Danfoss KP 1 Installation Manual page 2

CAUTION:
Disconnect power supply before wiring connections are made or service to avoid possible electrical shock or damage
to equipment. Do never touch live parts with your fingers or with any tool.
Contact 1-4 opens on pressure drop
Contact 1-2 opens on pressure rise
Manual trip function
Automatic reset
NOTE:
use FINGERS ONLY!
(Do NOT use screwdriver)
2 | 520H11524 | DKRCC.PI.C00.E3.02
KP 1, KP 1A
Cut In
Differential
Cut Out
-1 bar (30 in. Hg)
eff
KP 5, KP 5A
Cut Out
Differential
Cut In
Manual reset
Type Differential
KP 1, KP 1A
0.7 bar (10 psi)
KP 5, KP 5A 3 bar (43 psi)
Setting
Contact load
Max.
Regulation
Min.
AC1:
Alarm
AC3:
(Au surface
is burnt
AC15: 4 A/400 V
away)
DC13: 12 W/220 V
Adjustment
Range
KP 1, KP 1A: 0.7 bar (10 psi)/rev.
KP 5, KP 5A: 2.3 bar (33 psi)/rev.
6 mm
(15/64 in)
© Danfoss | DCS (jmn) | 2016.11
30 mA/30 V DC
1 mA/5 V DC
10 A/400 V
6 A/400 V
Differential
KP 1, KP 1A: 0.2 bar (3 psi)
KP 5, KP 5A: 0.3 bar (4 psi)
