Summary of Contents for Octava PRO DSX- TX
- Page 1 HDMI Over IP Installation Manual-PRO DSX HDMI Over IP Installation Manual-PRO DSX 172 Subnet and with Wireless AP + IR Revision: 1.1 Date : 8-29-18 HDMI Over IP Installation Manual-PRO DSX...
-
Page 2: Network Setup
Network Setup The Octava PRO DSX HDMI Video over IP solution is a scalable multiscreen 4K video connectivity platform. Designed to be scalable so you can build virtually any sized NxM HDMI Video Matrix, or Video Wall. The PRO DSX is runs on standard 1 Gigabit and LAN cables that is easy to install and maintain while delivery stunning 4K picture quality. - Page 3 The PRO DSX includes wideband IR in and out ports and can be used for: 1. changing the Zone receiver ( PRO DSX- RX) source selection. 2. controlling each video source An example is shown below. Octava Remote Video Source Remote HDMI Over IP...
- Page 4 PRO DSX –RX Receiver Phoenix Connector ( 3 position) for RS-232 Mounting Bracket Model Description PRO DSX- TX Pro HD over LAN Video Encoder Transmitter Phoenix Connector ( 3 position) Mounting Bracket PRO DSX- RX Pro HD over LAN Video Decoder Receiver...
- Page 5 Parts and Accessories: Optional Accessories PRO DSX TX 1 RU Mounting kit PRO DSX IR Emitter Cable PRO DSX IR Receiver Cable PRO DSX DC Power Supply 48V, 0.5 Amps PRO DSX Remote Control HDMI Over IP Installation Manual-PRO DSX...
- Page 6 Serial Port. Supports up to 115200 bps. Type = Phoenix 3 port connect IR Out and IN Infrared Cable Out , Infrared Cable IN Wide Band 20-60KHz using supplied Octava IR cables. 2CH Audio Line In 3.5 mm 2 Ch. audio inject. Overrides HDM input audio Reset Hardware Reset of PRO DSX –TX unit...
- Page 7 I/O Descriptions: RX Port Description IR Out and IN Infrared Cable Out , Infrared Cable IN Wide Band 20-60KHz using supplied Octava IR cables. RS-232 Port Serial Port. Supports up to 115200 bps. Type = Phoenix 3 port connect RX ID Button...
- Page 8 Basic Installation : Powering The PRO DSX can be PoE powered directly over the CATx LAN cables PoE Powered: Use PoE Source conforming to IEEE 802.3af or IEEE 802.3at PRO DSX –TX Transmitter PRO DSX –RX Receiver Connect to PoE port HDMI Over IP Installation Manual-PRO DSX...
- Page 9 ID and IP Setup : Each PRO DSX – TX and RX unit need to be set to a unique ID and IP address. For ease of installation, the ID and IP address can be set using the front panel push buttons.
- Page 10 RX ID LED Indicator 172.31.x.x subnet Each RX includes a LED ID indicator to easily identify the RX. The RX ID represents RX ID and the last octet of the RX IP address. PRO DSX_RX will have ID in the range : 01-199 PRO DSX_RX will have IP address in the range : 172.31.3.xxx.
- Page 11 TX ID LED Indicator 172.31.x.x subnet Each TX includes a LED ID indicator to easily identify the TX. The TX ID represents the CH ID and last octet of the TX IP address. PRO DSX-TX will have IP address in the range : 172.31.2.xxx. TX CH ID TX CH ID TX IP Address...
- Page 12 ID and IP Setup : RX ID and IP NOTE: The factory default is RX ID = 199 and IP = 169.254.3.199 Resetting the RX will reset RX ID = 199 and IP = 169.254.3.199 HDMI Over IP Installation Manual-PRO DSX...
- Page 13 ID and IP Setup : RX ID and IP The PRO DSX-RX ID can be manually setup per procedure shown below Example 2: Setting PRO DSX –RX to ID = 4 and IP = 172.231.3.4 Connect PRO DSX –RX and verify it is powered up. PRESS HOLD the button for ~ 5 seconds until the LED display indicates “N6”...
- Page 14 ID and IP Setup : RX ID and IP Release the button. LED will blink Note the 172 subnet LED indicator is ON Press button to increment from 01 to the desired RX ID. PRESS HOLD both the button for ~ 5 seconds until LED blinks.
