Zephyr 1
Day/Night Thermostat
Easy Guide
Note: This unit has been set to perform cooling function.
For heating function, refer to Optional settings.
VANCOUVER, W ASHINGTON U.S.A.
INSTRUCTIONS – REV. A
Day
temp
Step 1
Set values for Day and Night temperatures
OPTIONAL SETTINGS
B
A
C
Change to heating
A. Set both values to minimum
B. Plug in, then set both values to maximum within 5 seconds
C. Output light turns on
D. Follow instructions as shown in Step 1 & 2
Light sensor
(photocell)
Night
temp
Step 2
Plug into 120VAC outlet
Place the sensor at desired location
Connect the heating or cooling element in the front panel outlet
Installation is now complete
B
Change to cooling
A. Set both values to maximum
B. Plug in, then set both values to minimum within 5 seconds
C. Output light turns on
D. Follow instructions as shown in Step 1 & 2
www.titancontrols.net
For technical assistance call us at
1-888-80-Titan or 1-888-808-4826.
Sensor
B
A
C
®
