RDS Technology ICP 300 User Manual

In-cab printer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Electro-Magnetic Compatibility (EMC)
This product complies with Council Directive 2004/108/EC
when installed and used in accordance with the relevant
instructions.
Service and Technical Support
PLEASE CONTACT YOUR NEAREST DISTRIBUTOR
If unknown then fax: 44 (0) 1453 733322
© Copyright RDS Technology Ltd 2008
Document number
S/DC/500-10-570: Issue 1.01 : 11/8/08
\UK570101.DOC
User Guide
ICP 300
In-Cab Printer
Operation
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICP 300 and is the answer not in the manual?

Questions and answers

Summary of Contents for RDS Technology ICP 300

  • Page 1 Service and Technical Support PLEASE CONTACT YOUR NEAREST DISTRIBUTOR If unknown then fax: 44 (0) 1453 733322 © Copyright RDS Technology Ltd 2008 Document number S/DC/500-10-570: Issue 1.01 : 11/8/08 \UK570101.DOC User Guide...

  • Page 2: Table Of Contents

    ICP 300 IN-CAB PRINTER Contents Introduction____________________________________________3 Parts List_______________________________________________3 Setup _________________________________________________4 Operation ______________________________________________5 Power-On Self-Test _____________________________________5 Status LED _____________________________________________5 Replacing the paper roll_________________________________6 Maintenance ___________________________________________7 Service ________________________________________________7 Specifications __________________________________________8...

  • Page 3: Introduction

    Introduction Figure 1 The RDS ICP 300 In-Cab printer is an ultra-compact thermal printer designed for easy paper loading. It accepts 58mm wide rolls up to 44mm dia. The printer is connected to and powered from the instrument via a single cable with RJ-12 connector, and operates with a supply voltage in the range 10- 35V dc.

  • Page 4: Setup

    ICP 300 IN-CAB PRINTER Setup Plug the printer cable RJ-12 connector into the back of the printer and then attach the mounting plate with the two M3 screws provided. The cable is connected normally to the upper port on a ‘Pro-Series’/’Psi’...

  • Page 5: Operation

    ICP 300 IN-CAB PRINTER Operation When installed with a Wizard instrument the printer is normally powered on as the vehicle is started. When installed with a Pro-Series/Psi instrument the printer is powered on when the instrument is switched on. The status LED illuminates and the printer mechanism is reset.

  • Page 6: Replacing The Paper Roll

    ICP 300 IN-CAB PRINTER Replacing the paper roll Pull the lever up until the lid is released. Do not use excessive force. Figure 3: Unlock paper compartment Replace the roll and press the lid at each side until it clicks shut.

  • Page 7: Maintenance

    ICP 300 IN-CAB PRINTER Maintenance Occasionally, it may be necessary to clean dust or foreign matter from the paper compartment. Wipe the paper compartment clean using a dry soft cloth only. The rubber roller can be removed for cleaning if necessary. Push the roller forwards at each end to disengage it from the slots (figure 5).

  • Page 8: Specifications

    ICP 300 IN-CAB PRINTER Specifications Printing Printing System Direct Thermal line head Characters per line Character matrix 24 x 8 Horizontal dot pitch 0.125mm (200 dpi) Vertical Dot pitch 0.125mm Printing width 48mm Max. print speed 10 lines per second MTBF Approx.
  • Page 9 ICP 300 IN-CAB PRINTER Issue 1: 17/7/07 Original issue Issue 1.01: 11/8/08 ref. p.3 Parts List...
