Deteknix QuestPro User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
QUESTPRO
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QuestPro and is the answer not in the manual?

Questions and answers

Related Manuals for Deteknix QuestPro

Summary of Contents for Deteknix QuestPro

  • Page 1 QUESTPRO ®...
  • Page 2 IN THE BOX QUICK START 1. Controller 2. Armrest 3. Pro headphones 4. Magnetic USB charge cable 5. Audio adaptor 6. Screen protector 7. Rod set 8. 9.5x5.5 BladeS coil and cover 9. 11x9 RaptorS coil and cover...
  • Page 3 BREAKDOWN QUICK START 1. Control box 2. Magic Grip handle pieces 3. Search coil 4. Armrest 5. Upper rod (aluminum) 6. Middle rod (aluminum) 7. Lower rod (plastic) 8. Coil bolt 9.Coil cover. 10. (A) Lower Camlock (B) Upper Camlock 11.
  • Page 4 ASSEMBLE QUICK START...
  • Page 5 ASSEMBLE QUICK START Install the coil.

  • Page 6: Power On/Off

    POWER ON/OFF QUICK START 1Sec...
  • Page 7 CHARGE QUICK START 04:00Hr FULL...
  • Page 8 AUDIO QUICK START WHEN USE LOUD SPEAKER TO USE PRO OR WIRE HEADPHONES HEADPHONES 1Sec On/Off 4SEC MUTE／MAX VOLUME VOLUME On/Off...
  • Page 9 SENSITIVITY QUICK START Many things such as Power lines, Electric fences even buildings can cause Electrical Interference & Falsing when your detector is in use and there is no metal under the coil. Users can reduce the sensitivity by +／ pressing on the downward triangle ONE LEVEL button directly.Users can increase...
  • Page 10 Lower conductive such as Iron show lower on the scale usually under 25. The QUESTPRO comes with up to 40 bars of metal ID indication. Users can select or deselect specific metal I.D.s to discriminate out undesired metal objects.
  • Page 11 PROGRAM Level-up After powering on the detector to scroll through the various Programs, press and hold the Ground Balance button while at the same time scrolling with the Triangle buttons to arrive at the Programs you want. 1 and 2 are left for customize users own program.
  • Page 12 PINPOINTING Level-up By pressing on the PINPOINT button(the round button with cross sign), the detector will enter a non-motion mode and alarm to target without moving the coil. Users can use this function to pinpoint target with cross action as illustrated. The target depth will be indicated through the right bars.

  • Page 13: Ground Balancing

    GROUND BALANCING Level-up The QUESTPRO comes with Ground Balancing (GB) function. We recommend GB every time you change the detecting area. Make sure you have no metal targets under the coil while GB. When successfully ground balanced the matrix display will show GC RESULT.
  • Page 14 TONE Level-up TONES.Users can select different TONES by their own preference and different detecting conditions. TONE SPACE. Users are be able to set where to start the middle tone and high tone. When TONE SPACE menu been selected, use UP/ DOWN buttons to choose the point.
  • Page 15 BANDS Level-up BANDS: the frequency of transmitter. The QuestPro comes with 5kHz, 13kHz, 20kHz three selectable frequencies. We are keep working on better algorithm for different frequencies. We will push to our QuestGo APP to let you know when they are available.

  • Page 16: Installation

    Store for iPhones or GooglePlay store for You can use your Facebook account to login Loggin to enter the APP. Or just click Bluetooth before connecting to the QuestPro. Android phones. System requirement: or by email. After type in Email and Password Facebook account.
  • Page 17 Interface 1. Time counter. 2. START button. 3. GPS 1. Click this Plus in circle button to add post 1. Your profile avatar 2. Counting for recent 1. Bar chart of your activity 2. Finds signal gauge. 4. Distance counter. 5. Finds. in Group.

  • Page 18: Key Functions

    1. triangle button to return to products. Users Info: to set or change users your QuestPro to the APP. Simply open the pause the detecting for taking pictures or work, or by 2. button to end this session. You email or facebook account,change password.
  • Page 19 Mapping & Firmware Upgrading Tracking Mapping You can also use the APP without QuestPro The Green Pin Symbol shows the start metal detectors. The target ID won’t show point. The Red Pin Symbol shows the up on the tracking and mapping page.
  • Page 20 Sharing You can go to Personal----> Find to view your You can share directly on the group page as Your can select the area or drag up or down Click Share and the post is added to the history quests. Click any one to view the well.

  • Page 21: Troubleshooting

    TROUBLE SHOOTING ？ NOT POWER ON No power, please recharge. Or contact with your dealer NO ALARM Coil not connect to the control box VERY NOISY Please find another place with less interference NO SOUND Make sure the Volume is not ZERO level FALSING WHEN Please confirm the coil cable is not broken or avoid to hit the coil edge to hard objects.
  • Page 22 PRODUCTS CARE NOTICE! Do not twist the coil tail and connector to avoid wire damage. NOTICE! Do not store the device where prolonged exposure to extreme temperatures can occur to avoid device damage. NOTICE! Never use a hard or sharp object to operate the touch pad, or damage may result. NOTICE! Avoid chemical cleaners, solvents, and insect repellents that can damage plastic components and finishes.
  • Page 23 If you have 1 Why did you decide to buy a Deteknix difficulty to register online please contact with your dealer to detector? finish the process. Or, mail this part to following address:...

  • Page 24: Warranty

    Date Of Purchase Serial Number WARRANTY Title The Quest metal detectors is warranted against defects in Surname materials and workmanship under normal use for TWO years from the date of purchase to the original owner. First Name This warranty does not cover: •...
