- Page 1 ROKKER ® 700w RMS Dual-Amplifier Kit For 2015-2018 Harley® CVO Street Glide JAMP-700SG15-CVO Installation Instructions...
- Page 2 Product Description This STAGE-4 ROKKER XXR custom dual-amplifier KIT has been engineered to be 100% plug-and-play for your convenience during the This is the new J&M STAGE-4 ROKKER® XXR Custom 700w dual-am- installation and to maintain the complete integrity of your Harley CVO plifier installation kit for the 2015-2018 Harley CVO StreetGlide (CVO StreetGlide’s internal wiring harnesses. ONLY) with the Harley 6.5GT Premium CVO radio. Top quality heavy gauge power/ground wires are used for the fused This kit features our in-fairing mounted &...
- Page 3 7. Plug in the J&M amplifier adapter cable # 1 to the Photo C factory wiring harness amplifier plug and then connect the corresponding plugs to the amplifier, including the main power harness cable and secure all wires into place using the zip ties provided. (Photos-C) Remove the 3 plastic retainer plugs holding the fabric cover over the Harley amplifier in the back of the left side saddlebag. 9. Unplug the amplifier from the in-saddlebag wiring harness, remove the two top mounting screws and lift the amplifier out of the saddlebag bracket assembly. 10.
-
Page 4: Specifications
14. Turn on the ignition and test the entire system, including the bass, treble and front/rear fade capabilities. (Harley radio must be properly flashed to the J&M custom flash specs, using either the Diag- 4-bike or Techno-Research digital technicians) 15. Install the supplied fabric cover over the saddlebag amplifier us- ing the plastic push-plugs. (Photo-G) Photo G 16. Reinstall the fairing, windshield, fuel tank and seat. (Photo-H) Important Programing Note: The amplifier gain & frequency response adjustments have been pre-set at our factory for this specific Harley Davidson audio system application, using speakers... - Page 5 WARRANTY AND REPAIR INFORMATION TWO YEAR LIMITED WARRANTY In order to facilitate the servicing of this warranty, the Warranty Registration Form should be filled out and returned within 10 days of the date of purchase. However, return of the Warranty Registration Form is not a precondition of this warranty, and this Warranty will be observed by J&M CORPORATION whether or not the Warranty Registration Form is returned, on the condition that other satisfactory evidence of the date of the original purchase is provided to J&M CORPORATION.
