Summary of Contents for VPI ADS
- Page 1 VPI ADS Manual Setup and Instruction Manual VPI Industries, Inc., 77 Cliffwood Ave. #5D, Cliffwood, NJ 07721 http://www.vpiindustries.com...
- Page 2 33 RPM and after 6 seconds switches to 45 RPM which then lowers the output to the motor to the 90VAC run level. This sequence allows the ADS to quickly start heavier platters to 45 RPM.
- Page 3 There is an LED indicator the glows red when stopped and green when the platter is turning. System power There is an IEC power module on the rear panel to supply AC power to the ADS. The IEC module contains a fuse drawer that holds a 1-amp slow blow fuse protecting the ADS from electrical system malfunctions.
- Page 4 PECIFICATIONS Line Voltage: 115/230 VAC Factory set Line Frequency: 50/60Hz Line Fuse: 1 amp (Slo-Blo) Output voltage: 115/230 VAC Factory set Start Voltage: 120/240 VAC Run Voltage: 90/180 VAC Output Frequency: 50Hz/60Hz Factory Set Output Frequency Range: 60 Hz Center Detent: 60Hz @33 RPM & 81Hz@ 45 RPM 50 Hz Center Detent: 50Hz @33 RPM &...
- Page 5 VPI Industries, Inc. (VPI) warrants the ADS against defects in materials and/or workmanship for one (1) year from the date of purchase by the original retail purchaser. VPI's sole obligation under this warranty is limited to the repair or replacement, at VPI's option, of any part(s) found to be defective.
