Marantz professional AUDIO SCOPE SG-5BC User Manual

Box Contents
Contenido de la caja
Contenu de la boîte
Contenuti della confezione
Lieferumfang
Battery Installation
Instalación de la batería
Installation de la pile
Installazione della batteria
Batterieinstallation
1
2
Polar Pattern
Patrón polar
Diagramme polaire
Figura polare
Polardiagramm
Marantz is a trademark of D&M Holdings Inc., registered in the U.S. and other countries. All other product or
company names are trademarks or registered trademarks of their respective owners. Manual Version 1.0

User Guide

Guía del usuario
Guide d'utilisation
Technical Specifications
Especificaciones técnicas
Spécifications techniques
Specifiche tecniche
Technische Daten
Type
Polar Pattern
Frequency Response
Sensitivity
Impedance
Equivalent Noise
Maximum SPL
Signal-to-Noise Ratio 60 dB
Power Requirement
Dimensions
Weight
Frequency Response
Cardioid
Respuesta en frecuencia
(1 kHz)
Réponse en fréquence
Risposta di frequenza
Frequenzgang
Supercardioid
(1 kHz)
Guida per l'uso
Benutzerhandbuch
Electret condenser microphone
Cardioid, Supercardioid
70–16000 Hz
-70 dB (±3 dB; 0 dB = 1 V/μbar @ 1 kHz) (cardioid)
-56 dB (±3 dB; 0 dB = 1 V/μbar @ 1 kHz) (supercardioid)
1000 Ω (+30%; @ 1 kHz) (cardioid)
2200 Ω (+30%; @ 1 kHz) (supercardioid)
< 34 dB
120 dB (THD α 1%, 1 kHz)
(1) AA battery, not included
11.9" x 0.9" / 302 x 22 mm
0.38 lbs. / 0.17 kg
marantzpro.com
(length x diameter)
Cardioid
Supercardioid
