PROLOGUE
These operating instructions must be read carefully in order to familiarize yourself with your Electric Bicycle quickly.
Regular care and maintenance of the Electric Bicycle, preserve its value and your safety. For safety reasons, please
also pay attention to the information about modifications, accessories and spare parts. Provide the owner's manual if
you resale the Electric Bicycle. The developer is constantly working on further improvements of all models; please
understand that changes in terms of shape, equipment and technology are possible at any time.
All rights under the copyright law are expressly reserved. Subject to change.
Symbols used provide important information for you.
Be sure to follow these instructions to avoid personal injury and damage to the unit:

Symbols Used

Important notes for your safety are specially marked.
WARNING
Warns of dangers to your health and indicates possible injury risks.
DANGER
Indicates a potential hazard to the device or other objects.
NOTE
Highlights tips and information for you.
1
INFINI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INFINITE 48V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AMEGO INFINITE 48V

  • Page 1: Symbols Used

    PROLOGUE INFINI These operating instructions must be read carefully in order to familiarize yourself with your Electric Bicycle quickly. Regular care and maintenance of the Electric Bicycle, preserve its value and your safety. For safety reasons, please also pay attention to the information about modifications, accessories and spare parts. Provide the owner's manual if you resale the Electric Bicycle.
  • Page 2 INFINITE User Guide...
  • Page 3 INFINI TABLE OF CONTENTS SERVICE MAINTENANCE Right Side View Maintenance and Care Function and operation Cranks Handlebar Fittings Pedals Handlebars Assembly instructions Steering Bearings Pedal Assembly Spokes Seating Position Check Battery Fuse Adjusting the saddle height Adjust the saddle Locking the fork TECHNICAL SPECIFICATIONS Safety instructions Charger Charger Features...
  • Page 4 INFINI SERVICE Right Side View Display Motor Brakes Chain derailleur Seatpost Crankset Pedals Battery Disc Brake What is on your handlebars? Handlebar Left Side 1 Front Shift 2 Grip, left 3 Brake lever front brake...
  • Page 5 INFINI SERVICE Assembly Instructions for Steering Adjustable threaded spindle 1. Install the handlebars as shown and connect them to the top 2. Set the handlebars to the vertical position of the handlebars Screw the screw. And tighten the screws on the right side. Screw for setting the handlebar position 3.
  • Page 6 INFINI SERVICE Pedal Assembly WARNING Do not tighten the pedals by hand, use a suitable wrench. Identify your pedal: Check the letter on the pedal: "L" or "R". The pedal marked "R" is for right. To attach the crank, turn it clockwise. The pedal marked "L"...
  • Page 7 INFINI SERVICE Seat Position o ensure comfortable, fatigue free and safe driving, the saddle and handlebar height must be adjusted to the body si e. he saddle height is correct when the foot is resting on the pedal at the lowest position while the leg is not fully e tended. he tips of the toes must still touch the ground.
  • Page 8 INFINI SERVICE Adjust the seat height A not completely closed quick-release lever can open again. This allows the saddle to move down while driving. 3 max. This can lead to serious falls. The tension required on the quick-release lever is set by the user's palm strength.
  • Page 9 INFINI SERVICE Before using the charger, please read these safety instructions. Keep the charger away from children. To prevent any risk, charge only lithium-ion batteries; other battery types can explode when charged. This can lead to personal injury and/or material damage. The use of accessories or batteries that are not sold or recommended by us, may cause a fire, electrical shock or personal injury.
  • Page 10 INFINI SERVICE Charger functions This charger is suitable for Li-ion batteries. The LED (LED 1) on the charger keeps you constantly up to date on the operating status. You will be informed of the charging status and charging of the battery at a glance. Malfunction Please check: Check whether the socket carries voltage, if necessary, connect it to another socket.
  • Page 11 INFINI SERVICE Protect the battery from hard impacts and moisture. The maximum life of the batteries is achieved when you use them at an ambient temperature between +10C and max. +30C. After heavy use, the batteries heat up. Before starting the charging process, let the battery cool down for approx. 30 minutes. - Keep the battery away from children.
  • Page 12 INFINI SERVICE Handling of battery and charger In order to achieve the longest possible life out of the battery, the following instruction should be observed: - With the battery temperature below +0C and above +60C, the charger will not behave correctly. Therefore, bring the battery to room temperature before charging.
  • Page 13 INFINI SERVICE Charge the Battery NOTE he battery 1 can be charged either at the i e or e ternally. he battery is secured with a loc nloc and remove the battery. irst connect the mains plug 3 of the charger 4 to the mains supply of 1 Connect the charger of the charger 4 to the battery NOTE...
