GETTING TO KNOW YOUR PRODUCT
6
Components supplied. Please use this guide if you require replacement parts.
Ref
Dimensions
1
140X230cm
2
101X5cm
3
148X80cm
NEW PEACH DAYBED
Assembly instructions
Qty
Visual
Ctn
2
2
1
1
2
2
Ref
Dimensions
4
111x79cm
5
5.5X2cm
6
50x30cm
Qty
Visual
Ctn
2
2
2
1
2
2
1
2
3
4
5
1
