VC 11932 Mounting And Operating Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R
C
R
C
By selecting this VC product you have chosen a professional
device, which guarantees highest possible quality and
Please read the following instructions carefully before
comissioning the product in order to be able to take full
advantage of all quality features regarding this product line.
Änderungen in Technik, Design und Ausstattung vorbehalten
Installations- und Betriebsanleitung
Mounting and Operating Manual
Dear Customer!
reliability.
IP Camera
Art. no. 11932
©
All contents of this document may change without prior notice
MO_11932/04.05.2011
MO_14511-K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 11932 and is the answer not in the manual?

Questions and answers

Summary of Contents for VC 11932

  • Page 1 Installations- und Betriebsanleitung Mounting and Operating Manual Dear Customer! By selecting this VC product you have chosen a professional device, which guarantees highest possible quality and reliability. Please read the following instructions carefully before comissioning the product in order to be able to take full advantage of all quality features regarding this product line.
  • Page 3 Cautions 1. Read this user manual before use. 2. Keep this user manual accessible. 3. Follow instruction 4. Keep this unit away from cleanser. 5. Keep this unit dry in ventilation. 6. Give way to ventilation outlet. 7. Power cord must be fixed properly. 8.

  • Page 4: Table Of Contents

    Content 1.OUTLINE 1.1 INTRODUCTION 1.2 FEATURE 1.3 SPECIFICATION 1.4 ACCESSORY 1.5 SYSTEM REQUIREMENT 1.6 PANEL 2.INSTALLATION 2.1 CABLING 2.2 ETHERNET FRAMEWORK & CONNECTION 3.QUICK SETUP 3.1 IP SETUP for IPCAM 3.2 LOGIN -IPCAM ON IE 3.3 INSTRUCTION & LIVE VIEW of IPCAM 4.OPERATION 4.1 SYSTEM SETUP 4.1.1 STATUS...

  • Page 5: Outline

    I P C A M E R A 1.OUTLINE IPCAM is a low cost provision of network surveillance facility whichtransmits images on network to remote PC in format of compression technology. Monitoring, storage and recognition on line are provided by IPCAM. Image transmission remains the same quality on both ends of server site and remote site.

  • Page 6: Specification

     I P C A M E R A     1.3 Specification Compatible with BT.656，28.63636MHz (NTSC)、28.375MHz(PAL) Camera type LENS Mount C/CS Mount Compression MPEG4 / JPEG Client View NTSC (Resolution/ D1： 720x576 / 25 D1： 720x480 / 30 CIF：...

  • Page 7: Accessory

     I P C A M E R A 1.4 ACCESSORY 1.5 SYSTEM REQUIREMENT Pentium4 or above 1. IPCAM Windows 2000/XP/VISTA OS 2. CD ROM Protocol comply to 802.11 or ADSL network 3. USER MANUAL Microsoft Internet Explorer 6.0 or above 4.

  • Page 8: Ethernet Framework & Connection

     I P C A M E R A 2.2 ETHERNET FRAMEWORK & CONNECTION ★ PC TO IPCAM CONNECTION RJ45 Cross-over Cable 1).Use Cat5 Cross-over Cable to connect PC Brown Green/White Brown/White 7 Green Green Orange/White Blue/White 5 Blue Blue Blue/White Green/White 3 Orange...
  • Page 9  I P C A M E R A b. Select “Local Area Connection” by clicking mouse on the right. Click “Properties” accordingly. c.Select “TCP/IP” and click “Properties.”  ...
  • Page 10  I P C A M E R A d.Select “Use the following IP address” to input IP address, Subnet mask and Default gateway. Click ”OK” accordingly. 4).Follow the following procedure to make sure IP address correct. a. Click “ Start” “...
  • Page 11  I P C A M E R A b.Enter DOS and input “ipconfig”. Click “enter” to inspect IP address, Subnet mask and Default gateway. ★ INTRANET CONNECTION I P C A M Router/Access Point Switch Hub Computer Intranet 1.Cat 5 cable must be used in condition of connection via router, DSL modem and hub.

  • Page 12: Quick Setup

     I P C A M E R A 3.IPCAM detects DHCP when system starts working. IPCAM Enables DHCP protocol to accept IP address from NAT when NAT router detected. Default IP address becomes 192.168.1.126 when NAT router not detected. Suppose there is an IP address 192.168.1.126 on internet.
  • Page 13  I P C A M E R A 6.Update Name(N): Change user name of the indicated IPCAM, then press “OK” to reboot the IPCAM. 7.Update Port(P): Set the port of the indicated IPCAM and press “OK”to reboot the IPCAM. 8.Default(D): Restore the default value of the indicated IPCAM, then press “OK”...

