TEMP TRAQ TT-100 User Manual

Introduction to TempTraq

Welcome to TempTraq

Intended Use

TempTraq is a Bluetooth
®
disposable patch. The patch senses, records and transmits body temperature via Bluetooth
Version 4.0. Temperature information from the patch is monitored using a smart device
(Apple or Android™ with Bluetooth
®
TempTraq measures under-the-arm "axillary" temperature and this is converted to an oral
temperature which is displayed in the TempTraq app.

Indications for Use

The wireless thermometers are battery-operated electronic devices with intended use of
measuring human body temperature precisely. These devices are single-use and intended
for armpit temperature measurement for persons of all ages.

Warnings and Precautions

When using this product always follow these basic safety precautions to ensure that the
patch accurately reads temperature and to avoid skin irritation. Failure to follow these
precautions could result in inaccurate temperature readings resulting in delay in treatment,
or could result in skin irritation and mild discomfort.
DO NOT use the patch for any other purpose besides measuring human body
temperature.
DO NOT place the patch over wounds, sores or abrasions.
DO NOT excessively bend or twist the TempTraq patch.
DO NOT immerse the patch in water. Patch may be removed for a bath or shower
and then re-applied afterwards.
DO NOT use the patch if it has been damaged or immersed in water.
DO NOT attempt to take apart the patch; there are no user serviceable parts.
DO NOT wear TempTraq during an MRI scan. TempTraq has not been evaluated for
safety and compatibility in the MR environment. It has not been tested for heating,
migration, or image artifact in the MR environment. The safety of TempTraq in the
MR environment is unknown. Scanning a patient who has this device may result in
patient injury.
DO NOT wear TempTraq during an X-ray scan. Wearing a TempTraq patch during
an X-ray scan may block visualization in the application area.
Patch adhesive may irritate sensitive skin or cause allergic reactions. Contact your doctor if
irritation or allergic reactions persist.

For Best Results

• Clean and dry skin to remove deodorants or lotions, which can reduce adhesion of the
patch.
• The sensor - marked "underarm" - must be positioned high and in the center of the
armpit. Hold the arm at a 45° angle when applying the patch so that the center of the
armpit is easy to identify.
• Wait 8 minutes for the patch to warm up to body temperature.
• Maintain the placement of your arm along the side of your body to ensure an accurate
temperature reading. Temperature measurements can be affected by cold or hot
ambient temperatures if the arm is not at the side.
• Communication from the patch to the smart device is possible up to a distance of 40
feet (12 meters) but may be affected by objects between the patch and smart device.
• Individuals with high BMI may inadvertently cover the patch antenna with their arm
reducing the read range of the patch.
• For improved reception of temperature data from the patch, keep the phone awake,
and try moving it closer to the patch.
1. Download and Install App
The TempTraq app can be downloaded from
the App Store or Google Play™ store.
SM
3. Clean the Area
Clean and dry skin to remove deodorants or
lotions.
Key for obtaining accurate temperature measurements
5. Apply Patch
Apply the patch directly under the arm on either
side of the body with the sensor - the corner marked
"underarm" – high and in the center of the armpit
( ) . Hold the arm at a 45 degree angle away from
the side when applying the patch so that the center of
the armpit is easy to identify. If applied correctly the
TempTraq logo will be in an upright position. Patch
may be removed and re-applied if needed to position
the patch correctly.
Key for obtaining accurate temperature measurements

TempTraq Temperature Measurement

TempTraq measures under-the-arm "axillary" temperature and this is converted to an oral
temperature which is displayed in the TempTraq app.

Fever Guidance

The TempTraq app uses color coding to aid the user:
GREEN
ORANGE
RED
Troubleshooting Guide
Problem
Patch ID is not visible
in the Select Patch
list when adding the
patch
App is showing "No
temperature data
received in last 60
minutes..."
Temperatures from
the patch are lower
than expected
Temperatures from
the patch are higher
than expected.
No audible alert is
received from the
smart device when
there is an alert.
No alert is received
when temperature
measured by the
patch exceeds the
user set alert level
App displays "Patch
Error"
App displays "Rapid
temperature drop
detected..."
Model Number
Operating Time (hrs.)
Important: Read instructions carefully before use.
High, prolonged fever requires medical attention.
If symptoms persist, contact your healthcare provider.
, continuous temperature monitoring.
®
continuous temperature monitor in the form of a one-time use,
®
®
indicates a temperature is in the normal range.
indicates a possible fever of 100.4°F (38.0°C) or higher.
indicates a temperature equal to or higher than the alert
temperature that you selected.
Troubleshooting Hints
• Patch may not be activated. Press button on patch to activate.
• TempTraq only requires a single press of the "ON" switch to start operation.
Avoid repeated pressing of the "ON" switch which may damage the circuit
and cause TempTraq to fail.
• Move the smart device running the TempTraq app closer to the patch. The
patch can send temperature data up to 40 feet (12 meters). This distance is
reduced by walls and objects between the patch and the smart device.
• For improved reception of temperature data from the patch, keep the phone
awake, and try moving it closer to the patch.
• Check to make sure that the patch is properly positioned with the sensor
- marked "underarm" - correctly positioned in the armpit as shown in the
instructions for use.
• Lower than expected temperature readings can also be caused by exposure
to cold ambient temperatures, for example, when the arm is raised.
• Confirm the patch is correctly reading temperature by measuring oral
temperature with a digital thermometer.
• Confirm the patch is correctly reading temperature by measuring oral
temperature with a digital thermometer.
• Check to ensure that the phone volume is set to an audible level and is not set
to mute.
• Check settings for the app to ensure that notifications are enabled and sound
is enabled for notifications.
• Note that the audible alert only sounds for a short period. The visual
notification remains active in the app until canceled by the user.
• Check to make sure that the smart device running the app is in range of the
patch. A temperature alert will not be generated if the smart device is not
receiving data from the patch.
• Check to ensure that the app is running. No alerts will be generated if the app
is not running.
• Patch is not functioning correctly and needs to be replaced. Contact
Customer Care at 1 (440) 249-5440 for return instructions.
• Can be caused by the arm being raised, exposing the patch to ambient
temperatures. For best results the arm should be down and relaxed at the
side. Dismiss this alert, or Disable to permanently silence this alert for this
patch.
User Manual
TT-100 TT-200
24 48
Version 4.0 capability running the TempTraq app).
2. Activate Patch
Squeeze the (
and forefingers to activate the patch. You
will feel the switch "click" when you have
successfully activated the patch. Add your
patch to the TempTraq app.
SENSOR
4. Remove Backing
Remove the backing from the patch just prior
to application.
TT-300
72
) symbol between the thumb
ACTIVATION
SWITCH
PATCH ID &
EXPIRATION DATE
®
PATCH
RUN TIME
