- Page 1 INSTRUCTION MANUAL CLASSIC LINE SPÜLBOY Neptun T 2000 ® SPÜLBOY Twin Go T ® SPÜLBOY Twin Go T portable ®...
-
Page 2: Table Of Contents
Contents Dear SPÜLBOY customer, ® Foreword Thank you for your trust! We are delighted that you have chosen an Original SPÜLBOY quality product. Unit Description & Purpose Safety Instructions The globally established SPÜLBOY brand ® is well acknowledged internationally for: Exploded View, Spare Parts &... -
Page 3: Foreword
Foreword Safety instructions! • Continuously check the visual cleanliness of Please read the instruction manual before using your SPÜLBOY and keep it accessible for further the SPÜLBOY. • use and for all users. Check the connection hose and hose connections SPÜLBOY units may only be used by persons who are for damage, dirt or leaks familiar with the safety instructions. - Page 4 SPÜLBOY Neptun T 2000 ® brush head, standard brush head, large (optional) bayonet middle brush glass protection ring inlet pipe with one-way valve brush strip 2-step spray control valve suction foot with screw upper glass protection fully equiped connection hose 3/8“...
- Page 5 Spare parts Dimensions Neptun T 2000 H/B/T 330 mm / 330 mm / 190 mm Dimension Canister Ø 180 mm Internal glass height: middle brush with brush head, standard 235 mm Internal glass height: middle brush with brush head, large 251mm art.
- Page 6 SPÜLBOY Twin Go T/ Twin Go T portable ® brush head, large (optional) brush head, standard inlet pipe with one-way valve glass protection ring bayonet middle brush double ring shower brush strip 2-step spray control valve fully equiped connection hose suction foot with screw 3/8“...
- Page 7 Spare parts Dimensions Twin Go T/ Twin Go T portable H/B/T 375 mm / 330 mm / 190 mm Dimension Canister Ø 180 mm Internal glass height: middle brush with brush head, standard 235 mm Internal glass height: middle brush with brush head, large 251mm art.
-
Page 8: Operation & Start-Up
Operation & Start-up 5.1 Set-up & assembly 5.2 Start-up • • Install the SPÜLBOY in a counter sink with Before starting up your SPÜLBOY for the first time, a suitable tap water connection and drain. after a prolonged period out of use or after repairs, Fasten the enclosed connection hose to the unit. -
Page 9: Rinsing & Post-Rinsing
Washing 6.1 Pre-washing 6.2 Rinsing & Post-rinsing • • Check each receptacle / glass to be cleaned for Place the glass on the telescopic rinsing unit and carefully rinse it from the inside and any drink residues or other foreign bodies (e.g. lemon slices, straws) before starting the washing outside. -
Page 10: Cleaning, Care & Maintenance
Cleaning, care & maintenance • Make sure that you continuously check and keep the glass washer and the surrounding area clean, even when it is being used. The cleanliness of the unit, brushes and surrounding area should be checked at least once an hour. •... -
Page 11: Disposal & Recycling
• Improper cleaning • Inappropriate use • Destruction of the unit by force • Dismantling of a canister from the base • Dismantling of one or both spray pipes (Neptun T 2000) • Use of caustic and/or chlorinated active ingredients... - Page 12 Visit us at www.spuelboy.de Schäfer Produkte GmbH Simonshöfchen 53 42327 Wuppertal/ Germany Tel: +49 (0) 202 695 32-0 E-Mail: info@spuelboy.de www.spuelboy.de...
