Summary of Contents for Rossofuoco RUBINO
- Page 1 OUTDOOR WOOD PELLET PATIO HEATERS user and maintenance manual Rev. no. 02 - 25/03/2018...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Warnings and Manual Keeping pag. 01 Safety pag. 02 Design Description pag. 04 Positioning and Transport pag, 04 Assembly and Installation pag. 05 Functioning of the Heater pag. 08 Initial Operation pag. 08 How to load, fire up, unload and reload the Heater pag. - Page 5 WARNINGS This manual provides information on transport, installation, correct use and maintenance of the pyrolytic heater. It is aimed at persons involved in the installation, use and maintenance of the equipment. Before carrying out any operation, please read carefully these instructions. In case of doubts about the correct interpretation of these instructions, contact the manufacturer or the reseller to obtain the clarifications needed.
-
Page 6: Safety
12. the heater must be steadily controlled by the user during its normal operation; 13. the metallic sheating of the glass tube of the model RUBINO as well as the door of the internal brazier of both models must be always closed during the use of the heater, so that the key of the door has to be pulled out. - Page 7 26. do not fill the brazier with quantities of pellets lower or higher than those indicated; 27. do not open the door of the metallic sheating of the model RUBINO during the use of the heater; 28. do not move around the heater during the combustion process;...
-
Page 8: Design Description
On the base there are four tempered glass that surround the flame. All materials of RUBINO and DIAMANTE that get in contact with weather effects were treated with additional protections in order to avoid corrosion and to extent the durability.Finally, both the heaters are fitted with an internal collecting drawer underlying the brazier. -
Page 9: Assembly And Installation
ASSEMBLY AND INSTALLATION For the assembly of the model RUBINO, please attend the following instructions Remove the packaging and detach the base element, the metallic sheating and - in particular carefully - the glass tube. Splice the metallic sheating with the base element using the 4 screws supplied. - Page 10 Afterwards, splice the stainless steel element and the roof using the 8 screws supplied. Introduce carefully the glass tube in the metallic sheating, holding it skewed. It first has to be introduced in the aperture of the abordering above and then has to be deposited on the base element.
- Page 11 For the assembly of the model DIAMANTE please attend the following instructions Remove the packaging and detach the base element, the four tempered glasses and the pack with the 8 metal supports to be used for housing the glasses. Insert the eight metal supports in the holes tha are at the top of the heater fixing them the screws given Insert each of the four tempered glasses in the holders, tightening the locking screws.
-
Page 12: Functioning Of The Heater
It will be necessary to wait for 10 minutes before that the flame starts to come out from the glass tube (mod. RUBINO) or inside the area surrounded by the glasses (DIAMANTE). Do not open the door of the base element during the combustion. -
Page 13: How To Load, Fire Up, Unload And Reload The Heater
Reinsert the burner inside the base of the Heater and lock the door. Put the key in a safe place; It will be necessary to wait for 10 minutes before that the flame starts to come out from the glass tube (mod. RUBINO) or inside the area surrounded by the glasses (DIAMANTE). page 09... - Page 14 Throughout the combustion do not open the door of the base. It is recommended to make the heater works for the entire duration of the pellet combustion. The suggested pellet quantity is roughly calculated because the Heater filled with a few quantity of pellet produces an higher flame because there is more air inside the burner, but the duration will be shorter.
-
Page 15: Cleaning And Maintenance
Every 2/3 usage of the Heater, it is recommended a lubrication of the burner’ sliding guides, to avoid the malfunction of the system. Glass tube cleaning (mod. RUBINO): it makes sure that there isn’t flame and the Heater is cold and off;... - Page 16 TROUBLE TROUBLE POSSIBLE CAUSE SOLUTION Check that the used ecological igniter has not been switched off, if it is so to add Pyrolysis has not started more of it so that its quantity is adequate correctly and turn it on again making sure that its combustion is well started before closing everything.
-
Page 17: Technical Data
Manufacturer’s Brand Rossofuoco Model Pyrolitic heater DIMENSIONS AND WEIGHT OF THE PYROLITICAL HEATERS Length x Width x Height and Weight Pyrolitic outdoor heater RUBINO 500x500x1900 mm; 55 kg Pyrolitic outdoor heater DIAMANTE 500x500x900 mm; 35 kg CLIMATIC CONDITIONS OF USE Temperature: 0 –... -
Page 18: Declaration Of Conformity And Applicable Legislation
Via Cavalieri di V. Veneto, 21 – 61045 PERGOLA (PU) - ITALY declares under its own responsibility that the products PYROLITIC OUTDOOR HEATERS “RUBINO” AND “DIAMANTE” are pellet driven and therefore are not covered by the following supranational statutory provisions: •... - Page 19 WARRANTY CARD (part to be lled in and stored by the customer) Model Serial number Date of purchase Stamp and signature of the dealer Attention! The other underlying part of the warranty coupon must be lled in and sent as an ordinary letter to the manufacturer at the address on the back.
-
Page 20: Warranty Card
Send this part of the coupon in a sealed envelope, as an ordinary letter to the manufacturer, to the following address ROSSOFUOCO srl - VIA CAVALIERI DI V. VENETO, 21 - 61045 PERGOLA (PU) - ITALY... - Page 21 page 17...
- Page 22 page 18...
- Page 24 Production and distribution by: ROSSOFUOCO srl unipersonale Via Cavalieri di V. Veneto, 21 61045 Pergola (PU) - ITALY P.Iva: 02443170416 tel. +39 0721 735926 - fax +39 0721 737107 mail: info@rossofuoco.com www.rossofuoco.com...
