WatchMate Vision
INSTALL GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WatchMate Vision and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vespermarine WatchMate Vision

Summary of Contents for Vespermarine WatchMate Vision

  • Page 1 ® WatchMate Vision INSTALL GUIDE...

  • Page 2: Optional Accessories

    Your WatchMate Vision is a Class B AIS Transponder with a ® CONNECTIONS Colour Touch Display and integrated NMEA 2000 and WiFi connectivity. • USB The WatchMate provides information to improve your situational awareness and assist in avoiding collisions at sea. Because it consumes very low power it may be • AIS/VHF left turned on whenever your vessel is underway. It works by interpreting Universal antenna Shipborne Automated Identification Systems (AIS) message which are sent over VHF by transponders installed on other vessels. The AIS system uses two dedicated VHF channels designated for this purpose and with the installation of the WatchMate to recieve these signals you can view this information. You can also distribute this information to other devices on board your vessel (e.g. chart plotters, laptops, smart phones) using NMEA 2000, USB and WiFi. In addition, your vessel data is transmitted to other AIS-equipped vessels within range. For more information on AIS go to www.vespermarine.com/vision • GPS antenna...

  • Page 3: Gps Antenna

    GPS ANTENNA POWER AND DATA A 2m (6.5’) cable with attached 10 pin connector is supplied for connecting the The WatchMate requires a GPS fix before it can transmit its position. WatchMate to power, other devices over NMEA 0183 and an external alarm. You may extend this cable as necessary. Internal • Check you have the VHF antenna connected before connecting to power. The WatchMate has a built-in GPS patch antenna. • Fully engage the locking ring to ensure a watertight seal. Internal GPS • This antenna requires an unobstructed antenna location view of the sky. COLOUR DESCRIPTION • The antenna performance may be significantly reduced if the WatchMate DC positive (+) (12-24 volts). Always use a 2A is installed on, under, or near large fuse or circuit breaker. Do not connect directly metal structures.
  • Page 4 An aid to navigation. A search and rescue transponder (AIS SART). ® This symbol appears around a target to indicate it is the currently selected target. WATCHMATE WHEEL Press the Select button to view the complete target details. Offscreen Area This symbol is overlayed over a target to indicate the target is “lost”. No AIS data Wheel The WatchMate Wheel is a context sensitive has been received from the target within the expected interval. selection menu, providing access to relavent features as you navigate through each mode. Indicates your AIS data is not being transmitted. You can use the AIS Status screen to determine the reason. • The Wheel is activated and controlled by When used with a Vesper Marine AIS/VHF antenna splitter this symbol indicates touching the offscreen area. the VHF radio is in-use and AIS transmissions are temporarily disabled. • It’s adaptive and knows what menu is • Color and size of targets change depending on their alarm state. relevant to the mode you are currently interacting with. • The triangle points in the direction of the target’s heading (or course if heading data is not available for the target). • Flick your finger for fast moves, or simply tap • You must have a valid GPS fix for any targets to be shown on the up or down to make small adjustments. situation display. • ??? • Go to www.vespermarine.com/vision for additional information.

  • Page 5: Client Mode

    DROP CABLE RESISTOR WatchMate • Password: S 036 037.325 E 175 005.143 OFFSHORE S/Y MIMOSA We recommend that you change your password straight away. You can always access the password in Wifi settings. Supported PGN’s Vision The default IP address that mobile apps may need is 192.168.15.1 (Port 39150) Be sure to check out www.vespermarine.com/vision for an up-to-date list and description of PGN’s that are supported. Client Mode PGNs Received PGNs Sent (continued) 129040 AIS Class B Extended Position 127250 Vessel Heading iPad 129794 AIS Class A Static Voyage PGNs Sent 129798 AIS SAR Aircraft Position 129025 Position 129801 AIS Addressed Safety 129026 COG & SOG...
  • Page 6 MMSI and Your position will be transmitted every 3 minutes when your speed is under Call Sign for your vessel. If you do not have an assigned MMSI, contact the 2 knots or every 30 seconds otherwise. Your vessel information (e.g. name, callsign, etc) is transmitted every 6 minutes. If the warning symbol is still visible, relevant authority in your country. touch it to display the reason. See the troubleshooting section for • You can configure your WatchMate in either Tools mode, using the the probable cause. WatchMate App or the vmAIS PC software. The WatchMate App and vmAIS are avialable for download from www.vespermarine.com/vision • With vmAIS you can connect to the WatchMate using either the USB virtual GOT A QUESTION? COM port or over WiFi* by entering the IP address (192.168.15.1 default). Click the connect button and enter your vessel details using this screen: Visit www.vespermarine.com/vision for comprehensive answers to frequently asked questions, technical support, downloads, local dealer contacts and more… • Once you save the MMSI number it cannot be changed. If you need to change the MMSI, please contact an authorised dealer or Vesper Marine.

