ZS-6224 Series
USB-PIO Adapter
User's Manual
Zenisu Keisoku,Inc.
Zip code: 183-0027
2-13-37, Honmachi, Fuchu, Tokyo, Japan
TEL: +81-(0)42-368-2126
FAX: +81-(0)42-364-0067
URL
http://www.zenisu.co.jp/
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZS-6224P and is the answer not in the manual?

Questions and answers

Summary of Contents for Zenisu Keisoku,Inc. ZS-6224P

  • Page 1 ZS-6224 Series USB-PIO Adapter User’s Manual Zenisu Keisoku,Inc. Zip code: 183-0027 2-13-37, Honmachi, Fuchu, Tokyo, Japan TEL: +81-(0)42-368-2126 FAX: +81-(0)42-364-0067 http://www.zenisu.co.jp/ - 1 -...
  • Page 2: Table Of Contents

    ◆ Table of contents ◆ 1.Outline ..........................3 2.Specification ........................3 2.1.Operation environment ....................3 2.2.USB ........................... 3 2.3.Product specification ......................4 2.4.Relay ..........................4 2.5.Photocoupler ........................4 2.6.Appearance ........................4 3.Install ............................ 5 3.1.Device driver ........................5 3.2.Windows Vista ........................5 3.3.Windows XP/2000 ......................
  • Page 3: Outline

    1.Outline ZS-6224 is a unit built-in 4 relays and 1 photocoupler. It is possible to perform insulation between circuits, level conversion, etc, by connecting relays and photocoupler. 3.9KΩ ZS-6224 2.Specification 2.1.Operation environment : IBM PC/AT compatible machine (USB required)  :...
  • Page 4: Product Specification

    2.3.Product specification Model ZS-6224P ZS-6224S Feature Printed circuit boarded type Small case built-in type Data connector 50-core flat cable 50-core flat cable Power supply USB bus power (DC4.75V to 5.25V 100mA or less) USB bus power (DC4.75V to 5.25V 100mA or less) Environment Temperature 0℃...
  • Page 5: Install

    3.Install 3.1.Device driver Please download the device driver corresponding to each OS from our website below. http://www.zenisu.co.jp 3.2.Windows Vista In order to use this product, it is necessary to install hardware and device drivers. ① Turn on the power to the PC and start Windows. ②...
  • Page 6 Click “ There is no disc, try other method”. Click “Refer to the PC and search the driver software”. - 6 -...
  • Page 7 Refer to the downloaded file and click the “NEXT” button. The following screen will be displayed “It can not verify the publisher of the driver software”, but there is no problem. Click “Install this driver software”. - 7 -...
  • Page 8 Click “Close” button. The following screen will be displayed. Click “Search and install driver software”. - 8 -...
  • Page 9 Click “ There is no disc, try other method”. Click “Refer to the PC and search the driver software”. - 9 -...
  • Page 10 Refer to the download file and click the “NEXT” button. There is no problem. Click “Install this driver software”. - 10 -...
  • Page 11 Installation is completed, click “Close” button. - 11 -...
  • Page 12: Windows Xp/2000

    3.3.Windows XP/2000 In order to use this product, it is necessary to install hardware and device drivers. ⑤ Turn on the power to the PC and start Windows. ⑥ Connect the PC and this product with USB cable. ⑦ Install the device driver. ⑧...
  • Page 13 Select “Search for the driver in the following location”, refer to the downloaded driver and click the “NEXT” button. The following screen will be displayed, but there is no problem click “Continue” button. - 13 -...
  • Page 14 The following screen will be displayed if device driver installation is normally completed. Click “Finish” button. Since it may be required to restart depending on the configuration of the PC, restart according to the instructions on the screen. Even if you connect to the computer from the next time, these screen will not be displayed.
  • Page 15 Select “Search for the driver in the following location”, refer to the downloaded driver and click the “NEXT” button. There is no problem, click the “Continue” button. - 15 -...
  • Page 16 The following screen will be displayed if. Click “Finish” button. Since it may be required to restart depending on the configuration of the PC, restart according to the instructions on the screen. Even if you connect to the computer from the next time, these screen will not be displayed. - 16 -...
  • Page 17: Operation

    4.Operation 4.1.Preparation ZS-6224 uses API made by FTDI inc, depending on each programming language, include the following files. Visual Basic :D2XX_Module.bas Visual C++ :FTD2XX.H、FTD2XX.lib Delphi :D2XXUnit.pas 4.2.Function In order to control the relay and input the photocoupler, use the following function. FT_Open :Open the USB port.
  • Page 18: Ft_Setbitmode

    4.2.3. FT_SetBitMode  Function Set of I/O of 8 bits.  Format FT_SetBitMode (FT_HANDLE ftHandle, UCHAR ucMask, UCHAR ucMode) ftHandle :Set the handle number. ucMask :Set HEX(0F), 0:Input 1:Output In the ZS-6224, the upper 4 bits are input to the photocoupler and lower 4 bits are set to the relay output.
  • Page 19: Ft_Write

    4.2.5. FT_Write  Function Set the relay ON/OFF.  Format FT_Write (FT_HANDLE ftHandle, LPVOID lpBuffer, DWORD dwBytesToWrite, LPDWORD lpdwBytesWritten) ftHandle :Set the handle number. lpBuffer :Set“1” when the relay is ON, “0” is OFF, and execute Byte output. Bit assignments are as follows. 0 0 0 0 Relay_1 Relay_2...
  • Page 20: Connector

    5.Connector 57LE-40240-7700-FA Connector ( ) Signal Pin No. Signal Relay 1_COM Relay 3_COM Relay 1_NO Relay 3_NO Relay 1NC Relay 3_NC Relay 2_COM Relay 4_COM Relay 2_NO Relay 4_NO Relay 2_NC Relay 4_NC Photocoupler 1_IN+ Photocoupler 1_IN- Photocoupler 2_IN+ Photocoupler 2_IN- Photocoupler 3_IN+ Photocoupler 3_IN- Photocoupler 4_IN+...
  • Page 21: Warranty

    6.Warranty If it fails during normal use, we will repair it free of charge as described in this warranty as below. 1) During the warranty period which is one year from the date of purchase, we will repair it free of charge in case of malfunction in accordance with instruction manual. 2) It will be charged for extra in the following case, even during warranty period.
