Summary of Contents for Mobi-Chair BW-100
- Page 1 MOBI-CHAIR ® ASSEMBLY, OPERATION AND SAFETY MANUAL 75 Kingsland Avenue - Suite 1 Clifton, NJ 07014, USA Tél. + 1 973 928 3040 - Fax. + 1 973 928 3041 info@mobi-mat-dms.com...
-
Page 2: Table Of Contents
Foreword Thank you for purchasing a Mobi-Chair. This manual includes wheelchair operating limits and how you or your assistant can assemble your wheelchair, perform maintenance operations and make any adjustments. This model is designed with benefits and features to meet cus- tomer’s demands in their daily life. -
Page 3: Operating The Wheelchair
Operating the wheelchair The wheelchair is well suited for normal weather conditions and firm surfaces. For safety purposes, please avoid using the wheelchair in adverse weather and other poor conditions. 1 -1 User indications Operating the wheelchair may injure the user or damage the wheelchair if the user is unable to have full control. If the user is not mentally or physically able to keep full control of the vehicle at all times, an attendant must be present when necessary. Safety and Operating information This manual references the most common procedure. Techniques of safe operation and maintenance of the wheelchair are mentioned as well. In order to handle your wheelchair safely, please follow all detailed instructions given in the manual. -
Page 4: General Inspection
Mobi-Chair will not turn over if the user sits sturdily. However, for safety and requi- rement by law, a life jacket is to be worn by the user. The Mobi-Chair is not intended for areas with currents or strong waves. -
Page 5: Standard Components
Standard Components 4 Standard Components A. Chair Frame (1) B. Floating armrest (2) C. Rear tires (2) D. Front tire (1) 5/12... -
Page 6: Assembling The Chair
Assembling the chair 1. REAR TIRE INSTALLATION • Lay the chair frame on the ground such that the back of the chair and the Mobi- Chair logo are facing up. *To fold the chair, pull the chain located under the seat and push the back of the chair forward. - Page 7 2. FRONT TIRE INSTALLATION • Insert rod of the small tire into the front of the chair frame Main tube hole (2) Ring lock (3) • Make sure the pin is properly aligned in the chair frame and that it “clicks” in place to secure the tire.
- Page 8 3. ARMREST INSTALLATION • Open chair frame in upright position • Insert back rod on armrest into the back- rest of the chair frame by pressing down the pins. Make sure the pins are aligned properly and secure • Turn the black knob on the seat of the chair to create an opening for the front of the armrest •...
- Page 9 INSTALLATION COMPLETE *STORING THE MOBI-CHAIR: You can easily store the Mobi-Chair without removing all of the components. • To close the chair for storage, simply detach the front of the armrests by unscrewing the black knobs located near the seat.
-
Page 10: Pre-Use Checks
Pre-use checks Failure to carry out these checks before using the product may result in damage to the beach whee- lchair and/or injury to the user. Before using, please check the following points: CAUTION ! - If there are any faults or malfunctions, do not use the beach wheelchair and contact your retailer. Tire condition Tire pressures are affected by changes in temperature and altitude. Check and adjust them whenever you are using the chair in areas where there are large variations in temperature or altitude. -
Page 11: Controls
6-3 Controls Check the frame, fork, folding system and tire/armrest condition and ensure that they function correctly. valve Maintenance To ensure that your mobi-chair stays in good condition, the mobi-chair should be rinsed with fresh water after EVERY use. The connecting plates and rods must be rinsed thoroughly to remove all sand, salt and dirt from the mobi-chair. Failure to clean the connecting parts of the mobi-chair may result in creating forms of corrosion of the product. All connecting rods should be greased at the user’s discretion to ensure that the product remains in good condition. 11/12... -
Page 12: Specification
Rubber & PA+GF 16’’ Seat Fabric PVC Weight Capacity 135Kgs (300lbs) Product Weight 27,4Kgs (60lbs) Drawing Name Drawing By Edition Scale Project Drawing No Revision Approved 1 / 10 O1000001 BW-100 BEACH BUGGY Checked By Approved Unit Date Material 2009/12/02 12/12... -
Page 13: Warranty
Condition: With regards to the original purchaser/user only, Mobi-Chair warrants the frames to be free from defects in mate- rials and workmanship for a period of one (1) year from date of purchase; all remaining components for one (1) year from the date of purchase except upholstered materials, padded materials and tires/wheels. This warranty does not include any labor or shipping charges incurred for replacement, part installation or repair of any such product. Mobi-Chair’s sole obligation and your exclusive remedy under this warranty shall be limited to such repair and/or replacement. For warranty service, please contact the dealer from whom you purchased your Mobi-Chair product. In the event you do not receive satisfactory warranty service, please write directly to Mobi- Chair at the address on the last page of the instruction manual. Provide the dealer’s name and address, date of purchase, indicate the nature of the defect and, if the product is serialized, indicate the serial number. Do not return our products to our factory without our prior consent. - Page 14 75 Kingsland Avenue - Suite 1 Clifton, NJ 07014, USA Tél. + 1 973 928 3040 - Fax. + 1 973 928 3041 info@mobi-mat-dms.com...
