USER'S GUIDE SPECIFICATION
1.Model Description
MODEL
CW62A model
SUFFIX
ALL
2.Printing Specification
1.Trim Size (Format)
2.Printing Colors
* Cover :
* Inside :
3.Stock (Paper)
* Cover :
* Stock :
4.Printing Method :
5.Bindery :
6.Laguage :
7.Number of pages :
"This part contain Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level,
Details should be followed Eco-SCM management standard[LG(56)-A-2524].
Especially, Part should be followed and controlled the following specification .
Note
(1)Eco-hazardous substances test report should be submitted
when Part certification test and First Mass Production.
(2) Especially, Don't use or contain lead(Pb) and cadmium(Cd) in ink.
3. Special information
4. Change
10
9
8
7
6
5
4
1/12/2007
3
14/2/2007
2
1/1/2007
1
10/12/2006
Rev.No.
DD/MM/YY
LG
BRAND
Product Name
CW62A
Size A5 (210 mm. X 297 mm.)
Black
Black
Wood free pager 60 GSM
Wood free pager 60 GSM
Off-Set
Stiching
Eng/Thai
66 Pages
212903
212903
212903
212903
Signature
Change No.
-
add FS6,FS4 and FU1 tool
-
-
Add 29FG1 and FC2 tool
-
PIC
Chatchai A.
Somphop P.
Part No.
38289U0579Y
06/12 REV01
add FU3 and FU5 tool
update every thing
Change Content
COS

Advertisement

Table of Contents
loading

Related Manuals for LG CW62A

Summary of Contents for LG CW62A

  • Page 1 66 Pages 7.Number of pages : “This part contain Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level, Details should be followed Eco-SCM management standard[LG(56)-A-2524]. Especially, Part should be followed and controlled the following specification .
  • Page 2 P/N.:38289U0579Y(0702 REV04)

  • Page 4: Table Of Contents

    Contents Installation Location and function of controls Remote control handset Battery installation Front panel / Side panel Basic operation On and off / Programme selection Volume adjustment / Quick view Mute function On screen language selection (option) On screen menus Menu selection Setting up TV stations Auto programme tuning...

  • Page 5: Installation

    Installation Power This set operates on an AC mains supply, the voltage is as indicat- ed on the label on the back cover. Never apply DC power to the set. In the event of thunderstorms or powercuts, please pull out the aer- ial and mains plugs.

  • Page 6: Location And Function Of Controls

    Location and function of controls All the functions can be controlled with the remote control handset. Some functions can also be adjusted with the buttons on the front panel of the set. POWER MUTE Remote control handset Before you use the remote control handset, please install the bat- teries.

  • Page 7: Battery Installation

    Location and function of controls 8. FAVOURITE selects a favorite programme. 9. EYE/ (option) POWER MUTE switches the eye function on or off. 10. MUTE switches the sound on or off. 11. TV/AV selects TV or AV mode. switches the set on from standby. MENU TV/AV exits the Teletext mode.
  • Page 8 29FU3/29FU5 series...

  • Page 9: Basic Operation

    Basic operation On and off 1. Press the main power button to switch the set on. 2. If the set is in standby mode, press the POWER, , TV/AV or NUMBER buttons on the remote control handset to switch it on fully.

  • Page 10: On Screen Menus

    On screen menus The dialogue between you and your set takes place on screen with an operator menu. The buttons required for the operating steps are also displayed. Menu selection 1. Press the MENU button and then button to display each menu.

  • Page 11: Setting Up Tv Stations

    Setting up TV stations Up to 100 TV stations can be stored by programme numbers (0 to 99). Station Once you have preset the stations, you will be able to use the AutoOprogramme or NUMBER buttons to scan the stations you programmed. ManualOprogramme Program meOedit Stations can be tuned using automatic or manual modes.
  • Page 12 Setting up TV stations Manual programme tuning Station AutoOprogramme Manual programme lets you manually tune and arrange the sta- ManualOprogramme Program meOedit tions in whatever order you desire. Also you can assign a station FavouriteOprogramme name with five characters to each programme number. 1.
  • Page 13 Setting up TV stations Assigning a station name Station AutoOprogramme 1. Repeat the ‘Manual programme tuning’ steps 1 to 3. ManualOprogramme 2. Press the button to select Name Program meOedit FavouriteOprogramme 3. Press the button on the Name pull-down menu. 4.
  • Page 14 Setting up TV stations Programme edit Station AutoOprogramme This function enables you to delete or skip the stored programmes. ManualOprogramme Program meOedit Also you can move some stations to other programme numbers or FavouriteOprogramme insert a blank station data into the selected programme number. 1.
  • Page 15 Setting up TV stations Favourite programme Station AutoOprogramme ManualOprogramme This function lets you select your favourite programmes directly. Program meOedit FavouriteOprogramme 1. Press the MENU button to select the Station menu. 2. Press the button and then button to select Favourite ()O}{OOKOMENU programme...

