User manual
m-DZ3600 — Digital Time Switch
Scope of supply
• Digital time switch
• User manual
Specifications
Power supply:
Maximum power:
Minimum setting time:
Operating temperature:
Reserve battery:
General Information

To ensure that you can enjoy this product for many years to come, please
read this manual and store it in a safe place. With this time switch, you can
conveniently and easily control electric devices that are to be activated at a
certain time or over a longer time period.
1
230V~50Hz
16(2)A, 3600W
1 minute
-10°C to +40°C
>
NiMH 1,2V 100h
LCD display
MASTERCLEAR button
Configuration buttons
Device connection
Commissioning
1. Remove the product from the packaging and remove any remaining 1.
packaging material.
2. 2. Connect the time switch to the desired socket. Make sure that the volta-
ge matches the specifications of the time switch.
3. Switch on the socket and wait approximately 12 hours, to ensure that the 3.
reserve battery is fully charged.
4. 4. After 12 hours, press the MASTERCLEAR button with a pointed object to
reset the time switch.
5. 5. You can now make the desired settings, the device is now operational.
Setting the time
1. 1. Press and hold the CLOCK button while simultaneously pressing the
WEEK button, until the current day of the week appears on the display.
2. 2. Adjust the time using the HOUR and MINUTE buttons, while the CLOCK
button is still pressed.
3. As soon as you release all buttons, the settings for the day and time are
3.
accepted.
Further settings and functions that are available with this time switch:
• 16 different combinations of the weekdays, adjustable as required
• 8 configurable switching programs
• choice of 12 or 24 hour mode
• summertime
• manual ON/OFF switch
• random delay of switching programs from 0-32 minutes
m-DZ3600
Digital Time Switch