- Page 15 ID and IP Setup : TX ID and IP NOTE: The factory default is TX CH ID = 199 and IP = 169.254.2.199 Resetting the TX will reset TX CH ID = 199 and IP = 169.254.2.199 HDMI Over IP Installation Manual-PRO DSX...
- Page 16 ID and IP Setup : TX ID and IP SETUP The PRO DSX-TX CH can be manually setup per procedure shown below Example 4: Setting PRO DSX –TX to ID = 05 and IP = 172.31.2.5 Connect PRO DSX –TX and verify it is powered up PRESS HOLD the button for ~ 5 seconds until the LED display indicates “N6”...
- Page 17 ID and IP Setup : TX ID and IP SETUP Release the button. LED will blink Note the 172 subnet LED indicator is ON Press button to increment from 01 to the desired TX CH ID. PRESS HOLD both the button for ~ 5 seconds until LED blinks.
- Page 18 Connect the HDMI output to Display 2 of your system Continue for all PRO DSX-RX needed in your system installation PRO DSX- TX Installation Connect a PRO DSX –TX to Ethernet switch and set the TX CH ID = Refer to : “TX ID and IP SETUP “...
-
Page 19: Display Name
Basic Installation : RX Check List Note the RX ID , IP address and the connected Display for future reference. RX ID RX IP Display Name RX 01 RX 02 RX 03 RX 04 RX 05 RX 06 RX 07 RX 08 RX 09 RX 10... - Page 20 Basic Installation : TX Check List Note the TX CH ID , IP address and the connected Display for future reference. TX CH ID TX IP Video Source Name TX 01 TX 02 TX 03 TX 04 TX 05 TX 06 TX 07 TX 08 TX 09...
- Page 21 WEB Interface Access The PRO DSX- TX and RX has various features that can be enabled and modified by directing accessing the TX or RX web interface by entering the TX or RX IP address in a browser. Connect All devices to PoE Ports.
- Page 22 WEB Interface Access The PRO DSX- TX and RX has various features that can be enabled and modified by directing accessing the TX or RX web interface by entering the TX or RX IP address in a browser. Access PRO DSX-TX by entering: 172.31.2.xx...
- Page 23 Integrated Octava System Controller Integrated inside the PRO DSX unit is the Octava System Controller Software. The integrated System Controller enables you to install |customize| operate your video system without additional hardware/gateways or software. Open a browser ( Chrome recommended). Access the Integrated Octava System Controller on the TX 01 by entering: 172.31.2.1/octavaswitch...
- Page 24 Integrated Octava System Controller Enter the Name of your Video Sources Here and Match to the corresponding PRO DSX-TX unit. Note- Only Enter the sources that you will use. Leave others blank Enter the Name of your Displays Here and Match to the corresponding PRO DSX-RX unit.
- Page 25 Integrated Octava System Controller Enter the Name of your Video Sources here and match to the corresponding PRO DSX-TX unit. Note- Only Enter the sources that you will use. Leave others blank Enter the Name of your Displays here and match to the corresponding PRO DSX-RX unit.
- Page 26 Integrated Octava System Controller Your System Interface will be created. HDMI Over IP Installation Manual-PRO DSX...
- Page 27 The PRO DSX includes wideband IR in and out ports and can be used for: 1. changing the Zone receiver ( PRO DSX- RX) source selection. 2. controlling each video source An example is shown below. Octava Remote Video Source Remote HDMI Over IP...
- Page 28 Place the IR Emitter over the IR Receiver of the Video Source IR Detector Video Source Octava IR Emitter Cable Connect the IR Receiver cable to the IR IN Port as shown. Place the IR Receiver cable so there is line of sight from remote control...
-
Page 29: Safety Information
Safety Information HDMI Over IP Installation Manual-PRO DSX... -
Page 30: Contact Information
Pro DSX Video over LAN Contact Information Octava Inc.-7078 Peachtree Ind. Blvd Suite 300 Norcross, Ga. 30071 Tel 770.825.0388 www.octavainc.com Email: info@octavainc.com HDMI Over IP Installation Manual-PRO DSX...
