Summary of Contents for Trophy Strike 106475
- Page 1 Ice Auger MODEL # 106475 Operation Manual This safety alert symbol identifies important safety messages in this manual. Failure to follow this important safety information may result in serious injury or death. Part #106611 Rev C...
- Page 2 For Service or Questions Call 1-877-487-8275 720-287-5182 www.trophystrike.com Trophy Strike is a brand of 1100 W 120th Ave, Suite 600 Westminster, CO 80234 • 720-287-5182...
-
Page 3: Table Of Contents
Table of Contents Important Safety Information Intended Use ...................4 Personal Protective Equipment ............4 General Safety ..................5 Safety Decals ..................6 Auger Assembly ..................7 Overview of Components .................8 Operating Precautions................9 Mixing Fuel and Filling the Fuel Tank ...........9 Operation....................10 Maintenance ....................12 Troubleshooting ..................15 Warranty &... -
Page 4: Important Safety Information
Important Safety Information WARNING WARNING: Read and thoroughly understand all instructions and safety information before assembling or operating the Ice Auger. Failure to do so may cause serious injury or death. Do not allow anyone to operate this ice auger who has not read this manual. As with all power equipment, an ice auger can be dangerous if assembled or used improperly. -
Page 5: General Safety
Important Safety Information General Safety Failure to follow warnings, cautions, assembly and operation instructions in the Operation Manual may result in serious injury or death. DANGER READ THE OPERATION MANUAL BEFORE OPERATION. • Do not permit children to operate this equipment at any time. •... -
Page 6: Safety Decals
Make sure all safety CAUTION ! 2-Cycle warning decals are attached and in readable condition. Replace 52cc Ice Auger HOT SURFACE missing or defaced decals. Contact Trophy Strike at 1-877-487-8275 DO NOT TOUCH e Auger for replacement decals. MUFFLER ! 106612 106612... -
Page 7: Auger Assembly
Auger Assembly Attach the auger. Attach the auger to the output shaft on the bottom of the ice auger powerhead, lining up the holes in the auger with the output shaft and securing with 1/2 in. x 2 in. socket cap screw. SOCKET SCREW... -
Page 8: Overview Of Components
Overview of Components FUEL MUFFLER TANK ENGINE ON/ TRIGGER POWER SAFETY TRIGGER SWITCH CONTROL SPARK PLUG 8” DIA. WIRE AUGER CHOKE LEVER AIR FILTER RECOIL COVER FUEL FILL CAP HANDLE FUEL PRIMER BULB (not shown) -
Page 9: Operating Precautions
Operating Precautions PREPARING ENGINE FOR STARTING Before starting your unit, make sure the black throttle cable housing is seated all the way into the brass ferrule at the engine side of the cable. WARNING THIS ENGINE USES A GAS/OIL MIXTURE. DO NOT RUN ON STRAIGHT GAS ONLY, ENGINE DAMAGE WILL RESULT. -
Page 10: Operation
Operation 1. The clutch will transfer maximum power after about two hours of normal operation. During this break-in period clutch slippage may occur. The clutch should be kept free of oil or other moisture for efficient operation. 2. Drill holes without placing body weight on the unit. The auger operates most efficiently with a shaving action caused by the weight of the unit. - Page 11 Operation Warm Engine Start: 1. Push engine switch to the ON position. 2. Move choke lever to CHOKE or ON position. 3. Grasp starter handle with left hand and pull out slowly, until there is tension as you pull. Without letting starter handle retract, pull rope with a rapid full arm stroke.
-
Page 12: Maintenance
Maintenance AUGER MAINTENANCE 1. The gear case has 4 oz. of lithium grease installed at the factory. It is recommended that once a year the gear case be split and the grease level checked. Add grease only if level of grease is below top of the gears. - Page 13 Maintenance WARNING REMOVE THE SPARK PLUG WIRE TO PREVENT ACCIDENTAL STARTING BEFORE PERFORMING ANY MAINTENANCE SPARK PLUG MAINTENANCE 1. Check spark plug every 50 operating hours. The recommended spark plug is NGK BM6A. 2. Disconnect the spark plug cap, and clean any debris from around the spark plug area.
- Page 14 Maintenance AIR FILTER MAINTENANCE WARNING Never run engine without air cleaner properly installed. Added wear and engine failure may occur if air cleaner is not installed on engine. Steps for Cleaning Air Filter 1. Wash in warm water with mild soap until dirt and debris are removed.
-
Page 15: Troubleshooting
Troubleshooting Most troubleshooting problems are easy to resolve. Review the troubleshooting chart below for answers to common problems. For more complicated repairs, you may want to rely on your retailer or an authorized repair center (contact your retailer for a list of authorized mechanics in your area). -
Page 16: Warranty & Specifications
Record the information below for future reference. Model No. Serial No. Date of Purchase Place of Purchase SKU/Part No. 106475 Description Ice Auger Engine 52cc, 2-stroke Fuel 25:1 Gasoline to 2-cycle engine oil Fuel Tank Capacity 27 fluid ounces (0.8L)
