Page 1: Table Of Contents
Table of Contents Introduction Recording Safety Precautions -Voice Recording List of Items -Line-IN Recording from external audio source Product Introduction FM Radio mode -Basic Functions -Searching FM Frequencies -Parts Names -Storing the selected frequency -Menu Configuration -FM Turner and Recording Delete How to use manager program -Delete File or Folder...
Page 2 14hours non-stop play from 2 hour USB Charge. Xuke also provides GUI (Graphical Users Interface) and Firmware Upgrade that allow the user operate various functions more easily and quickly. Please visit our worldwide web-site at www.stormblue.co.kr and upgrade your firm-ware with the newest firmware function.
Page 3 Cautions <To maintain good performance> Avoid high or cold temperature and moisture. Do not drop or cause impact the product. have other Avoid direct sunlight, high different things in the temperature from heating product. device. Avoid placing Never disassemble, product under high repair or rebuild...
Page 4 <Safety > - Do not shake or apply heavy shocks on the product It might be the cause of malfunction or damaged -Avoid contacting the product with water This may cause serious damage to the product. If the player gets wet, wipe with a soft towel or rag as soon as possible.
Page 5 Included Accessories Earphones USB Cable Audio Cable User’s Manual Install CD Neck Strap Arm Band Carrying Case (Optional) (Optional) * Items can be changed without notice to increase the performance or quality of the product.
Page 6: Product Introduction
Product Introduction -Feature Multi-Codec Player Supports both MP3 and WMA file format Firmware Upgrade Firmware download are available to easily upgrade the newest functions on this product. Multi Languages Support with Graphic OLED Display localized file names in 35 languages with graphic OLED screen. FM Radio Listen and Record Worldwide range/Auto-search/user defined pre-set frequencies 7-Mode EQ...
Page 7 ① Play Mode (LCD Display) ② Artist & Music Title ③Played Time Display ④ ⑤ ⑥ ⑦ ⑧ ④ EQ ⑤ Play Speed ① ① ⑫ ⑥ Lock ② ⑦ Total Number of Music File ⑧ Current Track Number ③ ⑨...
Page 8 -MENU Structure Repeat Folder -Normal -FLAT -FOLDER 1 -FOLDER ALL -Rep 1 -POP -Rep All -ROCK -RANDOM -LIVE -Intro -CLASSIC -VOCAL -DBASS Play Speed FM BAND System Setup -SLOW -KOR/US -LCD Contrast -NORMAL -EU/CHA -Backlight Time -JAPAN -VOICE REC Setup -AUDIO REC Setup -OFF Time Setup -Format...
Page 9 Software Installation 1) For Windows 98/SE The software should be installed before using the product. For Firmware Upgrade, install Upgrade program after installing Windows 98/SE driver. 2) For Windows 2000/ME/XP The software only needs to be installed for format the player...
Page 10: How To Use Manager Program
-Installing Software to PC - Insert the provided CD in the CD-ROM of PC and follow the below instructions. Below screen will be appear. If it does not run automatically, run “Setup.exe” file from the install CD [Manager program] * For Windows 98/SE In Windows 98/SE, USB MP3 Disk cannot be recognized in the PC without USB Drive installation.
Page 11 1. When the installation is finished, ‘X-Manager for MP3’ icon is created in the Window and the following program appears. [ICON] [X-Manager Program] newest Firmware Font Data download available from web-site ( www.stormblue.co.kr). 3. ① Firmware download : Click ‘Upgrade Firmware’ button and download the upgrade file to a folder you want.
Page 12 *Warning) During the upgrade work, do not disconnect or execute other programs on the same PC. If so, fetal errors may occur in the PC or product. ②Font Upgrade: For font upgrading, click ‘Upgrade Font’ button and download the upgrade file to a folder you want.
Page 13: File Download/Upload
Open the cap of the player and connect the USB Port to the USB Port on PC. 2. Connecting the player to a PC using a USB Cable Connect one end of the provided USB Cable to one of the USB Port on the PC, and connect the other end of the player.
Page 14 2. Select the new folder with Right click on mouse. 3. New folder is created. Try the desired name in the new folder.
Page 15 * Downloading the files or folders from PC to the player 1. Select the files or folders on the PC to transfer to the player. 2. Select the desired folders or files on the player.
Page 16 Transferring 3. Download is completed to the player. *Deleting the files or folders on the player 1.Select the files to delete.
