AirGorilla PCO/UV N-Duct Installer Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PCO/UV N-Duct™
Model
Installer' s Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCO/UV N-Duct and is the answer not in the manual?

Questions and answers

Related Manuals for AirGorilla PCO/UV N-Duct

Summary of Contents for AirGorilla PCO/UV N-Duct

  • Page 1 PCO/UV N-Duct™ Model Installer’ s Manual...
  • Page 2 (VOC's) & odors. IMPORTANT POINTS FOR THE INSTALLER AirGorilla’ s PCO/UV N-Duct™ unit is designed for ease of installation and service. Cut just one hole and install. The unit never needs to be “un-installed” to replace the UV lamps.
  • Page 3 Provides over 5 times the killing power of the typical, ultraviolet systems. AUDIBLE ALERT – the PCO/UV N-Duct™ unit is often installed in areas not readily visible to the owner and therefore the Replace Lamp LED may not be seen when lit. When the UV lamps need to be replaced, an audible alert will also be sounded (a continuous beep) to notify the owner of the need to replace the lamps.

  • Page 4: Specifications

    Failure to do so will void all expressed or implied warranty representations. The PCO/UV N-Duct™ unit is designed for air disinfection and installs into the air handling system or ductwork. Select a mounting location that offers sufficient space for the mounting plate 7”...
  • Page 5 Once the unit is connected to an electrical power source it should be fully operational. The PCO/UV N-Duct™ unit has a “kill” switch activated by the Display Panel door. If the door is open, power to the electrical functions of the unit are shut off. The Display Panel door must be closed for the unit to operate.

  • Page 6: Troubleshooting

    – UV resistant safety glasses should be worn for this test) WARNINGS WARNING Electrical Shock – The PCO/UV N-Duct™ system is to be wired or plugged into 110 – 240 VAC electrical power. Ultraviolet Light is Harmful – Never look at a lit ultraviolet lamp without UV protective glasses and skin coverings.
  • Page 7 Grab the lamp base and pull it toward you gently. The lamps are held snug so a little force may be necessary to pull them out. The lamps are 16” long. 6. Install new, replacement lamps (AirGorilla #DR36-1). a. Make sure lamp is clean – use alcohol wipe to remove dirt and fingerprints.

  • Page 8: Limited Lifetime Warranty

    AirGorilla Corporation reserves the right to replace or repair the defective part or component. AirGorilla Corporation shall not be liable for any loss or damage of any kind, including any incidental or consequential damages resulting, directly or indirectly, from any breach of warranty, express or implied, or any other failure of this product.
