Barska 10-25x42 BATTALION Manual

CAUTION: DO NOT LOOK DIRECTLY AT THE
SUN VIEWING THE SUN OR ANY LIGHT
SOURCE WITH THIS OPTICAL DEVICE CAN
CAUSE PERMANENT EYE DAMAGE.
INSTRUCTIONS FOR USE
1. Remove protective lens covers.
2. Hold monocular with one hand and use the
other hand to focus in on an object in the
distance. Using the zoom ring rotate the
ring either right or left to zoom in and/or out.
FOCUSING
Bring viewed object into focus by slowly
twisting the main focus wheel knob either
right or left in the center of the barrel, until
you have a clear image.
ROLL DOWN EYECUP
The eyecup is designed for comfort and excludes
extraneous external light.
For sun/eye glasses users, roll down the eyecup.
This will bring the eye closer to the monocular
lens thus providing improved field of view.
TRIPOD ADAPTABLE FITTING
The monocular is equipped with a built in standard tripod adaptor located on the body of
the monocular near the focus wheel, where the neck strap can be attached. The tripod
adaptor can be attached to most tripods for easy hands-free use.
HOW TO CARE FOR YOUR MONOCULAR
1. When wiping the eyepiece or objective lens, use the included lens cloth or a soft
lint-free cloth. To remove any visible dust or debris by blowing or using a lens brush.
2. To remove any remaining dirt or smudges, add 1 or 2 drops of alcohol to a lens cloth
and gently wipe lens and eyepiece in a circular motion.
3. Always use lens caps when monocular are not in use
4. Store monocular in a moisture-free area.
IMPORTANT: Never attempt to clean your monocular internally or attempt to take
monocular apart.
BC274
10-25x42 BATTALION
Parts of the Monocular
®
©2013 BARSKA La Verne, CA 91750, USA
www.barska.com
Monocular Manual
Magnification Ring
Objective Lens
Eyepiece &
Eyecup
Zoom
Main Focus
Wheel
2/13
