Kajeet SmartBus™ 900
Quick Start Guide
1
Setting Up the Router
NOTE:
All SIM cards are pre-installed.
A. Screw in paddle antenna (A) to the MAIN port.
B. Screw in second paddle antenna (B) to the AUX port.
C. Screw in the GPS antenna (C) to the GPS port (if purchased).
D. Screw in two Wi-Fi antennas (D) to the 2.4/5Ghz ports.
E. Plug either the DC Power Supply cord or the AC Power
Supply cord in the 4-pin square (details on the back).
Router LED Light Explanation
Power: Green = Powered on
Wi-Fi: Green = On and operating normally
GPS: Blue = GPS locator is on
B
A
D
E
Modem: Solid Green = Active Connection
Signal Strength: Blue = 4 solid bars is the strongest signal
C
GPS Antenna
Paddle Antenna
(A & B)
(C)
Wi-Fi Antenna
(D)
Advertisement
Related Manuals for Kajeet SmartBus 900
Summary of Contents for Kajeet SmartBus 900
-
Page 1: Quick Start Guide
Kajeet SmartBus™ 900 Quick Start Guide Setting Up the Router NOTE: All SIM cards are pre-installed. GPS Antenna Paddle Antenna (A & B) A. Screw in paddle antenna (A) to the MAIN port. B. Screw in second paddle antenna (B) to the AUX port. -
Page 2: Power Options
If you did not request a custom configuration, the login information is: AC Power Supply NOTE: SSID: Kajeet SmartBus Password: smartbus This is for use in any location with an outlet. Plug the cord in to the 4-pin square. Plug the opposite Need the admin password? Please contact end into an outlet.
