  • Page 1 Distributed by: User's Manual TABLET PC...

  • Page 2: Table Of Contents

    Content Copyright Notice ........................1-3 Trademarks ..........................1-3 Revision History ........................1-3 FCC-B Radio Frequency Interference Statement ..............1-4 FCC Conditions ........................1-4 FCC ............................1-4 CE Conformity ..........................1-5 WEEE Statement ........................1-5 Safety Instructions ........................1-6 Introductions ................2-1 Unpacking..........................2-2 Product Overview ........................2-3 Open View ..........................2-3 Top Side View ........................2-5 Right Side View ........................2-6 Left Side View ........................2-7 Bottom Side View .......................2-9...

  • Page 3: Copyright Notice

    User's Manual Copyright Notice The material in this document is the intellectual property of Micro-Star International Co., Ltd. We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents. Our products are under continual improvement and we reserve the right to make changes without notice.

  • Page 4: Fcc-B Radio Frequency Interference Statement

    FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and radiates radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 5: Ce Conformity

    User's Manual CE Conformity This device is in compliance with the essential safety requirements and other relevant provisions set out in the European Directive. Battery Regulations European Union: Batteries, battery packs, and accumulators should not be disposed of as unsorted household waste. Please use the public collection system to return, recycle, or treat them in compliance with the local regulations.

  • Page 6: Safety Instructions

    Safety Instructions Read the safety instructions carefully and thoroughly. All cautions and warnings on the equipment or user’s manual should be noted. Keep this equipment away from humidity and high temperature. Lay this equipment on a stable surface before setting it up. The openings on the enclosure are used for air convection and to prevent the equipment from overheating.
  • Page 7 User's Manual Never pour liquid into the opening that could damage the equipment or cause an electrical shock. If any of the following situations arises, get the equipment checked by a service personnel: • The power cord or plug is damaged. • Liquid has penetrated into the equipment.

  • Page 9: Introductions

    Introductions User's Manual TABLET PC Part No.G52-17A12X8...

  • Page 10: Unpacking

    Introductions Congratulations on becoming an user of this product, the finely designed Tablet PC. You will have a delightful and professional experience in using this exquisite Tablet PC. We are proud to tell users that this Tablet PC is thoroughly tested and certified by our reputation for unsurpassed dependability and customer satisfaction.

  • Page 11: Product Overview

    User's Manual Product Overview This section provides the description of basic aspects of the Tablet PC. It will help you to know more about the appearance of this tablet before using it. Please be aware that the figures shown here are for reference only. Open View The figure of open view and description shown below will lead you to browse the main operating area of your Tablet PC.
  • Page 12 Introductions Power Button Power Button • Before powering on the Tablet PC for the very first time, you must connect it with AC power. Power • Press and hold the power button for 4 seconds can shut down the Tablet. Rotate Direction Lock • Lock down screen direction.

  • Page 13: Top Side View

    User's Manual Top Side View Smart Card Reader(SCR) (optional) SCR supports ISO7816 type of cards，eg: Chip Card (optional)

  • Page 14: Right Side View

    Introductions Right Side View Smart Card Reader(SCR) (optional) SCR supports ISO7816 type of cards，eg: Chip Card (optional)

  • Page 15: Left Side View

    User's Manual Left Side View Smart Card Reader(SCR) (optional) SCR supports ISO7816 type of cards，eg: Chip Card (optional) USB 3.0 Port The USB 3.0 port allows you to connect USB-interface peripheral devices, such as the mouse, keyboard, modem, portable hard disk module, printer, etc.
  • Page 16 Introductions Headphone Jack Used for connecting the speakers or headphones. SD Card Slot Used for inserting or replacing SD card to increase the storage capacity of the Tablet...

  • Page 17: Bottom Side View

    User's Manual Bottom Side View DC-in Jack It is an electrical connector for supplying direct current (DC) power.

  • Page 18: Rear Side View

    Introductions Rear Side View The figure of open view and description shown below will lead you to browse the main operating area of your Tablet PC. Rear Camera This built-in rear camera can be used for picture taking, video recording or conferencing, and any other interactive applications.

  • Page 19: Specifications

    User's Manual Specifications The specifications listed here is reference only, and may change without notice. The actual products sold are different from areas. Physical Characteristic Dimension 175 (L) x 110 (W) x 100 (H) mm Weight < 805 g ® Processor Type Intel Braswell Refresh Processor...
  • Page 20 Introductions Kingston Lock Hole SD Card Slot Power Jack LAN Port Communication Port Wireless Wifi Supported Bluetooth Supported Display LCD Type 10.1 Resolution 1280 x 800 Multi Touch Supported Brightness Controlled by setting Video Graphics Webcam Front Camera 2.0MP Rear Camera 5.0MP (optional) Audio Internal Speakers...
  • Page 21 User's Manual 2-13...
  • Page 22 Introductions 2-14...

  • Page 23: Getting Started

    Getting Started User's Manual TABLET PC...

  • Page 24: Begin To Use The Tablet Pc

    Getting Started Begin to Use the Tablet PC For a new user of this Tablet PC, we would like to suggest you follow the illustrations below to begin to use the Tablet PC.

  • Page 25: How To Manage Power Supply

    User's Manual How to Manage Power Supply This section provides users basic safety precautions to take when using an AC/DC adapter and battery power properly. AC/DC Adapter Ensure that your notebook is connected to an AC power source via the AC adapter before turning it on for the first time.

  • Page 26: Battery

    Getting Started Battery This Tablet PC is equipped with a built-in high-capacity Lithium-ion Polymer battery pack. The rechargeable Lithium-ion Polymer battery pack is an internal power source of the Tablet. Be aware that this battery pack may be damaged if users try to disassemble the battery pack on their own.

  • Page 27: Power On

    User's Manual Power On Long press the Power Button to power on the Tablet PC.
  • Page 28 Distributed by: Contradata Milano S.r.l. Via Solferino 12, 20900 Monza (MB) - Italy Tel: (+39) 039.230.14.92 - Fax: (+39) 039.230.14.89 E-Mail: info@contradata.it - Web: www.contradata.it...