  • Page 14: Login Ipcam On Ie

     I P C A M E R A 3.2 LOGIN IPCAM ON IE To Login: 1. In IPCameraSearcher, click the IP address of the indicated IPCAM. 2. In IE, type the IP address of the indicated IP address. ★ USERNAME:admin ★...
  • Page 15  I P C A M E R A 1. PLAY/STOP： Play/Stop Picture. 2. REC： Record the file in AV format. (Refer to 4.1.2 Video & Audio Settings to customize the file saving path.) 3. SNAPSHOT： Snapshot the picture on screen in a JPG file. (Refer to 4.1.2 Video &...

  • Page 16: Operation

     I P C A M E R A    4.OPERATION 4.1SYSTEM SETUP 4.1.1 STATUS 4.1.1.1 SYSTEM INFORMATION ˙ Firmware Current Version：By updating the firmware, more functions will be attached to the program. 4.1.1.2 NETWORK STATUS ˙ Ethernet MAC Address: MAC address of the IPCAM. ˙...

  • Page 17: Video & Audio Settings

     I P C A M E R A 4.1.2 VIDEO & AUDIO SETTINGS 4.1.2.1 VIDEO SETTINGS ˙ CBR：Set the Constant Bit Rate of Video ˙ Resolution：Picture resolution. Four levels of resolution are provided for selection. ˙ Limit Frame Rate to: Frame rate transmitting per second is defined by the internet connection speed.

  • Page 18: 3Networking

     I P C A M E R A    4.1.3 NetWorking 4.1.3.1 IP Address Configuration ˙ There are two ways to set the IP address： ˙ Obtain IP address via DHCP: Obtain IP address via Dynamic Host Configuration Protocol.

  • Page 19: Pppoe

     I P C A M E R A   4.1.4 PPPoE 4.1.4.1 PPPoE CONFIGURATION ˙ Enable PPPoE：Enable or disable PPPoE. ˙ User Name：Insert the user name from by ISP provider. ˙ Password: Insert password from ISP provider. ˙ MTU (128~1492): Maximum Transmission Unit, the largest packet that can pass onwards in communication protocol, is calculated in bytes of the size.

  • Page 20: Ddns

     I P C A M E R A 4.1.5 DDNS Signing up at DynDNS, PeanutHull, or perfecteyes before setting DDNS is required. 4.1.5.1DYNAMIC DNS ˙ Choose Server: Choose the DDNS server that provided by DynDNS, PeanutHull, and perfecteyes. ˙ DNS Account: Account number provided by DDNS server, ex. test. dyndns.org.

  • Page 21: Date & Time

     I P C A M E R A    4.1.6 DATE & TIME 4.1.6.1 CURRENT SERVER TIME ˙ Show current time at the IPCAM. 4.1.6.2 Time Zone ˙ Choose the time zone where the IPCAM is at. 4.1.6.3 TIME MODE ˙...

  • Page 22: Administrator

     I P C A M E R A 4.2.2 ADMINISTRATOR In this section, the user can add, delete, enable/disable anonymous user, and set the camera (video server) name. 4.2.2.1 USER LIST ˙ Add or remove users. ˙ Add: Click to add new users. ˙...

  • Page 23: Management

     I P C A M E R A 4.2.3 Management 4.2.3.1 Change Password ˙ User Name: Insert user name. ˙ Password: Insert new password. ˙ Confirm Password: Insert again the password to confirm. 4.2.4 SMTP (E-Mail) 4.2.4.1 SMTP Server Settings ˙...

  • Page 24: Ftp

     I P C A M E R A    4.2.5 FTP 4.2.5.1 FTP SETTINGS ˙ FTP Server: Insert address of FTP Server. ˙ User Name: Insert user name. ˙ Password: Insert password. ˙ FTP Command Port: insert FTP command port . ˙...

  • Page 25: Special Setting

     I P C A M E R A 4.2.6.1 EMBEDDED MOTION DETECTION SETTING ˙ Begin: Total 16 detection regions, click “ begin” to edit the setting. ˙ Edit Region: Under edit mode, define detection region. ˙ Remove Region: Under edit mode, remove defined detection region(s). ˙...

  • Page 26: User Guide Of Avplayback

     I P C A M E R A 5. USER GUIDE of AVPlayBack This software AVPlayBack can play the recorded files with an *.av extension and also can convert an *av file to an *.avi file 5.1 THE MAIN FUNCTION OF AVPlayBack ˙...
  • Page 27  I P C A M E R A OpenFile： Open the *.av recorded file. File information： Location of the File Path and Total Time for the video length Play Control：Fast Reverse、Reverse Play、 Pause、Play、Fast Forward Fast Reverse/Forward: 2X、4X、8X、16X、32X Snapshot： one click can capture one JPG image. Volume Control: Adjust or mute the volume.
  • Page 28 Installations- und Betriebsanleitung Your local distributor All contents of this document may change without prior notice All rights are reserved. Änderungen in Technik, Design und Ausstattung vorbehalten MO_14511-K...