  • Page 14 INFINI SERVICE The battery is secured in the frame with a lock. Before start riding, check that the battery is correctly locked in the frame and remove the key. We recommend wearing a bicycle helmet when riding! A fall with serious injuries could happen if the following points are not observed: 1 Before you ride, check the handlebar alignment.
  • Page 15 INFINI SERVICE The brakes of the front and rear wheels can be operated independently of each other. When stopping or slowing down at the same time. The e-bike is equipped with a mechanical or hydraulic disc brake system. In tight corners, on sandy and greasy streets, wet asphalt and ice, the front wheel brake should be used gradually so the front wheel does not slip.
  • Page 16 INFINI SERVICE Display Overview Speed display P display otor current oltage attery Capacity Indicator HIGH MODE -6 KM/H Walk-Mode -Assist Levels -Error code display -Menu Structure -Distance display...
  • Page 17 INFINI SERVICE Overall View of the Display Main view of the display when the system is switched on The normal view of the display is shown below. By pressing the "M" key, you can navigate through the individual information: Sequence: Total mileage. Riding Time Display. Trip Odometer. Max Speed Indicator. 1.
  • Page 18 INFINI SERVICE Adjustment in KM/H (kilometers per hour) or MPH (miles per hour). Backlight Press the "+" button (approx. 2 sec.) to switch ON the backlight. 6. Walk-Mode By pressing the "-" button (approx. 3 sec.) you can activate Walk-Mode. The top speed for this mode is 6km/h To turn-off Walk-Mode, hold the brake lever.
  • Page 19 INFINI SERVICE does not assist. The motor only assists to the specified speed in steps 1-6. All speeds beyond that, are generated by your own muscle power. 8. Error Code The wrench symbol appears flashing, followed by a number. Error Codes Definitions Error Code Definition No mistake...
  • Page 20 INFINI SERVICE 9. Submenu By simultaneously pressing the "+" and "-" buttons (approx. 7 seconds), you will be taken to the PIN code request to access the submenu. The PIN code is 8007. Each single digit is set with the "+" or "-" key. The respective digit is confirmed with the "M"...
  • Page 21 INFINI SERVICE 10. Display Information When the display is switched on,the indicators are displayed by pressing the "M" key several times. 10.1 Total Kilometers The total kilometers are shown in the main display. These can not be reset. 10.2 Daily Kilometers It is possible to reset the trip distance by pressing the "+"...
  • Page 22 C7 Display Instructions 1. Overview 3.5 PAS step selection 3.6 Error code display 3.7 SET Setting options 3.2 Support level / start-up assistance 3.3 Speed display km / h and mp / h 3.4 Backlighting 3.1Controller Voltage Display 3.10 Effort display 3.10.1 Total mileage indicator (ODO) 3.10.2 TRIP1 3.10.3 TRIP2...
  • Page 23 ull i ain i When the display is switched on, the following values are displayed as standard: vehicle speed, TRIP2, PAS level, energy content of the battery, and voltage of the battery. Press the button to scroll through the various display modes.
  • Page 24 2. Turning the power on and off r ss t utton on t control unit to acti at t isplay isplay controls t r supply to t controll r o turn t isplay pr ss t utton or s con s o po r is consu isplay is s itc...
  • Page 25 3.2. ATTENTION! Selection of support level & start-up assistance and C The drive settings: T supported in the display because the system is already perfectly balanced to ensure optimum overall driving performance. In the main view, you can press the button appro .
  • Page 26 3.4. Backlight When the display is on, press the button to turn the bac light on or off. 3.5. PAS step selection Press or D to change the PAS level to change the support level. The default setting is . ou can select between support modes.
  • Page 27 3.6. Error Code Display In case of problems with the electronics the display flashes at displays an error code automatically on the display. The meaning of the error codes can be found in the table below. The display shows the error code until the error has been corrected. If the error code is displayed, the e bi e can only be moved without support.
  • Page 28 3.7. Settings y pressing the buttons at the same time appro . seconds , you enter the PI code uery, to enter the submenu. he PI code is ach individual digit is set with the ith the button, the respective digit is confirmed and the ne t digit is selected automatically.
  • Page 29 . . .: m h and mp h Select between m h and mp h to display the speed..: riving mode selection The drive settings: and C supported in the display because the system is already perfectly balanced to ensure optimum overall driving performance.
  • Page 30 . . . Remaining battery power The battery power indicator consists of five segments. Each segment corresponds to 2 of the battery energy. When the battery is fully charged, all five segments are displayed. It is recommended to charge the battery with two bars to ensure continuous support. If the battery is too light, the battery indicator will start to flash and the battery should charge immediately.
  • Page 31 .2. TRIP The TRIP display is suitable to record several stages of a trip. It is added from the individual TRIP2 values. or a distance over m, the TRIP display will automatically reset. . . TRIP 2 The TRIP2 display shows the last distance for seconds after switching on the display.
  • Page 32 ! 11...

