INSTRUCTION AND MAINTENANCE HANDBOOK
MOD.75/3
SCARIFIERS
CM300 (with gasoline engine)
CM300D (with diesel engine)
ORIGINAL INSTRUCTION
CMC srl
Via Padre Meroni, 20 – 22031 Albavilla (Co) Italy
tel. +39 031 619 650 – fax +39 031 619 780
e-mail: cmcmt@cmcmt.it - www.cmcmt.it
Advertisement
Table of Contents
Summary of Contents for CMC CM300
- Page 1 Via Padre Meroni, 20 – 22031 Albavilla (Co) Italy tel. +39 031 619 650 – fax +39 031 619 780 e-mail: cmcmt@cmcmt.it - www.cmcmt.it ______________________________________________________________________________________ SCARIFIERS CM300 (with gasoline engine) CM300D (with diesel engine) INSTRUCTION AND MAINTENANCE HANDBOOK MOD.75/3 ORIGINAL INSTRUCTION...
- Page 2 SCARIFIER MACHINES CM300 / CM300D CMC srl Via Padre P. Meroni, 20 – 22031 Albavilla (Co) Italy tel. +39 031 619 650 – fax +39 031 619 780 e-mail: cmcmt@cmcmt.it - www.cmcmt.it REV.07 - 06/17/2014 p. 2 of 16 MOD.76/1...
- Page 3 The descriptions and the images contained in this publication are not binding. The CMC s.r.l. reserves the right to make any changes at any time, without notice. For further details, please contact CMC S.r.l., which is at your disposal for any kind of information you need.
-
Page 4: Table Of Contents
14) TRANSPORTING OF THE MACHINE BY TRUCK 15) PRECAUTIONARY MEASURES FOR MAINTENANCE 16) GENERAL MAINTENANCE 17) SET AT REST 18) GENERAL NOTES – WARRANTY 19) SPARE PARTS LIST OF SCARIFIERS CM300 / CM300D ENCLOSURES EC Declaration of conformity warranty certificate sketch of noise and vibrations... -
Page 5: Identification Of The Machine
You can identify the model of the machine from the CE plate placed on it (see picture on page 2). Note: The technical data printed on the plate must be always specified whenever you contact CMC S.r.l. for information, spare parts requests or any other question you might need to clear up. -
Page 6: Intended Use Of The Machine And Abnormal Uses
Machine has been built to be used just within a working-place and it is classified as a working ma- chine. CMC S.r.l. declines all responsibilities for any different use. Scarifier is thought, designed and built to remove the horizontal marking (paint or plastic) from smooth surfaces (asphalt, cement, etc.). -
Page 7: Set Up
• the paragraphs Not attempt any further operation but please contact: • CMC srl via Manzoni, 35 – 22030 Orsenigo (Co) Italy tel. +39 031 619 650 – fax +39 031 619 780 e-mail: cmcmt@cmcmt.it - www.cmcmt.it. REV.07 - 06/17/2014 p. -
Page 8: Safety Measures
• Never permit anyone to operate the machine without training them to correct use of machine and without delivering them this manual • CMC declines all responsibility for damage to the machine or third parties due to negligence, tampering or improper use of any kind •... -
Page 9: Inspection At The First Starting
INSPECTION AT THE FIRST STARTING • Verify that the machine has not been damaged during the transport, check that the screws, the nuts, the bolts etc. are all properly tight • Check the level of the engine oil through the proper cap (see engine manual) 10) REFUELLING Danger. -
Page 10: Set At Work
SET AT WORK PIC. 1 Adjustament of handlebars height: Cut the straps that hold the wire of safety device (PIC.1) Unscrew the screw for regulation of handlebar height through spanner 17 (PIC.2 N.1) Adjust the height of handlebars Tighten strongly the screw of regulation of handlebar height through spanner 17 (PIC.2 N.1) Reposition the safety device wire as in picture (PIC.1) and fix it through straps... - Page 11 4. Lift lever (PIC.3 N.3) for unlocking the lifting device and pull up the knob (PIC.3 N.2) for mov- ing the cutter units in rest position (PIC.4 N.1). PIC. 3 2- knob of lifting device 3- lever for unlocking 4- engine shut-off safety the lifting device device 1- grip for adjusting...
- Page 12 Once cutter unit is up, start the engine (see engine handbook). Attention: machine is endowed of safety device (PIC.3 N.4): if operator leaves unawares the han- dlebars and lever of safety device, the engine shuts down. To be able to start the engine without leaving the safety lever, follow below steps: 1.
-
Page 13: Instructions For Scarifying
INSTRUCTIONS FOR SCARIFYING Unlock the lifting device (as before described) and lower the cutter unit in working position. Turn clockwise the grip (PIC.3 N.1) till when the cutters touch the ground. Adjust working cutter height turning the grip (PIC.3 N.1). Start to scrape. Pay attention to not lower too much the cutters: cutters and all other components could be damaged. -
Page 14: Precautionary Measures For Maintenance
PRECAUTIONARY MEASURES FOR MAINTENANCE Before executing any maintenance or cleaning operation, turn off the engine, place the scarifier on a flat surface and position wheel chocks to prevent accidental movement Before acting on the engine and silencer, wait that the machine is cool Keep within your reach a first aid kit Wear work gloves, safety glasses, safety shoes and work clothes without torn or loose parts GENERAL MAINTENANCE... -
Page 15: General Notes - Warranty
GENERAL NOTES - WARRANTY The machine is delivered with a EC Declaration of Conformity, referring to Machinery Directive 2006/42/EC. The EC Declaration must be always enclosed to this manual. If you lose this declaration, you’ll have to submit report to the competent authorities. About the warranty duration and full text, please refer to Warranty enclosed to this handbook. -
Page 16: Spare Parts List Of Scarifiers Cm300 / Cm300D
SPARE PARTS OF SCARIFIERS CM300 / CM300D N° Description Code N° Description Code GBB300 15CM300 DRUM EMPTY HEXAGON SHAFT RETAINING COVER (n°2 per 2CM300 16CM300 HEXAGON BUSHING drum) 17CM300 RETAINING BOLTS(n°8 x drum) BALL BEARING 4CM300 18CM300 SHAFT (n°4 x drum) RETAINING RING (n°2 X)
