Saflok GARDLOK ES300 Instruction Manual

HEIGHTS KEY LOCK & SAFE
Contact us for more information
GARDLOK ES300
The GardLok is an electronic push button lock designed to
retrofit existing Adams Rite locks installed on narrow stile
aluminum frame doors. Ten different access
combinations can be programmed for lock access. User's
access can be easily change or blocked.

Low Battery Warning

THERE IS NO "POWER OVER-RIDE" OR "KEY OVER-RIDE" FOR THIS LOCK. IT IS VERY
IMPORTANT TO KNOW THE LOW BATTERY WARNING SIGNS!

Stage 1 - Codes will need to be entered twice to trigger lock followed by eight
(8) rapid beeps. This will only occur for 20 openings.

Final Stage - Codes will need to be entered three (3) times before the lock will
open. If the battery is not changed the lock will eventually stop working

To enter a New Master Code

The Master Code is always stored in key '1' of the lock. All other nine combinations
are stored in keys 2 to 0.
Press & hold the '0' key until the lock beeps twice
1.
Enter existing Master Code (factory default is 111111) followed by the '1' button -
2.
the lock will beep twice.
Enter a new 6-digit Master - the lock will beep twice.
3.
Re-enter the new Master code to confirm - a long beep will sound indicating a
4.
successful change.
