USER MANUAL
Safety Information.......................................................................................................... 3
Specifications.................................................................................................................... 4
Main Power Connection...............................................................................................5
DMX-512 Connection................................................................................................... 5
Fixture Label........................................................................................................................ 6
Set Up.....................................................................................................................................6
Operation Options...........................................................................................................7
Connection..........................................................................................................................8
Rigging the Fixture..........................................................................................................9
Cleaning & Maintenance................................................................................................9
Parts List...............................................................................................................................9
Advertisement
Table of Contents
Summary of Contents for Mega Lite Mega Air DMX
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information……………………………………………………………………………………………. 3 Specifications…………………………………………………………………………………………………….. 4 Main Power Connection…………………………………………………………………………………..5 DMX-512 Connection…………………………………………………………………...……………..5 Fixture Label…………......................6 Set Up.............................6 Operation Options……………………………………………………………………………………………..7 Connection…………………………………………………………………………………………………………..8 Rigging the Fixture…………………………………………………………………………………………….9 Cleaning & Maintenance....................9 Parts List..........................9... -
Page 3: Table Of Contents Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5. -
Page 4: Specifications
Technical Information Part Numbers 9505– Mega Air DMX Transmitter 9506– Mega Air DMX Receiver Electronic Specifications 4.85” 4.10” Radio Frequency Used: 2.40-252G Automatic Select 126 Channels using frequency Hopping technology—AFHSS Frequency Agile: Adaptive 4.35” Universes: Up to 16 selectable Broadcast Power:... -
Page 5: Main Power Connection
At the last fixture the DMX signal needs to be terminated with a terminator. Solder a 120 Ohm resistor between the (-) and the (+) signal into a 3 pin XLR plug and plug it in to the last fixture on the signal run. Pre-manufactured terminator plugs are available for purchase from your Mega-Lite dealer (HOS-DMXT). -
Page 6: Fixture Label
Fixture Transmitter Power Link Power In Antenna Function Button DMX In Receiver Power Link Power In Antenna Function Button DMX Out Set Up For optimum signal transmission the following conditions should be fulfilled. Distance between Transmitter and Receiver should not exceed 650 feet 650 feet max Position on the transmitter should be in clear sight of the receiver with a minimum of 3 feet above any person. -
Page 7: Operation Options
Operation Options Point to point Transmitter Receiver Point to multipoint Receiver Transmitter Receiver Multipoint to multipoint Receiver Transmitter Receiver Transmitter Receiver... -
Page 8: Connection
Connection Point to Point Connection Connect the Transmitter to power, the connection button should be flashing green. Connect DMX signal into the Transmitter, the connection button should be green. Connect the Receiver to power, the connection indicator should be off ( if the receiver connection light is not off you need to unlink your receiver) Press and quickly release the Function button on the Transmitter. -
Page 9: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. 3. Unit is to be 24inches away from flammable materials (decoration material) 4. - Page 10 Warranty is void if the product is misused, damaged, modified in any way, or for unauthorized repairs or parts. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Mega-Lite 5718 Kenwick St San Antonio, TX 78238 Ph 210-684-2600 Fax 210-855-6279 www.mega-lite.com / info@mega-lite.com...