  • Page 16: Calling The Programme Table

    Setting up TV stations Calling the programme table You can check the programmes stored in the memory by displaying the programme table. Displaying programme table Press the LIST (or BLUE) button to display the Programme table menu. The programme table appears on the screen. One programme table contains ten programmes as below.

  • Page 17: Picture Adjustment

    MENU grammed for good picture reproduction at the factory and cannot be changed. You can enjoy the vivid and hi-definition picture with LG’s excellent Digital Reality processor technology. 1. Press the MENU button and then button to select the Picture menu.
  • Page 18 Picture adjustment Eye (option) Eye is an optional function. Only a set with eye option can perform this function. In some models, the set will automatically adjust the picture accord- ing to the surrounding conditions. This will enable you to enjoy the most suitable picture according to the surroundings.

  • Page 19: Sound Adjustment

    Sound adjustment Sound SSM (Sound Status Memory) You can select your preferred sound setting; Flat, Music, Movie or Turbo 0Sound Sports and you can also adjust the sound frequency of equalizer. Balance 1. Press the MENU button and then button to select the Sound menu.

  • Page 20: X-Wave (Wireless Sound) (Option)

    Sound adjustment X-WAVE (Wireless Sound) (option) Sound You can also listen to the sound through the FM receiver. Turbo 0Sound 1. Press the MENU button and then button to select the Balance Sound menu. 2. Press the button and then button to select X-WA VE 3.

  • Page 21: Nicam Reception (Option)

    Sound adjustment Sound output selection In AV mode, you can select output sound for the left and right loud- speakers. Repeatedly press the I/II/ button to select the sound output. Audio signal from audio L input is sent to left loud-speaker and audio signal from audio R input is sent to right loud- speaker.

  • Page 22: Time Setting

    Time Setting Setting the clock Time Clock 1. Press the MENU button and then button to select the OffOtime Time menu. OnOtime AutoOsleep 2. Press the button to select Clock 3. Press the button and then button to adjust the hour. Time Clock Clock...

  • Page 23: Other Functions

    Other functions TV and AV modes Special Language Inputs can be set for TV or AV mode. AV mode is used when a video Input cassette recorder (VCR), or other equipment is connected to the set. Childolock Degauss Note : When a VCR is connected via the aerial socket the set is used in TV mode.
  • Page 24 Other functions Blue back (option) Special Language If you select on the Blue back pull-down menu, the blue back- Input Childolock ground appears on the screen when there is no or poor signal. Degauss 1. Press the MENU button and then button to select the Special menu.
  • Page 25 Other functions Games (option) Special Language Input Game is an optional function, only a set with game can perform this Childolock Degauss function by using the remote control handset. 1. Press the MENU button and then button to select the Special menu.

  • Page 26: Pip Operation (Option)

    PIP operation (option) Option : PIP is an optional function, so that only the set with PIP function can operate. PIP (Picture in Picture) displays a picture within a picture. On and off Press the PIP button to switch on the sub picture. press this button again to switch it off.

  • Page 27: Teletext (Option)

    Teletext (option) Teletext (or TOP text) is an optional function, therefore only a set with the teletext system can receive the teletext broadcast. Teletext is a free service broadcast by most TV stations which gives up-to-the-minute information on news, weather, television pro- grammes, share prices and many other topics.
  • Page 28 Teletext (option) TOP text (option) The user guide displays four fields-red, green, yellow and blue at the bottom of the screen. The yellow field denotes the next group and the blue field indicates the next block. Block / group / page selection 1.
  • Page 29 Teletext (option) Special teletext functions REVEAL Press this button to display concealed information, such as solutions of riddles or puzzles. Press this button again to remove the information from the display. SIZE Selects double height text. Press this button to enlarge the top half of the page. Press this button again to enlarge the bottom half of the page.

  • Page 30: Connection Of External Equipment

    Connection of external equipment You can connect additional equipment, such as VCRs, camcorders etc. to your set. Here shown may be somewhat different from your set. ANT IN 75‰ VIDEO (L/MONO)AUDIO(R) Aerial socket 1. Connect the RF out socket of the VCR to the aerial socket on the back of the set.

  • Page 31: Component In Sockets (Option)

    Connection of external equipment Component in sockets (option) 1. Connect the COMPONENT video output sockets (Y Cb Cr, Y Pb Pr or Y B-Y R-Y) of the COMPONENT (480i) to the COM- ANT IN 75‰ COMPONENT INPUT(480i) VIDEO (L/MONO)AUDIO(R) PONENT INPUT sockets (Y P ) on the set.

  • Page 32: Troubleshooting Check List

    Troubleshooting check list Symptoms No picture, no sound Sound OK, poor picture Picture OK, poor sound Picture blurred Lines or streaks in picture Poor reception on some channels No colour Poor colour Remote control does not work Check these items and try to adjust these The mains plug-(plugged in and switched on)
  • Page 33 MEMO...
  • Page 34 MEMO...
  • Page 38 FS4/FS6 series MENU 21/29FU1 series MENU 29FU3/29FU5 series...
