 200 mm
■
Screw specification
Diameter: M4
Depth of screw:
Minimum: 9 mm
Maximum: 14 mm
Warning
●
When optional accessories such as wall brackets etc.
are used, always read and follow the manufacturer
installation and usage instructions.
●
Do not mount the unit directly below ceiling lights (such
as spotlights or halogen lights) which typically give
off high heat. Doing so may warp or damage plastic
cabinet parts.
●
When installing wall brackets you must ensure the wall
bracket is not electrically grounded to metal wall studs.
Always ensure that there are no electrical cables,
pipes etc. in the wall before you begin the wall bracket
installation.
●
To prevent fall and injury, remove the TV from its fixed
wall position when it is no longer in use.
Press the hook and
lift the cover
(View from the side)
Depth of
screw
