Summary of Contents for Raysgem Loona
- Page 1 RC133N1 13.3...
- Page 2 All pictures in this manual are for reference only, actual product may di er. No further notice will be released on small modifications.
- Page 3 Thank you for purchasing this RAYSGEM smart mirror. Before installation, please Warning This is a sign of high voltage danger. Any contact with the internal parts can be extremely dangerous. Do not try to open the mirror in case of electric shock...
-
Page 4: Quick Guide
Standard LOONA Mirror package contains items as below. Please contact your local Adding display, sensor and a smart solution to a traditional lighted mirror, LOONA brings a new way for people to entertain in front of a mirror. It helps to mirror on color or shape because of customization or model. -
Page 5: Back View
Speaker Press for Shut down 10 sec ③ Display ON/OFF: When LOONA is ON and at home page, tap TWICE on screen will turn off the display, ON/OFF(touch key) tap ONCE to wake up the display. Power adapter Touch screen... - Page 6 LOONA blue tooth is ON by default. Once external devices(Sleep monitor, Blood pressure monitor, person is approaching. LOONA will turn OFF the display after 3 minutes if not in use. Screen Blood sugar monitor and etc..) are ON, they will pair with LOONA automatically.
- Page 7 Installation Installation Demonstration Wall 3M adhesive tape Wall Wall Hang with Leather Band wall anchor Wall or any smooth surface Wall anchor Leather Band Hang on a smooth surface Bracket 3 Screwheads 2*M8 screws 3M adhesive tape Bracket setscrews *3 Use 2*M6 screws Mirror Mirror...
-
Page 8: Specification
Dimension Specification Display Dimension/mm Display size 13.3" Display type Display ratio 16:9 Resolution 1920 x R.G.B x 1080 23 13 350 cd/m2 ( Original LED screen ) Brightness 1000:1( refer to actual model ) Contrast ratio Viewing angle 178° (H) X 178° (V)(refer to actual model) Response time 16ms Working life... -
Page 9: Connect To Power
Connection Connect to power Power/Consumption Power socket(220V) Power input DC 12V 3A Consumption ≤ 36W Standby ≤ 0.5W Power cable SCALE 1.000 Working / Temperature & Humidity Working humiture 0~45℃ /20-90%RH Storage humiture -20~60℃ /5-90%RH Connect to USB drive Dimension/Material/Process USB drive Portable hard drive General size... -
Page 10: Troubleshooting
Troubleshooting is only for users who are facing major operating issues on the Mirror. If users should have problems with specific functional page, please go to your retailer to get user manuals on specific functions. Couldn't start up LOONA mirror 1. Check if power jack is loose. No image/sound or bad display 1. -
Page 11: Fcc Statement
FCC Statement FCC Caution 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following Note: This equipment has been tested and found to comply with the limits for a Class B digital conditions: device, pursuant to part 15 of the FCC Rules.