  • Page 33: Safety Instructions

    INFINI Safety Instructions Traffic Safety An e-bike must be equipped with two independently operable brakes, a clearly audible bell, front & rear lights,as well as reflectors. The e-bike is only suitable for driving on paved roads and paths. Do not drive off the beaten track or in the field. Do not use the e-bike for water crossings, for off-road events or during sporting events.
  • Page 34 INFINI Before you get on the bike, make sure the motor is OFF. Only switch the engine ON after you start pedaling! Always follow the traffic rules. Never ride off track. Do not drive in the blind spot of other road users. Indicate in time where you want to turn.
  • Page 35 INFINI Remove front wheel for transport - Open the quick release lever (1) and release the axle nut (2) with a few turns. - Remove the front wheel (3) from the fork downwards. WARNING A not completely closed quick release lever can open again. This can lead to serious injuries. The flip of the quick- release lever must be tight enough for you can manipulate it, without any tools.
  • Page 36 INFINI Electric Bicycle care / care products NOTE Regular and expert care is essential for the preservation of the bicycle and is one of the prerequisites for the recognition of warranty claims. Corrosion caused by lack of care or by winter operation is not covered by the warranty. DANGER Rubber and plastic parts must not be contaminated by aggressive or penetrating cleaning agents or solvents to be damaged.
  • Page 37 INFINI In the interests of environmental protection, we recommend using care products that are labeled as environmentally friendly. If the bicycle is used during the winter months, damage caused by grit and salts can occur. DANGER Do not use warm water - increased salt action. At the end of the ride, clean the bike immediately with cold water.
  • Page 38 DANGER In your own interest, we recommend using only expressly approved accessories and genuine spare parts for AMEGO electric bicycles. For these accessories and these parts, safety, suitability and reliability have been specially tested for the Electric Bicycle. For other accessories and parts, we can not, nor will we be liable, in spite of ongoing market observation, even if in a particular case an inspection by an officially recognized Technical Inspection and Monitoring Association or an official approval should exist.
  • Page 39 INFINI Improper work on safety-related parts puts you at risk and other users. This applies, in particular, to work on: steering, braking and lighting. Carry out maintenance work during the warranty period and without exception through a specialist dealer. Only use original spare parts.
  • Page 40 INFINITE The cranks (1) can relax over time when driving. Check regularly if the cranks are tight. If you move the cranks vigorously sideways, there is no play to be spared. Also, the bottom bracket (2) axle should have no play and the cranks may need to be easily rotatable, then the bearing is in proper condition.
  • Page 41 INFINI A tight fit of the spokes (1) is important for the smooth running of the wheels. Spokes lose tightness in time. Broken spokes must be replaced immediately and the wheel completely trued. The replacement, tension or lessening of spokes is up to the dealer. Check battery fuse DANGER Never use a stronger fuse or fuse mending.
  • Page 42 INFINI COMPONENTS INFINITE 48V (27.5¨) Motor -Das-Kit, R2, 48V 250W Rear Motor Battery Pack I5-4813H, 36V 13AH 624WH, Li-Ion Cells Display Das-Kit, L7B Suntour, NEX 700C Fork Brake Lever Artek, with Cut-Off Sensor Brakes Front / Rear: mechanical Tektro disc brakes...

  • Page 43: List Of Wear Parts

    WARRANTY INFINI List of Wear Parts After 500 km and every wash.

  • Page 44: Warranty Terms

    INFINI WARRANTY Warranty Terms 2 years on the frame (e-bikes) 12 months on all electronic components including battery The period for the calculation of the warranty period begins with the date of the invoice. If material or manufacturing defects occur during this period, we provide as guarantor under the warranty one of the following services at our discretion: Free repair of the goods (repair time 1-4 weeks from receipt of goods) or free Exchange of the goods in whole or in part against an equivalent Article (possibly also a successor model, if the original product is no longer available).
