Wardenaar Infrarood Verwarming IP55 Series Manual

Quartz Infrared Outdoor Heaters
The following information should be considered when installing Quartz
Infrared Heaters.
Installation should always be carried out by a qualified electrician or a
competent person in accordance with current electrical regulations, protected by
a suitably rated isolator and fuse or type3 mcb.
•
The heater should be mounted horizontally where possible or at a maximum
angle of 35 degrees from the horizontal using the mounting brackets
provided to ensure adequate clearances.
•
If mounted on Parasols ensure the heater is left to completely cool before
closing.
•
A minimum air gap of 500mm should always be allowed between the top of
the heater and the ceiling, roof or canvas.
•
A safety distance of 1mtr should always be left in front of the heater.
•
Heaters should not be installed in areas where hazardous vapours may be
present as defined in BS5345
•
This fitting is rated classI and IP55 suitable for outdoor use. To maintain the
protection rating all connections to the mains must be done with a minimum
of IP55 equipment.
•
Ensure that there is no possibility of inflammable material coming into
contact with the heater, or is too near the heater.
The essential element of the heater is the halogen filled quartz linear lamp with
a tungsten element. This operates at about 1600°C and emits short wave
infrared radiant heat.
The lamp operates at full output almost instantly and emits a radiant energy of
1.6 microns.
Specifications
IP55 - 230V 1000W 4.5 Amps
IP55 - 230V 1500W 6.5 Amps
IP55 - 230V 2000W 8.5 Amps
This product conforms to EU Directive 2002/96/EC.
This appliance bears the symbol of the crossed waste bin. This
indicates that, at the end of its useful life, it must not be disposed of
as domestic waste, but must be taken to a collection centre for
waste electrical and electronic equipment. It is the user's
responsibility to dispose of this appliance through the appropriate
channels at the end of its useful life. Failure to do so may incur the
penalties established by laws governing waste disposal.
Protection - IP55
Protection - IP55
Protection - IP55
Wardenaar Infrarood
Verwarming BV
IP55 Series
Wall or Parasol Mounted
Infrared Heater
Wardenaar Infrarood Verwarming BV
Perenmarkt 10B,
1681 PG Zwaagdijk-Oost,
The Netherlands
Tel: +31 (0) 228 567729
Fax: +31 (0) 228 567797
www.wardenaar.com
info@wardenaar.com
INSTRUCTIONS SHOULD BE CAREFULLY READ BEFORE
INSTALLATION AND RETAINED BY THE USER.