Page 17: Formatting
2.Select “DELETE” from MENU mode. A warning message “Are you sure?” is displayed on the LCD. Choose “YES” to delete. 3.Deleted is completed. -Formatting Move to the Windows Explorer and select the removable disk to click file formatting. Note: Format will delete all files in the player. Back-up the important data before formatting and...
Page 18: Disconnecting From Pc
format with only FAT16 region. FAT32 is not supported. -Disconnecting from the PC Before disconnecting the player from the PC, double click on the green arrow icon the toolbar located at the bottom right of the screen. Click on the stop USB Mass Storage Device. , When the dialogue box “...
Page 19 Press Power ON/OFF (MODE SW) button over 1 second will turn the power on. Press the same button again over 1 second will turn the power off. * NOTE: The power will turn off automatically if there is no action in Stop mode within the configured Auto Off time 2.
Page 20 - Press Power ON (MODE SW) button shortly to enter the MODE (Play, FM, Encoding, Voice Recording) Click Click - Press and hold the ▶/■ (Play/Stop) button and move to Setup Menu. Long Click Click...
Page 21 Play Mode -Listening MP3 File Press and hold the Power ON (MODE SW) button to turn the player on. * NOTE: The capacity will be displayed as shown below. The player will be started at the last position. Long Click Display the Capacity Select the desired file to listen by using the jog key to ◄◄...
Page 22 Key Function in the play mode Press length Activation Briefly ☞ Pause the playing file and move to Navigation Mode ▶/■ (Play/Stop) Over 1 Sec ☞ Move to MENU Mode Briefly ☞ Increase or decrease the volume level step by step Volume +/- Over 1 Sec ☞...
Page 23 FM Radio Mode NOTE: Earphone should be inserted into the Player to receive FM frequency since the earphone works as an antenna Press the Power ON/OFF (MODE SW) button to select FM Mode. Click Mode Select Click FM frequency is displayed as below. FM Mode Use the jog key to ◄◄...
Page 24 Key Function in FM Mode Press length Mode Activation Short ☞ Select the SCAN Mode/ PRESET Mode ▶/■ Record ☞ Pause the current FM recording (Play/Stop) Long ☞ Move to MENU Mode Short ☞ Increase or Decrease the Volume level Volume +/- Long ☞...
Page 25 -Playing Voice and recorded FM file (Playing Voice file) Press the ▶/■ (Play/Stop) button to stop the current operation. Click Move to the VOICE folder and select the file to listen by using the Volume(+/-) jog key. Note: The recorded file is stored as “VOICE001” “VOICE002” in the Voice folder. (+)Up (-)Down 3.
Page 26: Recording -Voice Recording
Recording -Voice Recording 1. Press the Power ON (MODE SW) button. Click 2. Select Voice Recording Mode by using the jog key to ◄◄ or ►► REW(◄◄) FF(►►) 3. Press the ▶/■ (Play/Stop) button and move to Recording Mode. Click 4.
Page 27 5. Press the ▶/■ (Play/Stop) button to stop recording. (The recorded file is stored as “VOICE001” “VOICE002” in the VOICE folder) -Line-in Recording 1.Connect LINE OUT jack of the external audio source and the Line-IN jack of the player with a audio cable as below.
Page 28 4. Press the ▶/■ (Play/Stop) button and enter Line Encoding mode. Click 5. Press the AB/REC button and voice recording starts. *NOTE: Press the AB/REC button to pause the recording process. Press the AB/REC button again to restart recording. Click 6.
Page 29: Fm Radio Mode
FM Radio Mode (Listening & Recording) *Press the Menu SW (Jog SW) and select the scan or preset mode. NOTE: Earphone should be inserted into the Player to receive FM frequency since the earphone works as an antenna -Turn to the desired frequency Use the jog key to and search the desired frequency.
Page 30 2. Use the jog key to ◄◄ or ►► to select the channel. REW(◄◄) FF(►►) 3. Press and hold the A-B button for 1 to 2 seconds. *CH is displayed on the LCD as below. Long Click 4. Select the desired CH by using the jog key to ◄◄ or ►►. Press and hold the REC/A-B button to store the selected channel.
Page 31 2. The saved channels are displayed as shown below by using the jog key to ◄◄ or ►►. Click REW(◄◄) FF(►►) -Record FM Radio Press the Power ON (MODE SW). Short Click Select FM Radio mode by using the jog key to ◄◄ or ►►. REW(◄◄) FF(►►)
Page 32 3. Press the ▶/■ (Play/Stop) button and select FM RADIO Mode. 4. Press and hold the AB/REC button and the recording starts. Long Click 5. Press the AB/REC button to pause the recording process. Press the AB/REC button again to restart recording. Click 6.
