Advent GMNAV2 Quick Start Manual

System Selection
We Hope you Enjoy the added features of the
Advent Next Generation Integrated
Switching between the OEM system and the inteface can easily be
Navigation System.
done several ways.
1: Press Next on the Screen to scroll through the Menu Options
For your safety, please do not operate the
pages.
system while driving.
2: You can select the Navigation / Media interface by pressing the
source button on the radio for 2 seconds at any time (see below).
This Quick Start Guide describes the features, uses, settings etc. of
the Navigation System, see the vehicle owners manual for the car
audio system. A complete Navigation manual can be downloaded at
www.adventproducts.com.
Advent Customer Service: 800-645-4994
Advent Technical Support: 800-323-4815
Website: Manuals, Specifications, Information:
WWW.ADVENTPRODUCTS.COM
Map Updates, Map Add-on's, Technical support:
WWW.NAVIEXTRAS.COM
Due to continuous improvement, design and specifications may
change without notice.
OBD Information
The OBD information page displays Information from the vehicles
"On-Board Diagnostic" system.
This page provides selected data from that system that you
may or may not see in other menus depending upon your vehicles
options. This data selection cannot be changed . This information is
only for reference.
This Page Intentionally Left Blank
Interface Home Page Navigation
The Main menu page of the interface contains the Touch the Navigation Icon to enter the IGO map. Please refer to the
choices for Navigation, HDMI, Aux in, and ODB vehicle
IGO map quick start guides for user instructions.
information and System Settings.
System Settings System Settings
While in the Interface menu the "System Settings" page allows you to System settings continued:
make changes In the Interface only. For Entertainment system or
System Language: System Info:
System Update:
vehicle settings use the Settings Selection in the main Radio Menu Select the Provides Licensing
Only used when a
Language of your and software
Interface System
page.Instructions for those settings are covered in your factory choice for the version #'s.
Update is issued.
interface Menu
vehicle Owner's manual.
System Reset:
pages. Navigation
Reset's the
Language may be
system to
Rear Camera Settings: selected in the
factory default
Navigation
GPS Voice : GPS Vol. Level : If no camera is installed this will
settings.
Application.
cancel the switching to the Camera
Selects On/Off for Selects the main
input. Select OFF if no camera is
Navigation Voice system Volume for
installed.
Prompts NOTE: GPS prompts.
Navigation Volume is
Temp: Rear Camera Option:
also controlled in the
Selects Aftermarket or OEM
Navigation Mapping Selects Temp
Camera Input.
display in F or C.
Application.
Navigation Path Navigation Path Selection
The Navigation Path page is used only for maintenance when an
This screen will allow you to select the correct file to run the
update is done. Use caution: Changing settings here could cause navigation application. The System is preset from the factory
and this should not be changed unless you are instructed to
your Navigation to stop operating. If this screen appears when
do so by Tech Support personnel. Selecting the wrong file
starting the navigation application, make sure that Automatically Run could stop your Navigation unit from operating correctly.
GPS is checked, and then press RUN GPS. This can take up to 1
min. for the Navigation software to re-load. If your GPS does not start
correctly contact customer service for support.
Browse:
Browse will allow you to see the files and
Autorun Navigation software:
contents of the Navigation Memory folder.
Select To start Navigation without
seeing this menu each time.
System Settings AUX
System settings continued: AUX input allows the use of any media player with an audio
output.Connect your media player using the appropriate cable and
Fuel Unit: Time Format: select AUX to listen to the audio. Control of the media player is not
Changes the Selects 12 or 24 hour possible through the interface.
OBD Data
clock display in the
display from
Interface system.
Gallons to Liters
Speedometer
Display:
Changes the OBD USB Connection
Data display from
Miles to Kilometer's
NOTE: The USB connection added for your interface will provide
charging for a connected device. The USB is NOT used for AUX in
or Media playing. The USB Connection is also used for the
updating of maps covered in the Navigation QSG.
The interface will not play Media, Video, or pictures from any type
of USB stick or other USB connected device.
HDMI
The HDMI input will allow you to view your compatible* smart phone's screen
or any other device with a HDMI output on your Entertainment Systems
screen while the vehicle is NOT moving. This input does not offer control of
the connected device, only the image and audio are accessible.FMVSS and
Local laws do not allow the viewing of video by a driver or in a position the
driver may view while the vehicle is moving. The system will automatically
black out the screen once the vehicle starts moving but audio will still be
heard.
NOTE: You're Phone or other device
may require a special adapter to view
Video:
HDMI. Contact your Phone dealer for
information regarding these parts, If your Once your device is
device can be viewed on a TV with connected touch the video
HDMI input then it will be viewable on
button to start viewing.
your Media system.
GMNAV2
Interface System
Quick Start Guide
