Brinno ATH100 User Manual

Package Contents

1. ATH100 Weather Resistant Housing x1

2. User manual

Parts of ATH100

1
4
5
6
2
7
3
8

Specification

Dimension
89(W)x125(L)x54(D) mm
Weight
110 g
Material
PC, acrylic, and rubber
Waterproof
IP54
Product specifications, size and shape are subject to change without notice, and actual product appearance
may differ from that depicted herein.
Thank you for purchasing Brinno Time Lapse Camera Accessories!
If you have any questions or problems setting up your Brinno TimeLapse Camera
please contact the sales staff where you purchased our product or email us at
customerservice@brinno.com
Brinno Incorporated directly:
7F, No.75, Zhou Zi St., Taipei City 11493, Taiwan
Phone:+886-2-8751-0306
customerservice@brinno.com
1. Latch
2. I/O port
3. I/O USB port
4. Seal
5. MENU Control
6. TIME Control
7. OK/START
8. Extended space*
* this Space is for TLC200
Extension port cover.
Fax:+886-2-8751-0549
301-0036-00 EN A1
Weather Resistant Housing
ATH100
User Manual