Page 33: Delete
Delete - Delete Files or Folders of the player Select the files or folders to delete by using the Volume(+/-) buttons. (+) Up (-) Down 2. Press and hold the AB/REC button to delete. “Erase?” is displayed on the LCD. Long Click 3.
Page 34: Additional Function
<Additional Function> -REPEAT Mode 1. Press and hold the ▶/■ (Play/Stop) button. Long Click 2. Use the jog key to ◄◄ or ►► to select the Repeat Mode. REW(◄◄) FF(►►) 3. Press the ▶/■ (Play/Stop) button to select the Repeat Mode. Click Select the desired Repeat Mode.
Page 35: Select Eq
-Select EQ 1. Press and hold the ▶/■ (Play/Stop) button. Long Click 2. Use the jog key to ◄◄ or ►► to enter the EQ Mode. REW(◄◄) FF(►►) 3. Press the ▶/■ (Play/Stop) button to select the EQ type. Click Select the desired EQ type Play the music file with Flat Mode Play the music file with Pop Mode...
Page 36 -Folder Mode 1. Press and hold the ▶/■ (Play/Stop) button. Long Click 2. Use the jog key to ◄◄ or ►► to enter the Folder mode. REW(◄◄) FF(►►) 3. Press the ▶/■ (Play/Stop) button to select the folder mode type. Click -Play Speed 1.
Page 37: Fm Band Setting
2. Use the jog key to ◄◄ or ►► to enter the Play Speed Mode. REW(◄◄) FF(►►) 3. Press the ▶/■ (Play/Stop) button and select the Play Speed type. Click -FM BAND Setting 1. Press and hold the ▶/■ (Play/Stop) button. Long Click 2.
Page 38 3. Press the ▶/■ (Play/Stop) button and select the suitable FM Band type. Click KOR/US Korea, USA and others (87.5MHz~108MHz) EU/CHA Europe Japan (76MHz~90MHz) -Navigation Mode 1. Press the ▶/■ (Play/Stop) button to stop the current operation. Click 2. Select the desired folder by using the Volume(+/-) buttons. (+)up (-)Dwon 3.
Page 39 4. Move to the upper or sub folder by using the jog key to ◄◄ or ►► REW(◄◄) FF(►►) -Repeat A-B Mode Play a particular section of the current file repeatedly. 1. Press the AB/REC button at the beginning position of the block to be repeated. The “A” icon is displayed as shown below.
Page 40 System Setup 1. Press and hold the ▶/■ (Play/Stop) button. Long clik 2. Select the System Setup Mode by using the jog key to ◄◄ or ►► REW(◄◄) FF(►►) 3. Press the ▶/■ (Play/Stop) button and choose the Mode to change. Click Backlight Time Set the time for which the backlight is turned on...
Page 41 Set the transmission rate of the recorded voice files - 6Ks/TVF, 56K/MP3, 64K/MP3, 80K/MP3, 96K/MP3, 112K/MP3, 128K/MP3 Set the transmission rate of the recorded file from external audio sources. - 128KBps, 160KBps, 192KBps When the operation is paused or stopped, System turns off power automatically.
Page 42: Product Specification
Product Specifications Item Detail Specification Supported Audio Format MPEG 1/2/2.5 Layer 3, WMA Mp3/Encoding Equalizer POP / ROCK / CLASSIC / VOCAL/LIVE/FLAT/DBASS FM Frequency range 76 ~108 MHz FM Tuner FM Signal band noise ratio 50dB Frequency storage Preset 20 units Compression Bit Rate 32kbps ~ 224kbps Voice Recorder...
Page 43: Troubleshooting
Troubleshooting - Check the following list before requesting A/S. - Lock is in the HOLD position? (Release the hold) The Player does not - The batteries are exhausted? (Recharge the batteries) power on - Check whether VOLUME is set to “0” . - Make sure that there are MP3 files in the memory No sound is heard from player or distortion is...
Page 44: Warranty
We do not reissue warranty certificate. Please store it in a safe space. Product Model Name Name Customer Address Name Purchaser Address Date of Purchase Mo____/Day____/Yr______ Period of Warranty * For more warranty information and RMA service, please visit our web-site at http:// www.stormblue.co.kr...
Page 45 Note: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
