POPCORN HOUR WN-100 Quick Start Manual

R R
WN-100 Quick Start Guide WN-100 Quick Start Guide
How to Setup WN-100 Wireless USB Adaptor
Begin by removing the protective cap from the WN-100. Plug the WN-100 into one of the Popcorn Hour
device's USB slots.
Navigate to the Setup page and then select the Network option. Select the Mode box. The drop-down
menu will provide the option to select either Wireless Manual IP or Wireless Auto IP. Navigate down
and click the save button to proceed.
Preferences
Audio / Video
Network Share
DVD / Audio CD
Maintenance
Note: Manual mode will require an additional step to complete the installation.
The display will now switch to the SSID selection screen. Either select scan to look for nearby networks,
or enter the SSID manually.
Audio / Video
Network Share
DVD / Audio CD
Maintenance
o rk e d
R
n e tw
Re -
Figure 1.0 Setup WN-100 Wireless USB Adaptor screen
: Wired Manual IP
Mode
Wired Auto IP
Wireless Manual IP
:
Time Zone
Home .
Wireless Auto IP
. : pool.ntp.org
Time Server
.
off
:
Daylight Saving
Network .
.
.
. : 00.06.DC.41.DE.AC
MAC Address
IP Address :
192.168.0.230
configure IP
wireless config
/ / setup
Figure 2.0 Network option screen
None Detected
:
SSID List
select Scan
Home .
. -
Preferences :
SSID
.
None
:
Security
.
Network
*
:
Key
.
.
save cancel
.
/ / setup
Figure 3.0 SSID List screen
A -1 10
N o :
M od el
save