  • Page 7: Tech Specs

    TECH SPECS TROUBLESHOOTING The symbol indicates your AIS data is not being transmitted. It is located at Size 172mm wide x 130mm high x 60mm depth (6.85” x 5.12” x 2.44”) the top left of the WatchMate screen, click on it to reveal the AIS Transponder Status panel. Colour TFF screen Touch panel STATUS DESCRIPTION Power supply 12-24 VDC 2A max, 6W nominal You must have a valid MMSI programmed before you MMSI CONFIGURED Environmental Watertight (USCG CFR-46, IPx7) can transmit your position (see configuration section). Operating temp -25°C to +55°C (-13°F to 131°F) Silent mode is on. If this is not intentional check silent SILENT MODE IS OFF Storage temperature -25°C to +80°C (-13°F to 176°F)
  • Page 8 WARNINGS This AIS Transponder works in conjunction with other vessels and systems such as other AIS transponders Pour satisfaire aux exigences d’exposition aux frequencies radio pour les appareils mobiles de transmission, and GPS devices. The accuracy of this device and the AIS system can be affected by many factors, une distance de 1 mètre ou plus doit être maintenue entre l’antenne de ce dispositif et les personnes including equipment failure or defects, environmental conditions and incorrect installation, handling or pendant son fonctionnement. Pour assurer la sécurité, les opérations plus près de cette distance ne sont pas recommandées. use. Vesper Marine does not warrant that this product is error-free. It is the user’s responsibility to exercise common prudence and navigational judgement. This device should not be relied upon as a substitute for L’antenne utilisée pour ce transmetteur ne doit pas être co-localisés avec toute autre antenne ou such prudence and judgement. Always maintain a permanent watch so that you can respond to situations transmetteur. as they develop. The prudent mariner will not rely on a single aid to navigation. The user should verify the information obtained from this AIS Transponder is in accordance with expected situations and conditions. The Ce dispositif a été conçu pour fonctionner avec une antenne ayant un gain maximalde 3dBi. Les antennes information is not guaranteed to be accurate or reliable and this AIS Transponder is not a substitute for proper ayant un gain supérieur à 3dBi sont strictement interdits pour une utilisation avec cet appareil. L’impédance d’antenne requise est de 50 ohms. seamanship. Vesper Marine Limited cannot be held liable for any injury, damage or loss, caused by, during, or because of the installation, use or inability to use this device. This AIS Transponder is to be installed and used Pour réduire le risque d’interférence aux autres utilisateurs, le type d’antenne et son gain doivent être choisis entirely at your own risk. By installing and/or using this AIS Transponder you fully accept this risk and agree to pour que la puissance isotrope rayonnée équivalente (PIRE) ne soit pas supérieure à celle requise pour une hold Vesper Marine Limited harmless. communication réussie. Intended Use MMSI Programming Warning This product is intended to be used on leisure or commercial vessels (excluding IMO/SOLAS class). Vesper IMPORTANT: In most countries the operation of an AIS unit is included under the vessel’s marine VHF license Marine has designed and manufactured this product to be used only aboard vessels. provisions and the vessel on which this device is to be installed may be required to possess a current VHF radiotelephone license which lists the AIS system and the vessel Call Sign and MMSI number. Warranty Void An MMSI number is required in order for this device to operate as a transmitter. Do not disassemble the unit or remove the screws which hold it together. The unit is sealed and disassembly will Please contact the relevant authority in your country for more information.

  • Page 9: Warranty

    This warranty does not cover failures due to abuse, misuse, accident, improper installation, unauthorised alterations or repairs, shipping damage, wear and tear, or corrosion. This warranty will not apply if the product’s external housing has been opened, the serial number or other labels have been removed or altered, the specified input voltage has been exceeded, or the external alarm maximum switched current has been exceeded. This warranty is void if the product has been operated with an incompatible GPS antenna or without a suitable VHF antenna. This warranty is in addition to all other rights available to the consumer under any applicable statute and your statutory rights are not affected by this warranty. Vesper Marine retains the exclusive right to repair or replace the unit or offer a full refund of the purchase price at its sole discretion. In addition, Vesper Marine retains the exclusive right to replace the unit with a factory reconditioned unit or a new unit at its sole discretion. Where a replacement is provided the original product becomes the property of Vesper Marine and the warranty will remain from the original purchase date. This warranty applies only to products supplied new to you by a stockist or Vesper Marine and you have not bought the product for resale. In no event shall Vesper Marine be liable for any incidental, special, indirect, or consequential damages, whether resulting from the use, misuse or inability to use the product or from defects in the product. Vesper Marine declares that this product is in compliance with the essential requirements and other provisions of the R&TTE directive 1995/5/EC. This product is for use worldwide, including the following European countries: This device is also approved for use in the United States, Canada, Australia and New Zealand. Electronic Waste Recycling Various regional and national regulations exist regarding the recycling of certain electronics. Please consult your local authorities or contact Vesper Marine for recycling information. Phone +64 9 950 4848 | Email info@vespermarine.com Fax +64 9 950 4085 | Web www.vespermarine.com Follow us on Facebook | www.facebook.com/vespermarine Copyright © 2012, Vesper Marine Ltd. Member of: AIS WatchMate, WatchMate Vision and WatchMate Wheel are trademarks of Vesper Marine Ltd. All other products are trademarks or registered trademarks of their respective owners. Unless otherwise indicated, all documentation and operating software contained within this product or distributed with this product is copyrighted by Vesper Marine Ltd. All rights are reserved. Portions of this product may use software licensed under open source license agreements. Source code for the applicable software is available upon request from Vesper Marine Ltd...
