Elabs HM1CK-3 Instruction Manual

Pin Out for the IR:

EMITTER(Blaster )
1. Signal Output
2. + 5.6V
3. GND
Warning : Using a mono connector will damage the UNIT.
CE labs can support many areas of your audio and video distribution needs.
We manufacture:
• Digital Signage software and Media Players
• HD Matrix Switchers
• RF amplifiers
• HDMI and Component HD distribution amplifiers
• CAT 5 Signal Extenders
• VGA Extenders and Splitters
• and cables of all types.
See our full product line at www.celabs.net
WARRANTY
Cable Electronics, Inc. warrants this product to be free from defects in material
and workmanship, under normal use and service, for a period of one year from
the purchase by the original purchaser. If this product is defective or
malfunctions, Cable Electronics Inc. will replace or repair this unit (at their
option) within a reasonable time. No expressed or implied warranty is made
for any defects caused by immersion or exposure to liquids, abuse, neglect,
improper operation of unit, excess wear and tear, act of nature, including, but
not limted to, fire, flood or lightning, and defects resulting from unauthorized
disassembly and or modification.
3209 Wood Drive
Garland, TX 75041
Phone: (469) 429-9200
Toll free: (800) 767-6189
Fax: (469) 429-9205
www.celabs.net
RECEIVER
1. Signal Input
2. + 5.6V
3. GND
Document: HM1CK-3_manual.pdf
930-5065-01_ Rev.B00
H M 1CK-3
™
HDMI UTP
Extender Series

Key Features:

• Uses only one CAT5e/6/6a/7 cable
• HDMI™ 1.3 and HDCP compliant
• 3D ready
• Extend signal up to 328ft(CAT5e and CAT6a/7) at
1080p/60Hz/48 bit
• Bi-Directional control signal RS-232 allowing status request and
control of the destination unit
• Bi-Directional IR control signal (30 - 60 KHz maximum)
• Uncompressed high definition video up to 1080p/60Hz/48bits
• Maximum data rate 3.4 Gbps
• Audio transmission supports Dolby TrueHD, DTS-HD MA
• No adjustment required
• 4K x 2K Supported
