MODELS: Fuego Manual / Remote Option
PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN FOR FUTURE REFERENCE
This electric fire has been made with great care. Here are some instructions including cleaning and
maintenance, which will help you keep your fire in good condition for many years. If you experience
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
This is an amendment to the standard and now applies to all EN60335 or later approved products.
DO NOT TURN THE FIRE ON UNTIL YOU HAVE READ ALL OF THE INSTRUCTIONS.
St Marys Road, Nuneaton, Warwickshire, CV11 5AU
Email: sales@widney-leisure.co.uk | Web: www.widney-leisure.co.uk
The product complies with the European Safety Standards EN 60335 -1, EN60335-2-30 and the essential requirements of EEC Directives 73/23 and 89/336
Fuego LE Timer fires
Installation and User Instructions
any parts or service problems contact your retailer.
WARNING - DO NOT BLOCK ANY AIR VENTS.
Created in the UK by
WIDNEY LEISURE LTD
Telephone: +44(0) 2476 377550
1
Advertisement
Table of Contents
Related Manuals for Widney Fuego Manual/ Remote Option
Summary of Contents for Widney Fuego Manual/ Remote Option
- Page 1 WIDNEY LEISURE LTD St Marys Road, Nuneaton, Warwickshire, CV11 5AU Telephone: +44(0) 2476 377550 Email: sales@widney-leisure.co.uk | Web: www.widney-leisure.co.uk The product complies with the European Safety Standards EN 60335 -1, EN60335-2-30 and the essential requirements of EEC Directives 73/23 and 89/336...
-
Page 2: This Appliance Must Be Earthed
YOUR FIRE UNPACKING, ELECTRICAL INSTALLATION & GENERAL SAFETY GENERAL: Unpack the fire carefully and retain the packaging for possible future use, for example in the event of moving or returning the fire to your supplier. Remove any plastic protection film and transit tape. The fire incorporates a flame effect that may be enjoyed at any time of the year;... - Page 3 ALWAYS INSTALL THE FIRE SO THAT THE PLUG IS ACCESSIBLE. DO NOT COVER OR HANG CLOTHES, TOWELS ETC. OVER OR NEAR THE HEATER AS THIS COULD CAUSE OVERHEATING AND POSSIBLE DAMAGE. THE HEATER SHOULD NOT BE USED IMMEDIATELY BELOW A SOCKET OUTLET.
-
Page 4: Section 1: Electric Fire Fitting Instructions
SECTION 1: ELECTRIC FIRE FITTING INSTRUCTIONS The appliance can either be fixed to a flat vertical wall or inset – please refer to the instructions below. WARNING DO NOT BLOCK ANY OF THE AIR VENTS LOCATED IN THE BACK, SIDES OR THE FRONT OF THE FIRE FLAT WALL FIXING: The appliance should be securely fixed to the wall using suitable... - Page 5 FULLY INSET FITTING: The fire can be inset up to the fixing flange as indicated in the diagram. IMPORTANT: T IS IMPORTANT TO PROVIDE SUFFICIENT AIR TO THE CAVITY BEHIND THE APPLIANCE 12,600 RECOMMENDED MINIMUM IS HE FIRE MUST BE FITTED WITH A MINIMUM OF MM CLEARANCE BETWEEN THE REAR OF THE FIRE AND ANY SOLID WALL Fitting the fire into a wall or aperture:...
-
Page 6: Fitting The Fascia
Place pebbles onto the bed Pebble effect setup: Remove the pebbles carefully from the packaging and place the pebbles evenly on the effect tray. The fire is supplied with a pebble effect light box that is positioned on top of the flame effect panel as shown in the diagram (right). -
Page 7: Section 2: Operating Your Fire
SECTION 2: OPERATING YOUR FIRE OPERATING THE FIRE IN MANUAL MODE (Not applicable to LE Timer fires) MANUAL MODE IS USED IF THE OPTIONAL REMOTE HANDSET HAS NOT BEEN PURCHASED, HAS BEEN MISLAID OR THE BATTERIES ARE FLAT. To operate the fire in manual mode follow the steps below: NOTE: BY PRESSING ‘FLAME’... -
Page 8: Remote Operation
OPERATING YOUR FIRE—REMOTE OPTION FIRE REMOTE OPERATION: (Not applicable to LE Timer fires or if the remote option has not been purchased) On first use insert the batteries into the remote control handset—see battery replacement section below. With the mains supply connected to the fire and switched on the fire can be operated. - Page 9 OPERATING YOUR FIRE—LE TIMER FIRE (Not applicable to Manual / remote fires) To operate the fire follow the steps below: NOTE: BY PRESSING ‘FLAME’ MORE THAN ONCE THERE ARE THREE INTENSITY SETTINGS AVAILABLE...
-
Page 10: Section 3: Maintenance And Cleaning
SECTION 3: MAINTENANCE AND CLEANING DISCONNECT THE FIRE FROM THE SUPPLY BEFORE CLEANING OR CARRYING OUT ANY MAINTENANCE CLEANING Warning: If the air inlet becomes covered with dust the fire may cut out. This is a safety feature. Refer to Safety Cut-out information for further action. IMPORTANT NOTICE Your electric fire operates using a rotary fan. -
Page 11: Section 4: Important Information
SECTION 4: IMPORTANT INFORMATION SAFETY CUT-OUT: The heating element is fitted with a cut-out which will switch off the fire in the event the fire over- heats, should this occur follow the points below. Switch the fire off at the wall outlet, the fire must be isolated from the mains power supply. Ensure that there are no obstructions in or around the air inlet or air outlets. - Page 12 SECTION 4: IMPORTANT INFORMATION Continued Dimensional Specifications (GL Wide / GL Standard) Height 590mm / 575mm Width 720mm / 580mm Depth 165mm / 165mm Minimum mounting height from floor or 60mm surface Minimum aperture size 535mm High x 440mm Wide GL Wide GL standard...
