Installation & User Manual
EW5000
Outdoor Cooking Fire
IMPORTANT: Please read this manual before installing and using the ESCEA EW5000 Cooking fire. Failure to fol-
low these instructions may lead to a possible fire hazard and will void the warranty.
Safety
-
A lit fire must not be left unattended at any moment.
-
The fireplace must only be used for heating and cooking as intended.
-
Maintain and operate fireplace in accordance with these instructions.
-
Do not use flammable liquids and aerosols to start or rekindle a fire.
-
Do not place any combustibles in front of the fire as some firewood may spit sparks.
-
Do not touch the surfaces as they can be very hot, even after the fire has burnt out.
-
Ensure correct installation.
-
Do not modify the firebox and use only an ESCEA fascia.
-
Do not operate the fire without the fascia or flue system.
-
Young children should be carefully supervised when they are in the same area as the cooking fire.
Toddlers, young children and others may be susceptible to accidental contact burns. And must not
operate the cooking fire. A physical barrier is recommended if there are at risk individuals in the
house. To restrict access to a fireplace or stove, install an adjustable safety gate to keep toddlers,
young children and other at risk individuals out of the area and away from hot surfaces.
-
Take care when installing to prevent injury as this product is heavy.
1.0

Product Description:

The ESCEA EW5000 Wood Burning Cooking Fire is designed for outdoor use only. The fire is designed to
burn wood and charcoal only. This appliance requires a flue and must be installed into a non combustible
cavity.
1.1
Serial number can be found in the lower left of the fire underneath the receptacle for the fascia hooks, to
access this the fascia must be removed as detailed in section 5.0 of this manual.
1.2
Retain this manual for future reference.
630187_2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EW5000 and is the answer not in the manual?

Questions and answers

Related Manuals for Escea EW5000

Summary of Contents for Escea EW5000

  • Page 1 Take care when installing to prevent injury as this product is heavy. Product Description: The ESCEA EW5000 Wood Burning Cooking Fire is designed for outdoor use only. The fire is designed to burn wood and charcoal only. This appliance requires a flue and must be installed into a non combustible cavity.
  • Page 2 Face of the Wall Installation: The ESCEA EW5000 is for outdoor use only. Always check with your local city council for additional restric- tions prior to installation. Consider the topography of the land and the prevailing wind to ensure optimal performance before installation.
  • Page 3 The ESCEA EW5000 firebox and the flue system must be installed into a fully non combustible fireplace construction on all surfaces surrounding the fireplace, eg top/bottom/sides/back. Materials to be used can be e.g. solid concrete, concrete/masonry blocks, bricks or Hebel blocks/panels. Do not use timber framing.
  • Page 4 Placement of interior parts: TAKE CARE WHEN HANDLING ALL INTERIOR PARTS AS THEY ARE HEAVY AND MAY CAUSE INJURY IF DROPPED OR HANDLED INCORRECTLY. First remove the following parts secured inside the firebox for transit and remove and discard of all pro- tective packaging including white plastic end caps.
  • Page 5 Before fitting the fascia, the hooks must be attached using the screws supplied. The ESCEA EW5000 fascia is attached to the firebox by four ‘hooks’ on the corners of the fascia.
  • Page 6 Operating Instructions The first fire may produce odors from the paint. If possible light and maintain a small fire for a couple of hours, this will allow the paint to cure better. Always use paper, firelighters or finely split dry soft wood kindling to start a fire. Never use flammable liquid or aerosols and do not burn treated or painted wood, plywood, MDF or particleboard, as well as household rubbish, garden waste, plastics, waste oils, paint or construction or demolition waste must never be burnt.
  • Page 7 Warranty Provided the ESCEA EW5000 firebox is installed to the manufacturer’s specifications and operated in ac- cordance with these instructions, the warranty shall cover a period of 5 years from the date of purchase. Damage as a result of over firing or use of incorrect fuel such as flammable liquids and aerosols, is not covered in the warranty.
