Intergas inTouch Installation Manual page 2

1. Your intouch pack contains:
®
1.1 Basic intouch set
®
The intouch round set also contains
- LAN2RF gateway ®
a Honeywell Round (T87M2018) thermostat.
- Ethernet cable
- Power adapter
- Fixing materials
- Installation guide
1.2
The following smartphone app is available free of charge
intouch user app
®
2. Operation
The Intergas intouch system works simply and effectively. It runs on your home network
®
and connects your Intergas Combi Compact ECO RF boiler in-built RF module
(2014 or later), the LAN2RF gateway and an existing thermostat.
This system is compatible with the Honeywell Round (T87M2018) thermostat. Response
times between the intouch system and a room thermostat depend on the type of thermostat
®
in use. For proper connection, refer to your thermostat's installation and operating guide.
Once you've installed the LAN2RF gateway and intouch app, pair the gateway
®
and the boiler (one time only). Follow the instructions in the app.
NB: The intouch system does not work in combination with ON/OFF thermostats.
®
1 Remove the LAN2RF gateway
from the packaging.
3 Connect the LAN ports on
l
your home router and the LAN2RF
®
gateway using the Ethernet cable.
intouch intouch
® ®
Intergas
5 Connect the power adapter
to the LAN2RF gateway.
2 Remove the Ethernet cable 7 All five LAN2RF gateway LEDs should now briefly illuminate.
from the packaging.
1
1 PWR:
2 WAN:
3 LAN:
4 RF:
Control LED for future applications
5:
4 Remove the power adapter 8
from the packaging.
6 Plug the power adapter into 10
the plug socket.
LAN2RF
gateway
2 3 4 5
LAN2RF gateway has power
LAN2RF gateway and Intergas server connected
LAN2RF gateway and local home network connected
LAN2RF gateway and boiler connected
Download the app from Google play Create an Intergas account.
9
Follow the instructions on the app
or App Store. Follow the instructions
in the app.
intouch intouch
® ®
Intergas
Login to your Intergas account from 11 M ake sure your smartphone and
the app to pair your LAN2RF gateway LAN2RF gateway are using the
and the boiler. Follow the instructions same local Wi-Fi network.
in the app.
12 Four gateway LEDs should now
be ON. You can operate your
LAN2RF
gateway
boiler remotely.
If the system has been installed
properly, three LEDs will remain
ON (PWR/WAN/LAN).
The system is ready for use and you
can now pair the LAN2RF gateway
and boiler. Please consult the
'Network Problems' section if
these three LEDs are not ON.
