Curtis MP2029UK User Manual

MP2029UK
User Manual
2. Unique Features
1. Elegant appearance with LED indicator and card slot.
2. Multi-Code Player - Supporting MP1, MP2, MP3, WMA formats.
3. Drive Free U Disk - You may manage your files directly through "Portable
Device" in "My Computer" on Windows 2000 Operating System or above
without driver.
4. Function of LED Indicator Light
1. In Power OFF Mode: No Light.
2. In Music Playing Mode: Light flashing (about once per second).
3. In Music Pause Mode: Light bright.
4. In PC Connection / Charging Mode: Light bright.
5. Charging Complete: Light Off
6. USB Disk
1. USB Disk
The player could be use as standard USB disk with operating system of
Windows 2000 and above, Mac OS 10.3 and above, Linux Redhat 8.0
and above (no driver needed) while Windows 98 need to set up driver.
2. Charging
2.1 Make sure the power switch is on to charge, or the player could not
be charged properly. The LED light is on when the player is charging, the
light will be off when the battery is full.
2.2 Disconnect the player and charger if you want to stop charging.
2.3 Turn off the player when you do not use player.
3. Remarks (Additional information for Adaptor purchase)
3.1 The adaptor must be conformed to following standard
3.1.1 Input: 100V ~ 240V, 50/60Hz
3.1.2 Output: 5.2V ± 0.2V
3.1.3 Max.: 350mA
3.1.4 4 pins adaptor
8. Trouble Shooting
-
No Power
-
-
-
No Sound from earphone
-
-
Failure of music download
-
-
Shorted and Touch
GND
Empty
Check to see if battery is low
Check to see if the player is ON
Check to see Volume is set "0" and connect the
earphone connects properly.
Make sure earphone is clean and in good status
Damaged MP3 file may make noise and could not
be played. Make sure that the music file are not
damaged.
Check to see if USB cable is damaged and
connected properly.
Check to see if driver is installed correctly.
Check to see if memory space is enough
1. Overview
EARPHONE
JACK / RESET
3. Play Music
Connect the earphone to player
1. Press and hold
1.1 Select music
: To select previous music
: To select next music
2. To adjust the volume
2.1 Press
3. To change normal / shuffle play
3.1 Press and hold "V+ /S" button for 2-3 seconds to enter "Random"
play mode and the LED light will flashing slow about once per 2 seconds.
3.2 Press and hold "V+ /S" button for 2-3 seconds again to return to
"Normal" play mode and the LED light will flashing about once per 1
seconds.
5. External Memory Card
1. Turn OFF the player and then insert memory card into card slot; make
sure memory card is firmly and correctly inserted.
2. Turn ON the player by press
searching the supported music files from memory card / internal memory,
and found music will play automatically.
3. Before taking out / inserting the memory card with player. Please turn
OFF the player.
7. File Transfer
1. Connect player to PC by USB cable.
2. The device will be detected automatically.
Choose take no action and close the window.
3. Double click My Computer to choose
Removable Disk icon.
4. Drag your media files into the removable disk.
5. Close the removable disk window and
disconnect the player from PC after data transfer.
9. Technical Specifications
Capacity
Output DC 5V
Display
Interface
Max Playtime
Battery Type & Capacity
File Type
S/N Ratio
Power Output
Operating System
Dimensions
Weight
SPEAKER
LED INDICATOR
VOLUME + / SHUFFLE
POWER ON/OFF
V /S
OR
PLAY / PAUSE
FORWARD
V
VOLUME -
BACKWARD
button for 2-3 seconds to switch ON
/ to adjust volume
V /S V
button, the player is reading and
2GB
NA
USB 2.0 High Speed
Up to 4hrs
Li-Polymer Rechargeable (3.7V) 230mAh
MP1, MP2, MP3, WMA
85 ~ 95 db
(L) 5mW + (R) 5mW (32Ohm)
Compatible with Windows 2000 / XP
35 x 90 x 13.8 mm
40g
MICRO SD
CARD SLOT
USB PORT
