AMPD ST350 Operation Manual

NON_CONTACT INFRATED THERMONETER
OPERATION MANUAL

FEATURES:

Non-contact accurate temperature measuring
Built-in Laser aiming
℃ ℉
/ optional
White backlight liquid crystal display
Auto-data hold and auto-power off 15second after release the testing switch
Distance spot ratio: 10:1
Range: -25℃~400℃(-13~752℉)
Resolution: 1℃
Accuracy: 2%±2℃
Emissivity : preset at 0.95
Sample rate: about 0.5 seconds
Spectrum reaction: 8~14um
Power: one 9V battery

Operating Instructions:

1. Open cover of battery, install 9V battery, and select the switch of aiming laser and ℃/℉
switch at a proper place as your needs, and then close the cover of battery.
2. Point the aiming sensor at an object (Be sure to consider distance-to-spot ration and field of
view), and push the testing switch , and the temperature reading will appear on the display. When
the testing switch is released, the LCD will auto-store the last temperature reading and turn off in
about 15 seconds.
3. Pressing the Scan Trigger again will restart the testing process.
4. Please replace a new battery when battery symbol displayed on left of LCD.
Remind: Do not point the laser directly at the eyes of any people or animal.
