Sony CECHYA-0090 Quick Start Manual

Quick Start Guide Let's get started
IMPORTANT: Before using this product, read the safety precautions in the
Safety and Support Guide.
You can also use your headset with a PC, Mac or portable media player.
For details, visit: us.playstation.com/support/wirelessstereoheadset.
1. Turn on your PS4™ system
Press the power button.
2. Charge your headset
Platinum Wireless Headset
For more information, visit playstation.com/helpme. The example shown is not representative of an actual screen.
With your PS4™ system on*, connect your headset using
"2", "PlayStation" and "DUALSHOCK" are registered trademarks or trademarks of Sony Interactive
the supplied USB cable. Your headset might need up to
Entertainment Inc. "Sony Entertainment Network" is a registered trademark of Sony Corporation. Windows is
either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.
3.5 hours to charge fully.
Mac is a trademark of Apple Inc., registered in the U.S. and other countries.
*You can also charge your headset when your PS4™ system is in rest mode.
3. Insert the wireless adaptor
5. Download and install the Headset Companion
app from PlayStation
6. Open the Headset Companion app and update
your headset.
Use one of the USB ports on your PS4™ system.
Select one of the preset modes, which have been specially
4. Turn on your headset
designed to deliver an optimal audio experience. You can
also create your own audio mode.
Enhanced 7.1 Virtual Surround Sound:
Experience rich, highly positional virtual surround sound
powered by a new 3D audio technology from Playstation
3D Audio:
In supported games for the PS4™ system, 3D audio delivers
an amazingly rich audio experience via object-based
surround sound emanating from all directions, including
above and below you, across 100 virtual speakers.
Slide the power/audio mode switch to position "1" or "2".
1. Press and hold the PS button on your
DUALSHOCK ® 4 wireless controller.
2. Select [Sound/Devices] > [Output to Headphones].
3. Select [All Audio].
* Sony Entertainment Network account and Internet service required.
Headset anatomy
Rear
SOUND/CHAT buttons
Adjust the chat voice
Store*.
®
volume in relation
to the game sound.
Status indicator
Power/audio mode switch
Sets the audio mode or turns off the headset.
OFF - turns off the headset
® .
1 - standard mode
2 - bass boost mode
Both audio modes are customizable and
can be replaced with other modes from
the Headset Companion app.
VSS/3D AUDIO switch
VSS/3D AUDIO switch controls the
Bottom
audio format output desired by
the player.
OFF - standard stereo output
ON - enhanced 7.1 virtual surround
sound (VSS) for stereo/5.1/7.1 content or
3D audio for 3D audio content
USB port
Connect a micro-USB cable to your
VOLUME + / – buttons
PS4™ system or another compatible
USB device to charge your headset.
MUTE button / Sidetone
Microphone (integrated)
The MUTE button controls the microphone and the
sidetone feature. Sidetone allows you to hear your
Audio input jack
own voice from the headset.
Use the supplied audio cable to connect
When MUTE is on, the sidetone feature is turned off.
your headset to mobile devices.
• Short press to mute or unmute the microphone.
• Long press to choose the sidetone volume (low, high, off).
One beep - low volume
Two short beeps - high volume
For more instructions about the use of this product
One low beep - sidetone off
(including the Headset Companion app), visit
us.playstation.com/support/wirelessstereoheadset.
