BIKE GUARD 708A3 PLUS USER MANUAL
1
INTRODUCTION
Bicycles are stolen everywhere and every day no matter they are with or without locks. To protect your bicycle from
being stolen, our Digital RF wireless bicycle alarm system can be your best solution. Once the bike theft happens,
the Bike-Alarm will sound loud beeps to scare the thief away and the Beeper will also immediately activate an
emergency alarm to warn you to check the bicycle and take the necessary actions urgently. Therefore, with Bike
Guard 708A3 Plus armed on the bicycle, whenever you want to take a short break in the cycling journey, there is
no need for you to worry about parking your bike nearby.
Product Description
Base Unit
Back
Front
2
3
4
5
1
Tag Unit
Back
Front
2
1
Specification
Model Name
Function
Search Range
Alarm Triggered
Base Unit / Tag Unit Base (M08AM)x1
Battery Type CR2032 or LIR2032
Battery Life Time on Standby
Beep Audible Level (at 10 cm / 3.9 inches)
61.5x36x11.6mm
Dimension (L/W /H)
2.42x1.42x0.46inch
How to apply/wear the Base and Tag units.
Package Contents
Base Unit
708A3 Plus
Model Name
1 pc
Base Unit
Tag Unit 1 pc
Batteries CR2032x1, AAAx2
Strap 1
Hook
1
User manual

1 Ring attachment
2 Speaker Sound output
3 Show the signal synchronous status between Base and Tag unit
Connecting status
4 Search button Press to search for the Tag unit.
5 Power switch Power ON/OFF
6
6
Battery cover
1
Screw Hole
2 Speaker
Sound output
Bike Guard 708A3 Plus
Alert & Search
0~2600ft/800m (in open area)
Vibration Sensor
Tag (S07C)x1
AAAx2
10 days 30 days
95 db 105db
127x40x12mm
4.99x1.57x0.47inch
Tag Unit
Page 1
BIKE GUARD 708A3 PLUS USER MANUAL
2
GETTING STARTED
This section shows how to quickly setup and trigger an alert condition.
1. Place battery into the Base unit and the Tag unit.
Base Unit
Open the battery cover by placing your thumb on the cover
(as shown) and pulling it backwards until it clicks open;
then lift off the cover.
Insert the battery into the battery compartment with the "+"
sign on the battery facing up. Then replace the battery
cover by sliding it up into compartment opening.
Tag Unit
a) Open from the fillister on the button of housing or curve
side by your nail, like open shell.
b) Insert batteries (included) following the polarity
markings in the battery compartment.
c) Close the battery compartment cover.
2. Make sure that the Base and Tag units are in close proximity.
3. Turn ON the Power switch on the Base units. The base
units will establish a link and begin to blink synchronously .
4. Shock the Tag unit, and the base unit and Tag unit will beep.
5. Congratulations, now you are ready to
bottle cage on a bike. (Turn off the base unit in case the alarm is triggered while installation)
3
ALERT
A sensor is built-in to detect the vibration, while someone is trying to move your bike, the Bike
Guard will alert you in 2 seconds. The Base unit will begin to beep and RED led blinks, the Tag
units will also beep for 10 seconds and repeat alarm until vibration is stop.
Disarm Alarm:
Under standby mode, turn OFF the Base unit within 1 meter from your bicycle, the Tag unit will sound
"Di-du" to approve disarm. When you hear "Di-du", you have disarmed the Bike Guard. if you turn off
the base unit with tag unit is far away 2 meters.Then the tag unit is still triggered alarm by slight
vibration.
Beep Beep...
put the Tag unit underneath the
Beep Beep...
Page 2
